2000 PONTIAC BONNEVILLE ignition

2-33
Windows
Power Windows
Switches on the driver's door panel operate each of the
windows when the ignition is on or when Retained
Accessory Power is active. In addition, each passenger
door has a switch for its own window.Express
-Down Windows
When the driver's and front passenger's window switch
is pushed all the way rearward, the window will lower
completely. The window can be opened in smaller
amounts by pressing the switch rearward slightly,
to the first stop.
To stop the window while it is lowering in the express
mode, press the switch again, then release. To raise the
window, hold the switch forward.
Window Lock
Press the LOCK button on the driver's door armrest to
disable all passenger window switches. (If your vehicle
has a Driver Information Center (DIC), you can also set
the control to only lock out the rear window switches.
See ªDriver Information Centerº in the Index.)
The driver's window switches will still be operable.
Press the LOCK button again to allow passengers to use
their window switches.
An indicator light in the button will glow when the
window lock function is on.
Horn
Press on the center area of the steering wheel to sound
the horn.

2-36
Turn the control to this symbol to turn on the:

Parking Lamps

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
Turn the headlamp control to this symbol to turn
on the:

Headlamps

Parking Lamps

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
Turn the headlamp switch back to the off position to
turn all of the lamps and lights off.Wiper
-Activated Headlamps
This feature turns on the low
-beam headlamps, instrument
panel cluster backlighting and taillamps when the Twilight
Sentinel
 is in day mode and after the windshield wipers
have been in use for approximately six seconds.
To operate the wiper
-activated headlamps, the Twilight
Sentinel must be on. If the wiper
-activated headlamps are on
and the ignition switch is turned to RUN, the wiper
-activated
headlamps will continue. When you turn the key to LOCK,
the wiper
-activated headlamps will immediately turn off.
The wiper
-activated headlamps will also turn off if you turn
off the Twilight Sentinel or the windshield wipers.
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high beam,
push the lever forward. To change from high beam to low
beam, pull the turn signal lever toward you, then release it.
When the high beams are
on, this light on the
instrument panel cluster
will also be on.

2-41
Ending Cruise Control
There are three ways to turn off the cruise control:

Step lightly on the brake pedal,

move the cruise switch to OFF, or

push the cruise lever toward the driver.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
Headlamps
See ªTurn Signal/Multifunction Leverº in the Index.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.A light sensor on top of the instrument panel monitors
the exterior light level for the operation of DRL and
Twilight Sentinel
, so be sure it isn't covered. The DRL
system will make your high
-beam headlamps come on
at a reduced brightness when:

The ignition is on,

the headlamp switch is off, and

the transaxle is not in PARK (P).
When the DRL are on, only your high
-beam headlamps
will be on at reduced intensity. The taillamps,
sidemarker and other lamps won't be on. Your
instrument panel won't be lit either.
When it's dark enough outside, your regular intensity
headlamps will come on at full brightness and the DRL
lighting will turn off. The park lamps that normally
come on with your headlamps will also come on.
When it's bright enough outside, the regular intensity
headlamps and park lamps will turn back off, and the
reduced brightness DRL lighting will turn back on.
To idle your vehicle during the day with the DRL off,
shift the transaxle into PARK (P). The DRL will stay
off until you shift out of PARK (P).
At night, you can turn off all exterior lamps when you
are in PARK (P) by turning the Twilight Sentinel knob
all the way to OFF.

2-42
If the knob was already in OFF, it must be cycled to ON
and back to OFF. Turn the knob clockwise to turn the
exterior lighting back on. The lamps will come back on
automatically when you put the transaxle in gear.
The Twilight Sentinel will keep your headlamps on for
up to three minutes, to light your way when you leave
your vehicle. The timer will start when you move your
ignition key from the RUN position.
See ªTwilight Sentinel

º in the Index to learn how to
operate this feature.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps
The fog lamps button is located below the twilight knob
to the left of the steering wheel.An indicator light in the button will glow when the fog
lamps are on. Your parking lamps will also come on
automatically while the fog lamps are active.
If your fog lamps are on when you use your high beams
or flash
-to-pass feature, the fog lamps will be disabled
while the feature is being used.
Twilight Sentinel

Twilight Sentinel
will keep your headlamps on for up
to three minutes, to light your way when you leave
your vehicle.
To operate Twilight Sentinel, turn the DELAY knob
located to the left of the steering column on the
instrument panel fully clockwise for the three
-minute
delay. Turn it counterclockwise to reduce the delay.
Turn the knob to OFF to turn Twilight Sentinel off.

