3-25
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for ROCK, NEWS, POP, JAZZ, CLASSICAL and
COUNTRY stations. TONE and the preset equalization
setting will appear on the display when you press AUTO
TONE. Each time you press it, another setting will
appear on the display. The manual setting allows tone
control to return to the BASS and TREB controls.
Use PUSHBUTTONS and AUTO TONE button to
program AUTO TONE for station presets.
Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set
all tone and speaker controls to the middle position,
press and hold the P
-TYPE LIST/AUDIO knob
when no tone or speaker control is active. The radio
will produce one beep and display ALL with the level
display in the middle position.FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers
and counterclockwise to move the sound to the rear
speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the fade to the middle position, select the
control and press and hold the P
-TYPE LIST/AUDIO
knob. The radio will produce one beep and set the
display level to the middle position. To set all tone and
speaker controls to the middle position, press and hold
the P
-TYPE LIST/AUDIO knob when no tone or
speaker control is active. The radio will produce one
beep and display ALL with the level display in the
middle position.

3-26
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS, the radio can:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information is
available. In rare cases, a radio station may broadcast
incorrect information that will cause the radio features
to work improperly. If this happens, please contact the
radio station.When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.
DISP: Press this knob to change what appears on the
display while using RDS. The display options are station
name, station frequency, PTY and the name of the
program (if available). Press and hold the display knob
to set the default display of the RDS station from the
displays available.
Accessing RDS Stations:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST/AUDIO knob to display the program type list.
2. Turn knob either clockwise or counterclockwise to
select a program type. List is alphabetical. If you
select ANY TYPE your radio will seek to the first
PTY available.
3. Push SEEK TYPE button to activate search.

3-27
TRAF: Press this button to receive traffic
announcements. If the current tuned station does not
broadcast traffic announcements, the radio will seek
to a station that does. The TRAF icon will flash on the
display. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette
tape, CD or FM radio by enabling the traffic interrupt
feature. Press the TRAF button once to seek to an RDS
station that supports the traffic interrupt feature if the
current tuned station does not. The TRAF icon will flash
on the display when seeking for a station that supports
traffic interrupt. When the traffic interrupt feature is on,
TRAF will appear on the display.
When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or
a cassette tape or compact disc is playing. The TRAF
icon and TRAFFIC will appear on the display while
the traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.VOL: Turn this knob clockwise to increase volume when
RDS interrupts regular play. Turn it counterclockwise to
decrease volume.
INFO: If the current station has a message, the INFO
icon will appear on the display. These text messages are
from the RDS broadcaster to the listening public and
may be general information such as artist and song title,
call in phone numbers, etc. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To scroll
through the message at your own speed, press the
INFO button again for less than one second. A new
group of words will appear on the display. Once the
complete message has been displayed, INFO will
disappear from the display until another new message
is received. The old message can be displayed by
pressing the INFO button until a new message is
received or a different station is tuned to.

3-28
P-TYPE LIST: Turn this knob clockwise or
counterclockwise to select the Program Type (PTY) you
want to listen to. TYPE and a PTY will appear on the
display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
P
-TYPE. If the radio cannot find the desired P-TYPE,
NONE will appear on the display and the radio will
return to the last station you were listening to.
SEEK TYPE: Press this button to go to a station with
the last selected PTY. TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station,
you will hear it, even if the volume is muted or a
cassette tape or compact disc is playing. If the cassette tape or compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
ALTERNATE FREQUENCY: This feature allows the
radio to switch automatically to a stronger station with
the same programming. AF is off by default from the
factory. Press and hold AM FM for two seconds to turn
alternate frequency on or off. AF ON or AF OFF will
appear on the display and the radio will beep once.
The radio will not switch automatically to other stations
when AF is off.

