2000 PONTIAC BONNEVILLE ignition

2-51
To open a rear ashtray, lift the cover.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other smoking
materials could set them on fire, causing damage.
The cigarette lighter is located next to the storage tray.
To use a lighter, just push the center in all the way and
let it go. When it is ready, the center will pop back out
by itself. Pull out the entire unit to use it.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
The cigarette lighter will only operate when the ignition
key is in the RUN position and for 10 minutes after
turning the ignition OFF. If you would like the lighter to
operate regardless of ignition position, and for unlimited
periods of time, see ªEngine Compartment Bussed
Electrical Centerº in the Index or see your dealer.
Sun Visors
To block out glare, you can swing down the visors.
You can also remove them from the center mount and
swing them to the side, while the auxiliary sunshade
remains to block glare from the front.
Visor Vanity Mirror
Open the cover to expose the vanity mirror.
If your vehicle has the optional lighted vanity mirrors,
the lamps come on when you open the cover.

2-52
Air Inflator System (Option)
Some vehicles have an air inflator for use in maintaining
proper air pressure for the tires. The air inflator is
located in the trunk. The air inflator will work only with
the ignition on.
Pressing the AIR button will activate the inflator for
ten minutes.
The air inflator comes with a kit that includes a 20
-foot
(6.1 m) hose and an air pressure gage, as well as
instructions and special adapters for inflating things like
an air mattress or a basketball.
CAUTION:
Inflating something too much can make it
explode, and you or others could be injured. Be
sure to read the inflator instructions, and inflate
any object only to its recommended pressure.
Accessory Power Outlet
The accessory power outlet (12-volt) is located inside
the overhead console (if equipped) and at the rear of the
front console (if equipped). If your vehicle is equipped
with an overhead console, access the accessory power
outlet by sliding the access door to the side. If your
vehicle is equipped with a floor console, the power
outlet is at the rear of the floor console. Remove the
protective cap which covers the outlet.
The outlet can be used to plug in electrical equipment
such as a cellular telephone, CB radio, etc. Follow the
proper installation instructions that are included with
any electrical equipment you install.

2-53
The accessory power outlet will only operate when the
ignition key is in the RUN position and for 10 minutes
after turning the ignition OFF. If you would like the
accessory power outlet to operate regardless of ignition
position, and for unlimited periods of time, see ªEngine
Compartment Bussed Electrical Centerº in the Index or
see your dealer.
Leaving an accessory on for a long period of time, or a
fuse in the wrong place, can drain the vehicle's battery.
NOTICE:
When using the accessory power outlet, the
maximum load of any electrical equipment
should not exceed 15 amps.
OnStar
System (If Equipped)
Onstar is a vehicle communications service. The
following services are available through a subscription
with OnStar and are available 24 hours a day:
Emergency Services

Automatic Notification of Air Bag Deployment

Theft Notification and Stolen
-Vehicle Tracking

Roadside Assistance with Location

Remote Diagnostics

OnStar MED
-NET

Accident Assist
Convenience Services

Remote Door Unlock

Route Support

Concierge Services

Ride Assist
A complete user's guide is provided with the OnStar
System. For more information contact OnStar
at 1
-888-ONSTAR7.

2-54
Express Sunroof (Option)
If your vehicle is equipped
with this option, the switch
is located between the
sun visors.
The sunroof switch can be operated in four directions to
control sunroof movement. The switch will work only
when the ignition is on or when the ignition is off and
the Retained Accessory Power is active.
The sunroof has both manual and express features for
opening the glass panel and sunshade.Press and hold the switch rearward to the first position
to open the glass panel and sunshade. The sunshade can
also be opened by hand. To close the glass panel, press
and hold the switch forward. As the glass panel closes,
it will open slightly toward the vent position to provide
a better seal. The sunshade can only be closed by hand.
Press and release the switch rearward to the second
position to express open the glass panel. It will stop in a
partially open position. The glass panel may be fully
opened by pressing the switch rearward again. When the
glass panel is express opening, pressing the switch in
any direction will stop it. Please note that if you press
and hold the switch in the express open position for
more than one and a half seconds, the express open
operation will be overridden and the sunroof will
operate manually.
To vent open the glass panel, press and hold the switch
upward. The sunshade must be opened by hand.
To close the glass panel, pull and hold the
switch downward.

2-59
A. Air Outlets
B. Turn Signal/Multifunction Lever
C. Audio System Steering Wheel Controls
D. Windshield Wiper Lever
E. Steering Column Shift Lever
F. Driver Information Center (DIC) ControlsG. Audio System
H. Hazard Warning Flashers Control
I. Twilight Sentinel

and Fog Lamp Controls
J. Ignition Switch
K. Comfort Control System
L. Glove Box

2-65
If the driver's belt is already buckled, the light will
come on briefly, but the chime will not sound.
Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
This light will come on
when you start your vehicle,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help avoid
injury to yourself or others, have your vehicle
serviced right away if the air bag readiness light
stays on after you start your vehicle.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
On vehicles with the optional DIC, a SERVICE AIR
BAG message will be displayed when there is a problem
with the air bag system. See ªDIC Warnings and
Messagesº in the Index for more information.

2-66
Battery Warning Light (If Equipped)
This light will come on
briefly when you start the
vehicle, as a check to show
you it is working; then it
should go out.
If it stays on, or comes on while you are driving, you
may have a problem with the electrical charging system.
It could indicate that you have a generator problem or
another electrical system problem. Have it checked right
away. Driving while this light is on could drain
your battery.
If you must drive a short distance with the light on, be
certain to turn off all your accessories, such as the radio
and comfort control system.
Some instrument panel clusters with a voltmeter gage do
not have a battery warning light. They have a CHECK
GAGES warning to indicate a problem.
On vehicles with the optional DIC, a CHECK CHARGE
SYSTEM message will be displayed and a warning
chime will sound. See ªDIC Warnings and Messagesº in
the Index for more information.
Voltmeter (If Equipped)
You have a voltmeter
unless you have the
supercharged engine.
When the ignition is running, the gage shows the
condition of the charging system. Readings between the
red warning zones indicate the normal operating range.
Readings in the red warning zones indicate a possible
problem in the electrical system.
On vehicles with the systems monitor, the CHECK
GAGES light will also come on, and a warning chime
will sound if there is a problem in the electrical system.
Have your vehicle serviced immediately.
On vehicles with the optional DIC, a CHECK CHARGE
SYSTEM message will be displayed and a warning chime
will sound if there is a problem in the electrical system. Have
your vehicle serviced immediately. See ªDIC Warnings and
Messagesº in the Index for more information.

2-67 Brake System Warning Light
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though, you
need both parts working well.
If the warning light comes on, there is a brake problem.
Have your brake system inspected right away.
United States Canada
This light should come on briefly when you turn the
ignition key to RUN. If it doesn't come on then, have it
fixed so it will be ready to warn you if there's a problem.
If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the floor.
It may take longer to stop. If the light is still on, have the
vehicle towed for service. (See ªTowing Your Vehicleº
in the Index.)
CAUTION:
Your brake system may not be working properly
if the brake system warning light is on. Driving
with the brake system warning light on can lead
to an accident. If the light is still on after you've
pulled off the road and stopped carefully, have
the vehicle towed for service.
When the ignition is on, the brake system warning light
will also come on when you set your parking brake. The
light will stay on if your parking brake doesn't release
fully. If you try to drive off with the parking brake set, a
chime will also come on until you release the parking
brake. If the light stays on after your parking brake is
fully released, it means you have a brake problem.
If you have the optional Driver Information Center, a
PARK BRAKE SET message will be displayed while
the park brake is set.