2-43
At night, you can turn off all exterior lamps when you
are in PARK (P) by turning the Twilight Sentinel knob
all the way to OFF. If the knob was already in OFF, it
must be cycled to ON then back to OFF, to turn the
exterior lighting off. The lamps will come back on when
you turn the knob clockwise.
If the Twilight Sentinel lighting is active, it can be
disabled by turning on the manual parking lamps. This
lighting will be disabled until the key is turned from
RUN or until the manual park lamps are turned OFF.
Also, it's possible that your headlamps may go out if
you drive from a dark area into a bright area like a
lighted parking lot. If this happens, turn on your
headlamps with the regular headlamp switch.
Exterior Lighting Battery Saver
If the manual lamp control has been left on, the exterior
lamps will turn off approximately 10 minutes after the
ignition is turned to OFF and any door has been opened.
This protects against draining the battery in case you
have accidentally left the headlamps or parking lamps
on. If you need to leave the lamps on for more than
10 minutes, use the manual control to turn the lamps
back on after turning the ignition to OFF and opening
any door. To delay the lamps from turning off,
see ªTwilight Sentinel

º in the Index.
Interior Lamps
Instrument Panel/Brightness Control
When it is dark outside, you can brighten or dim your
instrument panel cluster lights by turning the DIM knob in
the light control. Turn the knob clockwise to brighten the
instrument panel cluster lights and displays. Turn the knob
clockwise all the way to turn on the interior courtesy lamps.
Turn the knob counterclockwise to dim the instrument panel
cluster lights and displays and to turn off the courtesy lamps.
Courtesy Lamps
If it is dark enough outside, when any door is opened,
several lamps will come on. They make it easier for you
to enter and leave the vehicle. Turn the dimmer knob all
the way clockwise to turn the interior courtesy lamps on.
Illuminated Entry
If it is dark enough outside and you press the button with
the unlock symbol on the remote keyless entry transmitter,
the interior courtesy lamps will come on and stay on for
approximately 40 seconds. The lamps will turn off
immediately by pressing the button with the lock symbol
on the remote keyless entry transmitter, turning the ignition
key to RUN or activating the power door locks.
If a door is left ajar, your interior lamps will turn off
after 10 minutes to save your battery.

2-44
Delayed Entry Lighting
When you open the door to enter your vehicle, the
interior lamps will come on if it is dark outside. When
you close the door with the ignition off, the interior
lamps will stay on for 25 seconds or until the ignition is
turned on. Please note that locking the doors with the
power door lock switch, or with the lock button on the
remote keyless entry transmitter, will override the
delayed entry lighting and the lamps will turn
off immediately.
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate turn off after
you remove the key from the ignition.
Delayed Exit Lighting
This feature will turn on the interior lamps for
25 seconds after you remove the key from the ignition
while the doors are closed and it is night. This will give
you time to find the door handle or lock switches as
you exit the vehicle.
This lighting will only be deactivated if the key is
reinserted into the ignition switch or the power door
locks are activated.
Parade Dimming
To activate the instrument panel backlighting during the
day, turn the headlamp switch to the parking lamp or
headlamp position. Dimming of the instrument panel
display is not possible during daylight hours. The
instrument panel display can only be adjusted when the
parking lamps or headlamps are on and it is dark outside.
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter is pressed, the DRL headlamps,
parking lamps and back
-up lamps will turn on if it is
dark enough outside.
Personalization Programming
This feature can be programmed in the on or off mode for
each transmitter. Vehicles are delivered with this feature on.
To turn the feature off:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains on at this time and the horn will
chirp twice.

2-45
4. Press the instant alarm on the transmitter again. Perimeter
lighting is disabled and the horn will chirp once.
5. Release the door lock switch. The perimeter lighting
feature is now off.
To turn the feature on:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains off at this time and the horn will
chirp once.
4. Press the instant alarm on the transmitter again.
Perimeter lighting is now enabled and the horn will
chirp twice.
5. Release the door lock switch. The perimeter lighting
feature is now on.
This procedure only changes the mode for the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through the
DIC. See ªDriver Information Center Personalization
Programmingº in the Index.Front Reading Lamps
The front reading lamps will come on as courtesy lamps
when you open any of the doors while it is dark outside.
They will also come on as part of the interior lighting
features listed previously.
To turn on a reading lamp when the doors are closed,
press either switch. Press it again to turn the lamp off.
To avoid draining your vehicle's battery, be sure to turn
off the reading lamps when leaving your vehicle. See
ªInadvertent Power Battery Saverº later in this section
for more information.

2-46
Rear Reading Lamps
The rear reading lamps will come on as courtesy lamps
when you open any of the doors while it is dark outside.
They will also come on as part of the interior lighting
features listed previously.
To turn on a reading lamp when the doors are closed,
press either switch. Press it again to turn the lamp off.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp or cigarette lighters. When the ignition
is turned off, the power to these features will
automatically turn off after 10 minutes. Power will be
restored for an additional 10 minutes if any door is
opened, the trunk is opened or the courtesy lamp switch
is turned on. To restore power back to the cigarette
lighters the ignition must be turned back to RUN.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at
higher revolutions per minute (rpm) than normal to
make sure the battery charges. High electrical loads may
occur when several of the following are on: headlamps,
high beams, fog lamps, rear window defogger, high
blower fan, heated seats and engine cooling fans.
