2000 YAMAHA XV535 stop start

L
3-3
INSTRUMENT AND CONTROL FUNCTIONS
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-3.frame
1. Engine stop switch
2. Lights switch
3. Start switch Ò Ó
4. Fuel reserve switch ÒFUELÓ
EAU00138
Engine stop switch
The engine stop switch is a safety de-
vice for use in an emergency such as
when the motorcycle overturns or if
trouble occurs in the throttle system.
Turn the switch to Ò Ó to start the en-
gine. In case of emergency, turn the
switch to Ò Ó to stop the engine.
EAU00134
Lights switch
Turning the light switch to Ò Ó,
turns on the auxiliary light, meter lights
and taillight. Turning the light switch to
Ò Ó, turns the headlight on also.
EAU00143
Start switch Ò Ó
The starter motor cranks the engine
when pushing the start switch.
EC000005
CAUTION:
See starting instructions prior to
starting the engine.
EAU00149
Fuel reserve switch ÒFUELÓ
This switch should usually be kept
ÒONÓ while riding. If you run out of fuel
while riding, move the switch to ÒRESÓ
and refuel at the first opportunity. Then
move the switch to ÒONÓ.
When the switch is turned to reserve
ÒRESÓ, about 2.5 L remain in the fuel
tank.
1. Clutch lever
EAU00152
Clutch lever
The clutch lever is located on the left
handlebar, and the ignition circuit cut-
off system is incorporated in the clutch
lever holder. Pull the clutch lever to the
handlebar to disengage the clutch, and
release the lever to engage the clutch.
The lever should be pulled rapidly and
released slowly for smooth clutch oper-
ation. (Refer to the engine starting pro-
cedures for a description of the ignition
circuit cut-off system.)

R
3-10
INSTRUMENT AND CONTROL FUNCTIONS
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-3.frame
EAU00331
Sidestand/clutch switch
operation check
Check the operation of the sidestand
switch and clutch switch against the in-
formation below.
TURN THE MAIN SWITCH TO ÒONÓ
AND THE ENGINE STOP SWITCH TO
ÒÓ.
TRANSMISSION IS IN GEAR AND
SIDESTAND IS UP.
PULL IN CLUTCH LEVER AND
PUSH THE START SWITCH.
ENGINE WILL START.
CLUTCH SWITCH IS OK.
EW000045
If improper operation is noted, con-
sult a Yamaha dealer immediately.
SIDESTAND IS DOWN.
ENGINE WILL STALL.
SIDESTAND SWITCH IS OK.

R
5-2
OPERATION AND IMPORTANT RIDING POINTS
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-5.frame
TURN THE MAIN SWITCH TO ÒONÓ AND THE
ENGINE STOP SWITCH TO Ò Ó.
IF THE TRANSMISSION IS IN NEUTRAL
AND THE SIDESTAND IS DOWN,
PUSH THE START SWITCH.
ENGINE WILL START.
RETRACT THE SIDESTAND AND PUT
THE TRANSMISSION IN GEAR.
IF THE TRANSMISSION IS IN GEAR
AND THE SIDESTAND IS UP,
PULL IN THE CLUTCH LEVER AND PUSH START
THE SWITCH. ENGINE WILL START.
MOTORCYCLE CAN BE RIDDEN.MOTORCYCLE CAN BE RIDDEN.

L
5-3
OPERATION AND IMPORTANT RIDING POINTS
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-5.frame
1. Turn the main switch to ÒONÓ and
the engine stop switch to Ò Ó.
2. Shift the transmission into neutral.
NOTE:
When the transmission is in neutral, the
neutral indicator light should be on. If
the light does not come on, ask a
Yamaha dealer to inspect it.
3. Turn on the starter (choke) and
completely close the throttle grip.
4. Start the engine by pushing the
start switch.
NOTE:
If the engine fails to start, release the
start switch, wait a few seconds, then
try again. Each attempt should be as
short as possible to preserve the bat-
tery. Do not crank the engine more
than 10 seconds on any one attempt.
5. After starting the engine, move the
starter (choke) to the halfway posi-
tion.
NOTE:
For maximum engine life, never accel-
erate hard with a cold engine!
6. After the engine is warm, turn off
the starter (choke) completely.
NOTE:
The engine is warm when it responds
normally to the throttle with the starter
(choke) turned off.
EAU01258
Starting a warm engine
The starter (choke) is not required
when the engine is warm.
EC000046
CAUTION:
See the ÒEngine break-inÓ section
prior to operating the motorcycle for
the first time.

L
5-5
OPERATION AND IMPORTANT RIDING POINTS
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-5.frame
EAU00424
Tips for reducing fuel
consumption
Your motorcycleÕs fuel consumption
depends to a large extent on your
riding style. The following tips can help
reduce fuel consumption:
lWarm up the engine before riding.
lTurn off the starter (choke) as
soon as possible.
lShift up swiftly and avoid high en-
gine speeds during acceleration.
lDo not double-clutch or rev the en-
gine while shifting down and avoid
high engine speeds with no load
on the engine.
lTurn off the engine instead of let-
ting it idle for an extended length
of time, i.e. in traffic jams, at traffic
lights or railroad crossings.
EAU00436
Engine break-in
There is never a more important period
in the life of your motorcycle than the
period between zero and 1,000 km. For
this reason we ask that you carefully
read the following material. Because
the engine is brand new, you must not
put an excessive load on it for the first
1,000 km. The various parts in the en-
gine wear and polish themselves to the
correct operating clearances. During
this period, prolonged full throttle oper-
ation, or any condition which might re-
sult in excessive heating of the engine,
must be avoided.
EAU00444
0 ~ 150 km
Avoid operation above 1/3 throttle.
Stop the engine and let it cool for 5 to
10 minutes after every hour of opera-
tion. Vary the speed of the motorcycle
from time to time. Do not operate it at
one set throttle position.
150 ~ 500 km
Avoid prolonged operation above
1/2 throttle. Rev the motorcycle freely
through the gears, but do not use full
throttle at any time.
500 ~ 1,000 km
Avoid cruising speeds in excess of
3/4 throttle.
EC000056
CAUTION:
After 1,000 km of operation, be sure
to replace the engine oil, oil filter
and final gear oil.

