2001 BMW Z8 Owners Manual

17n

IndexDataTechnologyRepairsCar careControlsOverview

Cockpit

1

d

Turn signal indicator58

>

Parking lamps70

>

High beams70

>

Headlamp flasher58
2 Side lamps/Low beams69
3 Washer/Wiper system59
4 Hazard warning flashers24
5 Central locking system32
6 Rear window defroster for the
hardtop60
7 Shift lever58
To engage reverse gear, pull the
lever across the gate to the left to
overcome the detent
8 Cruise control61
9 Adjusting the steering wheel47
10 Horn: entire surface
11 Rear fog lamp70
12 Unlocking the hood104
13

d

Unlocking the luggage
compartment lid37

>

Unlocking the fuel filler door25

18n

Instrument cluster
520us002

19n

IndexDataTechnologyRepairsCar careControlsOverview

Instrument cluster

1 Fuel gauge with indicator lamp for
fuel reserve62
2 Speedometer with indicator and
warning lamps for

>

Dynamic Stability Control
(DSC)22

>

Engine electronics22
3 Instrument panel lighting69
4 Tachometer62
with indicator and warning lamps
for:

>

Battery charge current20

>

Convertible top operation41

>

Tire Pressure Warning (RDW)20

>

Antilock Brake System (ABS)21

>

Parking brake/Brake hydraulic
system/Cornering Brake Control
(CBC)20

>

Service Engine Soon22

>

Engine oil pressure/Engine oil
level20, 21
5 Coolant temperature gauge with
"Coolant temperature too high"
warning lamp63
6 Indicator and warning lamps for:

>

Rear fog lamp22

>

Turn signal, right23
7 Clock648 Control knob for:

>

Clock64

>

Trip odometer, reset to zero62
9 Indicator and warning lamps for:

>

Please fasten safety belts21

>

High beam23

>

Airbags21
10 Indicator for:

>

Odometer62

>

Trip odometer62

>

Service Interval63
11 Indicator and warning lamps for:

>

Turn signal, left23

>

Brake pads22

20n

Indicator and warning lamps

Technology that monitors itself

Many of the systems for your BMW
monitor themselves automatically, both
during engine starts and while you are
driving. Indicator and warning lamps
identified by "

l

" are tested for proper
operation whenever the ignition key is
turned. They each light up once for
different periods of time.
The indicator lamps signal defects in
monitored systems either by remaining
lit after the engine is started or by
coming on in the course of normal
vehicle operation. Refer to the following
section for detailed information on how
to respond to the various types of warn-
ings.

Red: stop immediately

Battery charge current
The alternator is no longer
charging the battery. Indicates a
defect in the alternator drive belt or the
charging circuit. Please contact the
nearest BMW center.
Never attempt to continue driving
if the V-belt is defective: the
engine could overheat and sustain
serious damage. A broken or damaged
V-belt will also lead to a sudden
increase in steering effort.

<

Engine oil pressure

l

Stop vehicle and switch off
engine immediately. Check the
engine oil level and top up as required.
If the oil level is correct, please contact
the nearest BMW center.
Do not continue driving. The
engine could sustain damage
owing to inadequate lubrication.

<



Tire Pressure Warning (RDW)

l

Flashing warning lamp in addi-
tion to an acoustic signal: a tire
failure has occurred. Carefully reduce
speed to less than 50 mph (80 km/h),
and avoid hard braking or steering
maneuvers.
For additional information, refer to
page 67.
Brake warning lamp

l

If the lamp comes on when the
parking brake is not engaged,
check the brake fluid level. Before
driving further, be sure to read the
notes on pages 91 and 112.
Brake warning lamp for Cana-
dian models.

