2001 Acura RL bulb

Lights

Replacing Rear Bulbs

1. Open the trunk. Undo the fastener on the side of
the trunk lining by pushing on the
center of the fastener's head until
it pops in. Pull the lining back. 2. Determine which of the four bulbs
is burned out: stop/taillights, back-
up light, or turn signal.
3. Remove the socket by turning it one-quarter turn counterclockwise. 4. Pull the bulb straight out of its

socket.

Push the new bulb straight intothe socket until it bottoms.
5. Reinstall the socket into the light assembly by turning it clockwise
until it locks.
6. Test the lights to make sure the new bulb is working.
7. Reinstall the trunk lining. Make sure it is installed under the edgeof the trunk seal.

Maintenance
FASTENER

Lights

8. Reset the fastener by pushing on the pointed end until it pops backalmost flush with the fingers on
the housing.
9. Put the fastener in the hole in the side of the trunk lining and push
on the center until it locks (the
center is flush with the head). Replacing a High-mount Brake
Light Bulb
1. Open the trunk and remove the socket from the light assembly by
turning it one-quarter turn counter-
clockwise.
2. Remove the bulb by pushing it in slightly and turning it counter-
clockwise.
Install the new bulb in the socket. 3. Reinstall the socket. Turn it
clockwise until it locks.
4. Test the lights to make sure the new bulb is working.

Maintenance

Lights

Replacing a Rear License Plate
Bulb
1. Remove the license light assembly by carefully prying on the left
edge of the lens with a flat-tipscrewdriver and pulling the
assembly out. 2. Remove the lens from the bulb
holder by pulling the lens whilesqueezing the tabs on both sides
of the holder. 3. Pull the bulb straight out of its
socket. Push the new bulb in until
it bottoms in the socket.
4. Turn on the parking lights and check that the new bulb is
working.
5. Put the lens back on the bulb holder and push it until it latches.
6. Slide the right side of the light assembly into the hole. Push on
the left side to latch the assembly
into place.
Maintenance
LIGHT ASSEMBLY

BULBBULB HOLDER

LENS

Lights

Replacing Bulbs in the Interior Courtesy Lights
The courtesy lights in the doors and roof come apart the same way. Theydo not use the same type of bulb.
1. Remove the lens by carefully prying on the edge of the lens witha fingernail file or a small flat-tip
screwdriver. Do not pry on the
edge of the housing around the

lens.
Door light:

Pry on the top middle of the lens.

Front ceiling light:
Pry on the front edge of the lens

in the middle. Rear ceiling light:
Pry on the rear edge of the lensin the middle. Remove the bulb
cover by pulling it straight down.

CONTINUED

Maintenance
DOOR LIGHT
FRONT

REAR

Lights
2. Remove the bulb by pulling it straight out of its metal tabs.
3. Push the new bulb into the metal tabs. Snap the lens back in place. Replacing the Trunk Light Bulb
1. Remove the lens by carefully prying on the edge of the lens in
the middle with a fingernail file ora small flat-tip screwdriver. Do not
pry on the edge of the housing around the lens. 2. Remove the bulb by pulling it
straight out of its metal tabs.
3. Push the new bulb into the metal tabs. Snap the lens back in place.

Maintenance

VANITY MIRROR LIGHT

TRUNK

Specifications

Technical Information
page 236

"' Low beam headlight bulbs are a type of high voltage discharge tube
(D2R).

page 295
page 294
