The Instrument Panel -- Your Information System

2-71
The main components of the instrument panel are:
A. Air Outlets
B. Driver Information Center Buttons
C. Turn Signal/Multifunction Lever
D. HVAC Steering Wheel Controls (or Cellular
Telephone Controls, If Equipped)
E. Instrument Panel Cluster
F. Windshield Wiper/Washer Lever
G. Audio Steering Wheel Controls
H. Ignition Switch
I. Air Vent Control Thumbwheel
J. Hazard Warning Button
K. Audio SystemL. Lamp Controls
M. Hood Release
N. Fuel Door Release
O. Trunk Release
P. Cruise Control
Q. Horn
R. Heated Seat Controls
S. Traction Control Switch
T. Console Shift Lever
U. Convenience Storage/Optional Ashtray
V. Electronic Climate Controls
W. Glove Box

2-72
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how
fast you're going, how much fuel you're using and many other things you'll need to drive safely and economically.
United States version shown, Canada similar

2-73
Speedometer and Odometer
The speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
The odometer shows how far your vehicle has been
driven, in either miles (used in the United States) or
kilometers (used in Canada).
You may wonder what happens if a vehicle has to have
a new odometer installed. The new one may read the
correct mileage. This is because your vehicle's computer
has stored the mileage in memory.
Trip Odometer
There are two trip odometers, which are indicated by
Trip A and Trip B. In order to change from one to the
other, press the A/B portion of the TRIP button.
By pressing the bottom of
this button, you can tell
how many miles you have
traveled on either your
Trip A or Trip B odometer
since you last set the
odometer back to zero.Press the RESET part of the button until zeros appear to
reset the odometers.
If your vehicle is first sold in the United States, the
trip odometer will return to zero after 999.9 miles
(1 609 km). If your vehicle is first sold in Canada, the
trip odometer will return to zero after 1 999.9 km
(1,242 miles). The RESET TRIP A/B button only
resets the trip odometer (A or B) that is being displayed.
Each trip odometer has to be reset individually.
Display Mode
This button is located
between the RESET
TRIP A/B button and
the ENG/MET button.
Press DSPL MODE to turn the backlighting and the
digital speed image on and off.

2-74
English/Metric Display
You can go back and forth
from English (miles) to
metric (kilometers) by
pressing this button.
Other readings such as temperature, fuel and trip
odometer also go back and forth between English
and metric.
Vehicle Speed Limiter
This feature prevents your vehicle from exceeding
speeds that the tires are not rated for. When this
happens, the engine's fuel supply is shut off. When the
vehicle speed slows, the fuel supply will come on again.
Tachometer
This gage indicates the
engine speed in revolutions
per minute (rpm).
NOTICE:
Do not operate the engine with the tachometer in
the red area or engine damage may occur.

2-75
Engine Speed Limiter
This feature prevents the engine from operating at too
many revolutions per minute (rpm). When the engine's
rpm are critically high, the fuel supply to the engine is
shut off. When the engine speed slows, the fuel supply
will come on again. This helps prevent damage to
the engine.
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.
When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Safety Belt Reminder Light
When the key is turned to ON or START, a chime will
come on for about eight seconds to remind people to
fasten their safety belts.
The safety belt light will
also come on and stay on
for about 70 seconds. If the
driver's belt is already
buckled, the light will come
on briefly, but the chime
will not sound.

2-76
Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG (United States) or the air
bag symbol (Canada). The system checks the air bag's
electrical system for malfunctions. The light tells you if
there is an electrical problem. The system check
includes the air bag sensors, the air bag modules, the
wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
United States Canada
This light will come on when you start your vehicle, and
it will flash for a few seconds. Then the light should go
out. This means the system is ready.If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help avoid
injury to yourself or others, have your vehicle
serviced right away if the air bag readiness light
stays on after you start your vehicle.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.

2-77
Passenger Air Bag On/Off Lights
(If Equipped)
United States Canada
If your vehicle is equipped with the Automatic
Occupant Sensor (AOS) system, when the key is turned
to ON or START, the passenger air bag ON/OFF lights
will come on for five seconds as a check. After five
seconds, either the OFF light or the ON light will stay
on to let you know if the right front passenger's frontal
and side impact air bags are off or on. See ªAutomatic
Occupant Sensor (AOS) Systemº in the Index for more
on this, including important safety information.If, after five seconds, one of the lights does not go out or
if there are no lights at all, there is a problem with the
lights. There may also be a problem with the lights if
they both don't come on as a check. See your dealer
for service.
United States Canada
If the OFF light appears, it means that the AOS system
has turned off the right front passenger's frontal and side
impact air bags.
