2001 CHEVROLET CAVALIER Owners Manual

6-35 Headlamps
1. To remove the six plastic fasteners from the shield
use a screwdriver to pull up the center of the
fastener. Be careful not to break the fasteners that
hold the shield in place.
2. Using a 13 mm socket, remove the two bolts from
the headlamp. Pull the headlamp assembly up and
toward the front of the vehicle to access the
bulb assembly.
When replacing the driver's side headlamp, twist the
bulb assembly one
-eighth turn counterclockwise and
remove it from the headlamp assembly.
When replacing the passenger's side headlamp, twist
the bulb assembly one
-eighth turn clockwise and
remove it from the headlamp assembly.

6-36
3. Disconnect the bulb base from the socket by lifting
the plastic locking tab.
4. Remove the black collar by turning it counterclockwise.5. Remove the bulb by pulling the bulb straight out.
6. Snap a new bulb into the socket.
7. Reinstall the bulb assembly by reversing
Steps 1 through 3, making sure the lower leg of
the headlamp bracket is properly seated into the
wedge
-shaped retainer.

6-37 Front Park and Turn Signal Lamps
1. Follow Step 1 under ªHeadlamps.º
2. Place the tip of a screwdriver through the rectangle
hole in the headlamp bracket. Apply pressure to the
snap feature (toward the outboard of the vehicle).
Guide the lamp forward.
3. When the lamp is removed twist the socket to
remove from the lamp. (The bulb is connected to
the wire harness).
4. Replace the bulb and reinstall the socket.

6-38
5. Align the outboard pin to the outboard tab in the
bracket. Align the (two) inboard pins with the hole
in the headlamp bracket.6. Push the front park and turn lamp straight in until
you hear a snap. The snap feature is visible through
the slot in the headlamp bracket.

6-39 Taillamps and Rear Turn Signal Lamps
To replace a bulb, do the following:
1. Remove the fastener which holds down the trunk
trim. On vehicles without a convenience net, pry the
fastener loose. On vehicles with a convenience net,
remove the net and unscrew the fastener. Then pull
down the trunk trim.
2. Remove the assembly by turning it one
-quarter
turn counterclockwise.
3. To remove the bulb, pull it out.
4. Push in a new bulb.
5. Reverse all steps to reinstall the taillamp assembly.

6-40 Back-Up Lamps
To replace a back-up lamp, do the following:
1. Open the trunk lid and locate the back
-up lamp
assembly on the trunk lid.
2. Gently remove the bulb from the socket by turning it
counterclockwise and pulling it out.
3. Replace the bulb in the socket by aligning the tabs
and turning the bulb clockwise.
Dome Lamp with Integral Reading Lamps
To replace a bulb, do the following:
1. Insert the tip of a screwdriver into the slot at the
rear of the lens.
2. With the screwdriver, push the tab rearward to
release the lamp lens.
3. Push the lens forward to release the two tabs at the
front of the lens.
4. Gently remove and replace the bulb(s).
5. Reverse Steps 1 through 3 to reinstall the lens.
Dome Lamp without Integral
Reading Lamps
To replace a bulb, do the following:
1. From the rear of the dome lamp lens, insert the
flat tip of a screwdriver between the roof trim and
the lens.
2. With the screwdriver, push the tab at the rear of
the lens forward to release the lens.
3. Pull the lamp lens rearward to release the two
front tabs.
4. Gently remove and replace the bulb(s).
5. Reverse Steps 1 through 3 to reinstall the lens.

6-41
Windshield Wiper Blade Replacement
Windshield wiper blades should be inspected at least
twice a year for wear or cracking. See ªWiper Blade
Checkº in the index for more information.
Replacement blades come in different types and are
removed in different ways. For the proper type and
length, see ªCapacities and Specificationsº in the Index.
Here's how to remove the Shepherd's Hook type:
1. Pull the windshield wiper arm away from
the windshield.
2. Push the release lever and slide the wiper assembly
toward the driver's side of the vehicle.
3. Install a new blade by reversing Steps 1 and 2.

6-42
Tires
Your new vehicle comes with high-quality tires made by
a leading tire manufacturer. If you ever have questions
about your tire warranty and where to obtain service,
see your Chevrolet Warranty booklet for details.
CAUTION:
Poorly maintained and improperly used tires
are dangerous.

Overloading your tires can cause
overheating as a result of too much friction.
You could have an air
-out and a serious
accident. See ªLoading Your Vehicleº in
the Index.
CAUTION: (Continued)
CAUTION: (Continued)

Underinflated tires pose the same danger
as overloaded tires. The resulting accident
could cause serious injury. Check all tires
frequently to maintain the recommended
pressure. Tire pressure should be checked
when your tires are cold.

Overinflated tires are more likely to be
cut, punctured or broken by a sudden
impact
-- such as when you hit a pothole.
Keep tires at the recommended pressure.

Worn, old tires can cause accidents. If your
tread is badly worn, or if your tires have
been damaged, replace them.
