2000 PONTIAC BONNEVILLE ignition

1-5 Heated Front Seats (Option)
This option is only available if your vehicle is equipped
with the power lumbar control.
The front seat controls
are located on the
center console.
Push the ON part of the button once for a HI setting or
twice for a LO setting. Push the OFF part of the button
to turn the heated seat off. The LO setting warms the
seatback and cushion until the seat approximates body
temperature. The HI setting heats the seatback and
cushion to a slightly higher temperature.
The heated seats can only be used when the ignition
is turned on. The heated elements in the seats
automatically turn off when the vehicle's ignition is
turned off.
Reclining Front Seatbacks
If your vehicle has a power
recliner, the vertical control
described previously in
this section reclines the
front seatbacks.
If your vehicle has the manual recliner, lift the lever on
the outer side of the seat and move the seatback to the
desired position. Release the lever to lock the seatback.
Pull up on the lever and the seat will go to an
upright position.

1-28
NOTICE:
If you damage the covering for the driver's or
the right front passenger's air bag, or the air
bag covering on the driver's and right front
passenger's seatback, the bag may not work
properly. You may have to replace the air bag
module in the steering wheel, both the air bag
module and the instrument panel for the right
front passenger's air bag, or both the air bag
module and seatback for the driver's and right
front passenger's side impact air bag. Do not
open or break the air bag coverings.
Servicing Your Air Bag-Equipped Vehicle
Air bags affect how your vehicle should be serviced.
There are parts of the air bag systems in several places
around your vehicle. Your dealer and the service manual
have information about servicing your vehicle and the
air bag systems. To purchase a service manual, see
ªService and Owner Publicationsº in the Index.
CAUTION:
For up to 10 seconds after the ignition key is
turned off and the battery is disconnected, an
air bag can still inflate during improper service.
You can be injured if you are close to an air bag
when it inflates. Avoid yellow connectors. They
are probably part of the air bag systems. Be sure
to follow proper service procedures, and make
sure the person performing work for you is
qualified to do so.
The air bag systems do not need regular maintenance.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-9 Remote Keyless Entry (If Equipped)
2
-14 Trunk
2
-15 Theft
2
-16 Universal Theft-Deterrent (Option)
2
-17 PASS-Key
III
2
-19 New Vehicle ªBreak-Inº
2
-20 Ignition Positions
2
-21 Starting Your Engine
2
-22 Engine Coolant Heater (If Equipped)
2
-23 Automatic Transaxle Operation
2
-26 Parking Brake
2
-27 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)
2
-31 Parking Over Things That Burn
2
-31 Engine Exhaust2
-32 Running Your Engine While You're Parked
2
-33 Windows
2
-33 Horn
2
-34 Tilt Wheel
2
-34 Turn Signal/Multifunction Lever
2
-41 Exterior Lamps
2
-43 Interior Lamps
2
-47 Mirrors
2
-50 Storage Compartments
2
-51 Sun Visors
2
-52 Air Inflator System (Option)
2
-54 Express Sunroof (Option)
2
-58 The Instrument Panel -- Your
Information System
2
-64 Warning Lights, Gages and Indicators
2
-79 Head-Up Display (Option)
2
-84 Driver Information Center (DIC) (Option)

2-2
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or other
controls or even make the vehicle move. Don't
leave the keys in a vehicle with children.

2-3
There is a master key that
works in all of the lock
cylinders (driver's door,
trunk, ignition and
glove box).
There is also a VALET
key which only operates
the driver's door and
the ignition.Both the master and VALET key have a transponder
embedded into the key for security and theft deterrence.
The keys also come with a bar code tag. Keep the bar
code tag in a safe place. If you lose your key, you will
be able to have a new one made using the bar code tag.
The replacement key must have a transponder
embedded in it.
If you need a new key, contact your dealer who can
obtain the correct key code. Remember to carry the
pre
-cut emergency key which Pontiac sends after
delivery. (This service is unavailable in Canada.)
In an emergency, call Pontiac Roadside Assistance at
1
-800-ROADSIDE (1-800-762-3743).
In Canada, call 1
-800-268-6800.
NOTICE:
Your vehicle has a number of features that can
help prevent theft. But you can have a lot of
trouble getting into your vehicle if you ever lock
your keys inside. You may even have to damage
your vehicle to get in. So be sure you have
extra keys.