L
6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-6.frame
EC000066
CAUTION:
lDo not put in any chemical addi-
tives. Engine oil also lubricates
the clutch and additives could
cause clutch slippage.
lBe sure no foreign material en-
ters the crankcase.
8. Start the engine and warm it up for
a few minutes. While warming up,
check for oil leakage. If oil leakage
is found, stop the engine immedi-
ately and check for the cause.
1. Final gear oil drain bolt
2. Final gear oil
3. Final gear oil filler bolt
4. Correct level
EAU02943
Final gear oil
EW000066
Do not let foreign material enter the
final gear case. Be sure oil does not
get on the tire or wheel.
Oil level inspection
1. Place the motorcycle on a level
place and hold it in an upright posi-
tion. The engine should be cool at
ambient temperature.2. Remove the oil filler bolt and
check the oil level. The oil level
should be at the brim of the filler
hole. Add the recommended oil if
necessary.
Oil replacement
1. Place an oil pan under the final
gear case.
2. Remove the oil filler bolt and drain
bolt to drain the oil.
3. Install and tighten the drain bolt to
the specified torque.
4. Fill the gear case to the brim of the
filler hole with the recommended
oil. Tightening torque:
Drain bolt:
23 Nm (2.3 mákg)

L
6-13
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/E-6.frame
EAU01168
Idle speed adjustment
NOTE:
A diagnostic tachometer must be used
for this procedure.
1. Attach the tachometer. Start the
engine and warm it up for a few
minutes at approximately 1,000 to
2,000 r/min. Occasionally rev the
engine to 4,000 to 5,000 r/min.
The engine is warm when it quick-
ly responds to the throttle.
1. Throttle stop screw
2. Set the idle to the specified engine
speed by adjusting the throttle
stop screw. Turn the screw in di-
rectiona
to increase engine
speed and in direction b
to de-
crease engine speed.
NOTE:
If the specified idle speed cannot be
obtained by performing the above ad-
justment, consult a Yamaha dealer.Standard idle speed:
1,150 ~ 1,250 r/min
a. Free play
EAU00635
Throttle cable free play
inspection
There should be a free play of 3 ~
5 mm at the throttle grip. If the free play
is incorrect, ask a Yamaha dealer to
make this adjustment.

L
INDEX
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9149_XV535-E6/English/XV535IX.-
A
Air filter .................................................6-10
B
Battery ..................................................6-25
Brake and clutch lever lubrication ........6-22
Brake and shift pedal lubrication ..........6-22
Brake fluid replacement ........................6-21
Brake light switch adjustment ...............6-19
C
Cable inspection and lubrication ..........6-21
Carburetor adjustment ..........................6-12
Care ........................................................7-1
Checking the front brake pads and
rear brake shoes ................................6-19
Clutch lever ............................................3-3
Clutch lever free play adjustment .........6-17
Controls/Instruments ..............................2-3
D
Dimmer switch ........................................3-2
E
Engine break-in ......................................5-5
Engine oil ................................................6-7
Engine stop switch .................................3-3
F
Final gear oil ...........................................6-9
Front brake lever ....................................3-4
Front brake lever free play
adjustment ........................................ 6-17
Front fork inspection ............................ 6-23
Fuel ........................................................ 3-5
Fuel reserve switch ................................ 3-3
Fuel tank cap ......................................... 3-5
Fuse replacement ................................ 6-27
G
Give safety the right of way ................... 1-1
H
Handlebar switches ............................... 3-2
Dimmer switch ................................. 3-2
Engine stop switch ........................... 3-3
Fuel reserve switch .......................... 3-3
Horn switch ...................................... 3-2
Lights switch .................................... 3-3
Pass switch ...................................... 3-2
Start switch ...................................... 3-3
Turn signal switch ............................ 3-2
Headlight bulb replacement ................. 6-27
Helmet holder ........................................ 3-8
High beam indicator light ....................... 3-1
Horn switch ............................................ 3-2
I
Identification number records ................ 9-1
Idle speed adjustment ......................... 6-13
Indicator lights ....................................... 3-1
High beam indicator light ................. 3-1
Neutral indicator light ....................... 3-1
Turn indicator light ............................ 3-1
Inspecting the brake fluid level ............ 6-20
K
Key identification number ...................... 9-1
L
Left view ................................................. 2-1
Lights switch .......................................... 3-3
M
Main switch ............................................ 3-1
Model label ............................................ 9-2
N
Neutral indicator light ............................. 3-1
P
Parking ................................................... 5-6
Pass switch ............................................ 3-2
Periodic maintenance and lubrication .... 6-2
Pre-operation check list ......................... 4-1
R
Rear brake pedal ................................... 3-4
Rear brake pedal height and free play
adjustment ......................................... 6-18
Rear shock absorber adjustment ........... 3-9
Rear suspension lubrication ................ 6-23
Recommended shift points
(for Switzerland only) .......................... 5-4
Right view .............................................. 2-2
