2001 CHEVROLET CAVALIER Owners Manual

6-59
Vehicle Identification Number (VIN)
This is the legal identifier for your vehicle. It appears
on a plate in the front corner of the instrument panel,
on the driver's side. You can see it if you look through
the windshield from outside your vehicle. The VIN also
appears on the Vehicle Certification and Service Parts
labels and the certificates of title and registration.
Engine Identification
The 8th character in your VIN is the engine code. This
code will help you identify your engine, specifications
and replacement parts.
Service Parts Identification Label
You'll find this label on your spare tire cover. It's very
helpful if you ever need to order parts. On this label is:

your VIN,

the model designation,

paint information and

a list of all production options and
special equipment.
Be sure that this label is not removed from the vehicle.

6-60
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment
can keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring is protected by fuses. Should your
headlamps fail to function, have your headlamp system
checked right away.
Windshield Wiper Fuse
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow or ice, the wiper will stop until the motor cools.
If the overload is caused by some electrical problem,
have it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed.

6-61 Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links. This greatly reduces the
chance of damage caused by electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
If you ever have a problem on the road and don't have a
spare fuse, you can ªborrowº one that has the same
amperage. Just pick some feature of your vehicle that
you can get along without
-- like the radio or cigarette
lighter
-- and use its fuse if it is the correct amperage.
Replace it as soon as you can.
There are two fuse blocks in your vehicle: the instrument
panel fuse block and the engine compartment fuse block.Instrument Panel Fuse Block
The fuse panel is located at the driver's side of the
instrument panel. To open, push the tab on the access
door to the left and pull the door forward. Make sure to
insert the tabs when replacing the cover.

6-62
Fuse Usage
TURN
-B/U Turn Signals, Back-Up Lamps
ERLS Engine Relays
BCM/CLU Body Control Module,
Instrument Panel Cluster
PCM Powertrain Control Module
IGN MDL Ignition Module
F/P
-INJ Fuel Pump, Fuel InjectorsFuse Usage
AIR BG Air Bag
CRUISE Cruise Control Module/Switch
ABS Anti
-Lock Brake (Ignition)
Blank Not Used
RFA BATT Remote Keyless Entry System
MIRROR Power Mirror
LT HDLP Left Headlamp
RDO/INTLP Radio, Interior Lamps
RT HDLP Right Headlamp
CLSTR Instrument Panel Cluster
EXT LP Exterior Lamps
CIG Cigarette Lighter,
Diagnostic Link Connector
FOG Fog Lamps
HORN Horn
Blank Not Used
Blank Not Used

6-63
Fuse Usage
STOP/HZD Stop Lamps, Hazard Lamps
Blank Not Used
Blank Not Used
RR DEFOG Rear Window Defogger
PWR ACC Power Door Locks
Blank Not Used
Blank Not Used
Blank Not Used
O
2 HTR Oxygen Sensor Heater
HVAC Climate Control System
WIPER Windshield Wiper
BCM Body Control Module
AMPL Audio Amplifier
PWR WDO Power Windows, Sunroof
DRL Daytime Running Lamps (Relay)Engine Compartment Fuse Block
The engine compartment fuse block is located on
the driver's side of the engine compartment.
Lift off the cover to check the fuses. See ªEngine
Compartment Overviewº in the Index for more
information on location.