3-31 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone
Control (Option)
Playing the Radio
PWR: Press this button to turn the system on and off.
VOL: Turn this knob clockwise to increase volume.
Turn it counterclockwise to decrease volume.DISP: Press this button to display the clock with the
ignition off. Press this button to display an RDS station
frequency or program type when the radio is on.
AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press AUTO VOL to adjust the SCV.
AVOL will appear on the display. Each time you press
AUTO VOL, another volume setting (LOW, MEDIUM
or HIGH) will appear on the display. NONE will appear
on the display if the radio cannot find out the vehicle
speed. Then, as you drive, SCV automatically increases
the volume, as necessary, to overcome noise at any
particular speed. The volume level should always sound
the same to you as you drive. If you don't want to use
SCV, select OFF. Each volume setting allows for more
volume compensation at faster vehicle speeds.

3-33
Setting the Tone
BASS: Press and release the P
-TYPE LIST/AUDIO
knob until BASS appears on the display. Then turn the
knob clockwise to increase bass and counterclockwise
to decrease bass. The display will show the bass level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. To set bass to the middle
position, select the control and press and hold the
P
-TYPE LIST/AUDIO knob. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST/AUDIO
knob when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
TREBLE: Press and release the P
-TYPE LIST/AUDIO
knob until TREB appears on the display. Turn the knob
clockwise to increase treble and counterclockwise to
decrease treble. The display will show the treble level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. If a station is weak or
noisy, you may want to decrease the treble. To set treble to the middle position, select the control
and press and hold the P
-TYPE LIST/AUDIO knob.
The radio will produce one beep and set the display
level to the middle position. To set all tone and speaker
controls to the middle position, press and hold the
P
-TYPE LIST/AUDIO knob when no tone or
speaker control is active. The radio will produce
one beep and display ALL with the level display in
the middle position.
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for ROCK, NEWS, POP, JAZZ, CLASSICAL and
COUNTRY music stations. TONE and the preset
equalization setting will appear on the display when you
press AUTO TONE. Each time you press it, another
setting will appear on the display. The manual setting
allows tone control to return to the BASS and TREB
controls. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.

3-34
Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set
all tone and speaker controls to the middle position,
press and hold the P
-TYPE LIST/AUDIO knob
when no tone or speaker control is active. The radio
will produce one beep and display ALL with the level
display in the middle position.
FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers and
counterclockwise to move the sound to the rear speakers.
The middle position balances the sound between the
speakers. The display will show the speaker balance.
To set the fade to the middle position, select the control
and press and hold the P
-TYPE LIST/AUDIO knob. The radio will produce one beep and set the display
level to the middle position. To set all tone and speaker
controls to the middle position, press and hold the
P
-TYPE LIST/AUDIO knob when no tone or speaker
control is active. The radio will produce one beep and
display ALL with the level display in the middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS, the radio can:

Seek only to stations with the types of programs
you want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information
is available.

3-35
In rare cases, a radio station may broadcast incorrect
information that will cause the radio features to work
improperly. If this happens, please contact the
radio station.
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name
of the current program.
DISP: Press this knob to change what appears on the
display while using RDS. The display options are station
name, station frequency, PTY and the name of the
program (if available). Press and hold the display knob
to set the default display of the RDS station from the
displays available.
Accessing RDS Stations:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST/AUDIO knob to display the program type list.
2. Turn knob either clockwise or counterclockwise to
select a program type. List is alphabetical. If you
select ANY TYPE your radio will seek to the first
PTY available.
3. Push SEEK TYPE button to activate search.TRAF: Press this button to receive traffic
announcements. If the current tuned station does not
broadcast traffic announcements, the radio will seek to
a station that does. The TRAF icon will flash on the
display. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette tape,
CD or FM radio by enabling the traffic interrupt feature.
Press the TRAF button once to seek to an RDS station
that supports the traffic interrupt feature if the current
tuned station does not. The TRAF icon will flash on the
display when seeking for a station that supports traffic
interrupt. When the traffic interrupt feature is on, TRAF
will appear on the display.
When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or
a cassette tape or compact disc is playing. The TRAF
icon and TRAFFIC will appear on the display while
the traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.
