2001 Acura RL 3.5 Owner's Manual

Audio System

To select a different disc, press the appropriate preset button (1— 6). If
you select an empty slot in the
magazine, the changer will, after
finding that slot empty, try to load
the CD in the next slot. This continues until it finds a CD to load
and play.
You can use the SEEK bar to select tracks within a disc. If you push andrelease either side of the SEEK bar (— or +), the system will move to
the beginning of a track. Push the +
button to move to the beginning of
the next track, and push the — but-
ton to move to the beginning of the
current track. If you push and hold the SEEK bar
(— or +), you will hear a beep and
the system will continue to move across tracks. Release the button
when you think it has reached thedesired place on the disc.
REPEAT — When you activate the Repeat feature by pressing the
REPEAT button, the system
continuously replays the current
track. You will see REPEAT in the display as a reminder. Press the
REPEAT button again to turn it off.
RANDOM PLAY — This feature,
when activated, plays the tracks on a CD in random order, rather than in
the order they are recorded on the CD. To activate Random Play, press
the A. SELECT button. You will see
A. SELECT in the display. The sys- tem will then select and play tracks
randomly on the current disc. When
all tracks on that disc have been
played, the next disc is loaded and played randomly. This continues un-
til you deactivate Random Play by
pressing A. SELECT again.
To take the system out of CD mode, press the AM/FM button or insert acassette in the player. If a tape is
already in the cassette player, press
the CD/TAPE button. When you
return to CD mode, play will contin-
ue at the same point that it left off.
If you turn the system off while a CD
is playing, either with the PWR/VOL
knob or the ignition switch, play will
continue at the same point when you
turn it back on.

Protecting Compact Discs

For information on how to handleand protect compact discs, see page
161.

Comfort and Convenience Features

Audio System
Loading the CD Changer
The CD changer is located in the trunk on the driver's side. 1. Slide the lid to open the CD
changer. 2. Push the EJECT button to remove
the CD magazine. The magazine
will pop up automatically.

CONTINUED

Comfort and Convenience Features
CD CHANGER

EJECT

BUTTON
Slide

Audio System

3. To install a CD, pull the tab out to remove the tray from the maga-

zine.
4. Put a CD on a tray with the printed
surface up as shown.
5. Reinstall the tray in the magazine. Repeat this procedure for the oth-er five trays. 6. Store all six trays in the magazine,
and then reinstall the magazine in
the CD changer as shown in the il-
lustration.
7. Slide the lid closed until it clicks.
Comfort and Convenience Features TAB
TRAY

Audio System

Protecting Compact Discs
Handle a CD by its edges; never
touch either surface. Contamination
from fingerprints, liquids, felt-tip pens, and labels can cause the CD to
not play properly, or possibly jam in
the drive. When a CD is not being played, store
it in its case to protect it from dust
and other contamination. To prevent
warpage, keep CDs out of direct sunlight and extreme heat.
To clean a disc, use a clean soft cloth. Wipe across the disc from the centerto the outside edge. A new CD may be rough on the
inner and outer edges. The small
plastic pieces causing this roughness
can flake off and fall on the re-
cording surface of the disc, causing
skipping or other problems. Remove
these pieces by rubbing the inner
and outer edges with the side of a
pencil or pen.
Never try to insert foreign objects in
the CD player or the magazine.
Comfort and Convenience Features

Audio System

CD Changer Error Indications
If you see an error indication in the
display while operating the CD
changer
, find the cause in the chart
to the right. If you cannot clear the
error indication, take the car to your
Acur

a dealer.

Comfort and Convenience Features

Audio System

Remote Audio Controls
Two controls for the audio system are mounted in the steering wheel
hub. These let you control basic
functions without removing your
hand from the wheel. The top and bottom buttons adjust the volume up ( ) or down ( ).
Press the proper button and hold it
until the desired volume is reached,
then release it.
The AUDIO/CH button has three functions, depending on whether you are listening to the radio, or playing a
cassette or CD.
If you are listening to the radio, use
the AUDIO/CH button to change stations. Each time you press this
button, the system advances to the next preset station on the band you
are listening to. You will see the
number of the selected Preset button
in the display. To change bands,
press the AM/FM button on the audio system's front panel. If you are playing a cassette, use the
AUDIO/CH button to advance to the next selection. You will see "FF"
blinking in the display when you
press the AUDIO/CH button. The system fast forwards until it senses asilent period, then goes back to
PLAY.
If you are playing a CD, the system skips to the beginning of the next
track each time you push the
AUDIO/CH button. You will see the disc and track number in the display.
Comfort and Convenience Features

AUDIO/CH
BUTTON

Audio System

Theft ProtectionYour car's audio system will disable itself if it is disconnected fromelectrical power for any reason. To
make it work again, the user must
enter a specific five-digit code in the Preset buttons. Because there are
hundreds of number combinations
possible from five digits, making the system work without knowing the
exact code is nearly impossible.
You should have received a card that lists your audio system's code
number and serial number. It is bestto store this card in a safe place at
home. In addition, you should write
the audio system's serial number in
this Owner's Manual. If you should
happen to lose the card, you mustobtain the code number from your
Acura dealer. To do this, you will need the system's serial number. If your car's battery is disconnected
or goes dead, or the radio fuse is
removed, the audio system will disable itself. If this happens, you
will see "Code" in the frequency display the next time you turn on thesystem. Use the Preset buttons to
enter the five-digit code. If it is
entered correctly, the radio will start

playing.

If you make a mistake entering the
code, do not start over or try to
correct your mistake. Complete the
five-digit sequence, then enter the correct code. You have three tries to
enter the correct code. If you are
unsuccessful in three attempts, you
must then leave the system on for one hour before trying again. You will have to store your favorite
stations in the Preset buttons after
the system begins working. Your original settings were lost when
power was disconnected.

Comfort and Convenience Features

Security System

The security system helps to protect your car and valuables from theft.
The horn sounds and a combination of headlights, parking lights, side
marker lights and taillights flashes if someone attempts to break into your
car or remove the radio. This alarm
continues for two minutes, then the system resets. To reset an alarming
system before the two minutes have
elapsed, unlock either front door
with the key or the remote
transmitter.
The security system sets auto- matically fifteen seconds after you
lock the doors, hood, and trunk. For
the system to activate, you must lock
the doors from the outside with the
key, lock tab, door lock switch, or
remote transmitter. The security system light next to the driver's door
lock starts blinking immediately to show you the system is setting itself. Once the security system is set,
opening any door (without using the
key or the remote transmitter), or
the hood, will cause it to alarm. It also alarms if the radio is removed
from the dashboard or the wiring is

cut.
With the system set, you can still
open the trunk with the master key
or the remote transmitter without
triggering the alarm. The alarm will sound if the trunk lock is forced, or
the trunk is opened with the trunk
release button on the driver's door.
The security system will not set if the hood, trunk, or any door is not
fully closed. If the system will not set,check the Door and Brake Lamp
Monitor on the instrument panel (see page 57), to see if the doors
and trunk are fully closed. Since it is not part of the monitor display,
manually check the hood.
Do not attempt to alter this system
or add other devices to it.

Comfort and Convenience Features

SECURITY SYSTEM LIGHT