6-64
Fuse Usage
IGN Ignition Switch Circuits
BATT 1 Exterior Lamps, Power Outlet,
Horn, Audio Amplifier
BATT 2 Rear Defogger,
Power Locks, Stoplamps
ABS Anti
-Lock Brake System
COOLING FAN Engine Cooling Fan
PCM/HVAC Powertrain Control Module,
Heater and A/C Blower
BLO Heater and A/C Blower
PCM Powertrain Control Module
A/C A/C Compressor
FUEL PUMP Fuel Pump
HEATER BLOWER Heater and A/C Blower
Replacement Bulbs
Lamps Bulb Number
Back
-Up Lamps 912. . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking/Turn Signal Lamps 3157. . . . . . . . . . .
Center High
-Mounted Stoplamp
Interior Mounted 1141. . . . . . . . . . . . . . . . . . . . . . .
Spoiler Mounted 912. . . . . . . . . . . . . . . . . . . . . . . .
Halogen Headlamps, High/Low Beam 9007. . . . . . .
Tail/Turn Signal Lamps 3057. . . . . . . . . . . . . . . . . .
Turn Signal Lamps (Rear Sedan) 3057. . . . . . . . . .
Dome/Reading Lamp (If Equipped)
Base Model 912. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Up
-Level Model 168 & 906. . . . . . . . . . . . . . . . . . .
Sunroof Model 912 (Dome). . . . . . . . . . . . . . . . . . .
212
-2 (Mirror)

6-65
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the Index
for more information.
Engine Crankcase4.0 quarts (3.8 L) . . . . . . . . . . . .
Automatic Transaxle (3
-Speed)
Complete Overhaul 7.0 quarts (6.6 L). . . . . . . . . . .
When draining or replacing torque converter, more fluid
may be needed.
Automatic Transaxle (4
-Speed)
Complete Overhaul 9.5 quarts (9.0 L). . . . . . . . . . .
Manual Transaxle
Complete Drain and Refill 1.8 quarts (1.7 L). . . . .
Cooling System
2.2L 10.2 quarts (9.6 L). . . . . . . . . . . . . . . . . . . . . .
2.4L 10.2 quarts (9.6 L). . . . . . . . . . . . . . . . . . . . . .
Refrigerant
Air ConditioningSee refrigerant charge . . . . . . . .
label under hood.Fuel Tank14.3 U.S. gallons (54.1 L) . . . . . . . . . . . .
Tire Pressures, SizesSee Tire
-Loading . . . . . . . . . . .
Information label on driver's door.
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
All capacities are approximate. When adding, be sure to fill
to the appropriate level, as recommended in this manual.
2.2L Engine Specifications
VIN Engine Code 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 115 @ 5,000 rpm. . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 180
F (82
C) . . . . . . . . . . .
2.4L Engine Specifications
VIN Engine Code T. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 150 @ 5,600 rpm. . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 180
F (82
C) . . . . . . . . . . .

6-66
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
2.2L ACDelco
Type A-1172C . . . . . . . . . . . . . . . .
2.4L ACDelco
Type A-1172C . . . . . . . . . . . . . . . .
Engine Oil Filter
2.2L ACDelco

Type PF-47 . . . . . . . . . . . . . . . . . .
2.4L ACDelco
Type PF-44 . . . . . . . . . . . . . . . . . .
Spark Plugs
2.2L ACDelco

Type 41-928 . . . . . . . . . . . . . . . . . .
Gap: 0.040 inch (1.02 mm)
2.4L ACDelco

Type 41-963 . . . . . . . . . . . . . . . . . .
Gap: 0.050 inch (1.27 mm)
Windshield Wiper Blade (Shepherd's Hook Type)
Left Side 22 inches (56 cm). . . . . . . . . . . . . . . . . . .
Right Side 17 inches (43 cm). . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length
All Models 180.9 inches (460.0 cm). . . . . . . . . . . . .
Width
All Models 75.4 inches (191.5 cm). . . . . . . . . . . . . .
Height
Coupe 53.2 inches (135.1 cm). . . . . . . . . . . . . . . . .
Sedan 54.9 inches (139.4 cm). . . . . . . . . . . . . . . . . .
Wheelbase
All Models 104.1 inches (264.4 cm). . . . . . . . . . . . .
Front Tread
All Models 57.6 inches (146.3 cm). . . . . . . . . . . . . .
Rear Tread
All Models 56.8 inches (144.3 cm). . . . . . . . . . . . . .