2-5 Central Door Unlocking System
If your vehicle has a theft-deterrent system, all doors
will unlock if the key is held in the outside key cylinder
unlock position for more than two seconds. The doors
will also unlock if the key is turned to the unlock
position twice in three seconds.
Power Door Locks
With power door locks,
you can lock or unlock
all the doors of your
vehicle using the driver's
or front passenger's door
lock switch.
Programmable Automatic Door Locks
Close the doors and turn on the ignition. Every time you
move the shift lever out of PARK (P), all of the doors
will lock. And, every time you stop and move the shift
lever into PARK (P), the doors will unlock. If someone
needs to get out while you're not in PARK (P), have that
person use the manual or power door lock switch. When
the door is closed again, it will not lock automatically.
Just use the manual or power door lock switch to lock
the door again.
Overriding Lock Delay
If you need to lock your doors before shifting out of
PARK (P), just use the manual or power door lock
switch to lock the doors.
Personalization Programming
You can program the automatic door lock feature to
change to the following modes:
Mode 0: No automatic door lock or unlock.
Mode 1: All doors automatically lock when shifted
out of PARK (P). No automatic door unlock.
Mode 2: All doors automatically lock when shifted
out of PARK (P). Only the driver's door automatically
unlocks when shifted into PARK (P).

2-6
Mode 3: All doors automatically lock when shifted
out of PARK (P). All doors automatically unlock when
shifted into PARK (P).
Mode 4: All doors automatically lock when shifted out of
PARK (P). Only the driver's door automatically unlocks
when the key is turned to OFF. (DIC equipped vehicles only)
Mode 5: All doors automatically lock when shifted out
of PARK (P). All doors automatically unlock when the
key is turned to OFF. (DIC equipped vehicles only)
Vehicles are delivered programmed in Mode 3.
If your vehicle is not equipped with remote keyless
entry, use the following procedure to change modes:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 3.
3. Cycle the shift lever, starting in PARK (P), out of
PARK (P) and then back into PARK (P), to advance
by one mode for each cycle.
After the first cycle, you will hear a door locking
action, which identifies the current mode.
4. Release the power door lock switch. The automatic door
locks will remain in the most recent mode selected.If your vehicle is equipped with remote keyless entry,
use the following procedure to change modes:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 4.
3. Press the button with the lock symbol on the remote
keyless entry transmitter. The automatic door locks
will remain in the current mode.
4. Press the button with the lock symbol on the
transmitter again. Each time the transmitter's lock
button is pressed, the mode will advance by one,
going from 3 to 0 to 1, etc.
The door locks will cycle according to the mode
entered. (Mode ª0º has no feedback.)
5. Release the power door lock switch. The automatic door
locks will remain in the most recent mode selected.
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through the
DIC. See ªDriver Information Center Personalization
Programmingº in the Index.

2-7 Delayed Locking
This feature lets the driver delay the actual locking of the
vehicle. When the driver's power door lock switch or the
remote keyless entry lock button is pressed, with the key
removed from the ignition and the driver's door open, a
chime will sound three times to signal that the delayed
locking system is active. When all doors have been closed,
the doors will lock automatically after five seconds. If any
door is opened before this, the five
-second timer will reset
itself once all the doors have been closed again.
Pressing the driver's/passenger's door lock switch or the
remote keyless entry lock button again will override
this feature.
Personalization Programming
The delayed locking feature can be turned on or off.
Vehicles are delivered with delayed locking off.
If your vehicle is not equipped with remote keyless
entry, the delayed locking feature can be turned on or off
by using the following procedure:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 4.3. Cycle the park lamp switch from off to on six times.
On the sixth cycle, the doors will unlock to confirm
that the feature has been turned on. Your doors will
remain locked if delayed locking is off.
4. To change modes, cycle the park lamp switch once
more. A locking action will confirm the new mode.
5. Release the power door lock switch.
To turn the feature off, repeat the previous procedure.
If your vehicle is equipped with remote keyless entry,
your vehicle can be programmed to each driver's
preference for each of the transmitters. Use the
following procedure to turn the feature off using the
corresponding transmitter:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the power door lock switch in the
LOCK position throughout this procedure. All the
doors will lock.
3. Press the button with the unlock symbol on the
transmitter. The lock delay is still on and all the
doors will unlock.
4. Press the button with the unlock symbol on the
transmitter again. Lock delay is now off and all the
doors will lock.
5. Release the power door lock switch.