21n

IndexDataTechnologyRepairsCar careControlsOverview

Indicator and warning lamps

Red and yellow: continue driving
cautiously

The red brake warning lamp
comes on together with the
yellow indicator lamps for ABS
and DSC:
The entire ABS, CBC, DSC and
DBC control system has failed.
Continue driving cautiously and
defensively. Avoid hard brake
applications. Please have the
system checked by your BMW center
as soon as possible.
For additional information, refer to
pages 65, 88.
Indicator and warning lamps for
Canadian models.

Red: an important reminder

Brake warning lamp

l

Comes on when the parking
brake is applied Ð an additional
acoustic signal sounds when the
vehicle is set in motion.
For additional information, refer to
page 57.



Brake warning lamp for Cana-
dian models.
Please fasten safety belts

l

Together with an acoustic
signal. Comes on until the safety
belts are fastened.
For additional information on safety
belts, refer to page 50.
Airbags

l



Please have the system
inspected by your BMW center.
For additional information, refer to
pages 51, 148.

Yellow: check at the earliest
opportunity

Antilock Brake System (ABS)

l

ABS has been deactivated in
response to system malfunction.
Unrestricted conventional brake system
performance remains available. Please
have the system inspected by your
BMW center.
For additional information, refer to
page 88.
Antilock Brake System (ABS)
warning lamp for Canadian
models.
Engine oil level

Comes on while driving: the oil
level is at the absolute minimum;
add engine oil as soon as possible. Do
not drive more than approx. 30 miles
(50 km) without stopping to add oil.
For additional information, refer to
page 109.
Engine oil level
Comes on after the engine has
been shut off: add engine oil at
the earliest opportunity (when you stop
to refuel).
For additional information, refer to
page 109.

22n
Indicator and warning lamps
Brake pads l

Have the brake pads checked.
For additional information, refer
to page 91.
Dynamic Brake Control (DBC) l

Malfunction in the DBC system.
The brake system continues to
provide unrestricted conventional
performance.
For additional information, refer to
page 90.
Dynamic Brake Control (DBC)
warning lamp for Canadian
models.
Dynamic Stability Control
(DSC) l
Indicator lamp flashes:
The system is actively regulating engine
torque.
If the indicator lamp does not go out
after the engine is started, or if it comes
on during normal driving and stays on:
DSC has been switched off or has been
deactivated because of a malfunction.
In the event of a malfunction, have the
system checked by your BMW center.
For additional information, refer to
page 65.
Service Engine Soon l
If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the emis-
sions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW center at the
earliest possible opportunity.
For additional information, refer to
page 124.
Service Engine Soon warning
lamp for Canadian models.
Engine electronics
Malfunction in the engine's
electronic control system. The
electronics revert to a default mode
permitting continued operation, but at
lower than usual engine speeds and
with reduced power. Please have the
system inspected by your BMW center.
Yellow: for your information
Rear fog lamp
Lights up whenever the rear
foglamp is turned on.
For additional information, refer to
page 70.

23n
IndexDataTechnologyRepairsCar careControlsOverview
Indicator and warning lampsGreen: for your information
Turn signal indicator
Flashes when the turn signals
are operated. Rapid flashing
indicates a system malfunction.
For additional information, refer to
page 58.
Blue: for your information
High beams
Comes on when the high beams
are on or the headlamp flasher
is activated.
For additional information, refer to
pages 58, 70.

24n
Hazard warning flashers Warning triangle
*
First-aid kit
*
The button flashes continuously when
the hazard warning flashers are on.
To help you locate the switch at night,
the button is also illuminated whenever
the vehicle's lamps are on.520de003
The warning triangle is stored beneath
a floor panel located in the luggage
compartment.
Comply with legal requirements
requiring a hazard warning
triangle to be kept on board.<520de004
The first-aid kit is located under the
luggage compartment's floor panel
beneath the onboard tool kit.
Some of the articles in the first-aid
kit may be used within a limited
time only. Check the expiration dates of
each of the items regularly, and replace
any whose expiration dates have
passed. You can get replacements in
any drugstore or pharmacy.
Comply with laws requiring a first-aid
kit in the vehicle.< 520de005
