2000 PONTIAC BONNEVILLE display

3-35
REV (4): Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
EQ: Press EQ to select the desired preset equalization
setting while playing a compact disc. The equalization
will be automatically set whenever you play a
compact disc.
SEEK: Press the down arrow while playing a CD to go
to the start of the current track if more than eight
seconds have played. Press the up arrow to go to the
next track. If you hold the button or press it more than
once, the player will continue moving backward or
forward through the disc.
SCAN: Press and hold one of the SEEK arrows for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SCAN to listen to each
selection for a few seconds. The disc will go to the next
selection, stop for a few seconds, then go on to the next
selection. Press this button again to stop scanning. The
sound will mute while scanning. SCAN and the track
number will appear on the display.RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes. While elapsed time is showing, CD
TIME will appear on the display.
AM
-FM: Press this button to play the radio when a
disc is in the player.
CD
-TAPE: With a cassette tape in the player and the
radio playing, press this button to play a cassette tape.
Press AM
-FM to return to the radio when a cassette tape
is playing. Press CD
-TAPE to switch between the tape
and compact disc if both are loaded. The inactive tape or
CD will remain safely inside the radio for future
listening. The display will show TAPE and CD icons.
If you have the optional CD changer and the CD
changer is loaded, the CD
-TAPE button will activate
the changer and an icon will be lit in the display.
EJECT: Press this button to remove the disc. The
radio will play. EJECT may be activated with either the
ignition or radio off. CDs may be loaded with the radio
and ignition off if this button is pressed first.

3-38
All of the CD functions are controlled by the radio
buttons except for ejecting the magazine. Whenever a
CD magazine with discs is loaded in the changer and the
door is closed, the compact disc symbol will appear on
the radio display. If the CD changer is checking the
magazine for CDs, the compact disc symbol will flash
on the display until the changer is ready to play.
If CD changer mode is entered during initialization,
LOADING will appear on the display. When a CD
begins playing, a disc and track number will be
displayed. The disc numbers are listed on the front
of the magazine.
Compact Disc Changer Errors
If an error appears on the display, an error has occurred
and the compact disc temporarily cannot play.
NO CD'S is displayed when the CD changer cartridge
is empty. An empty magazine is inserted in the CD
changer. Try the magazine again with a disc loaded on
one of the trays.CHECK CD # could be displayed for the following:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched or wet.

The air is very humid. If so, wait about an hour and
try again.
CD DOOR OPEN is displayed when the CD changer
door is left open. Completely close the changer door to
restore normal operation.
If any error occurs repeatedly or if an error cannot be
corrected, please contact your dealer. If your radio
displays an error, write it down and provide it to your
dealer when reporting the problem.
Playing a Compact Disc
FWD (1): Press and hold this button to advance quickly
within a track. As the CD advances, elapsed time will be
displayed to help you find the correct passage.
PROG (2): Press this button to select the next disc in
the magazine. Each time you press PROG, the disc
number on the radio display will go to that of the next
available CD.

3-39
RDM (3): Press this button to enter the multi-disc
random play mode. RANDOM ALL will appear on the
display. The tracks on all the discs will play in random
order. Press and hold this button to enter the single
-disc
random play mode. RANDOM ONE will appear on
the display and a chime will sound. The tracks on the
current disc will play in random order. Press this button
again to turn off the random feature and return to
normal operation.
REV (4): Press and hold this button to reverse quickly
within a track. As the CD reverses, elapsed time will be
displayed with a flashing arrow to help you find the
correct passage.
(5): Press this button to select the previous disc in the
magazine. Each time you press this button, the disc
number on the radio display will go to that of the
previous available CD.
(6): No function when in CD changer mode.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes. While elapsed time is showing,
CD TIME will appear on the display.SEEK: Press the down arrow while playing a CD to go
to the start of the current track if more than eight
seconds have played. Press the up arrow to go to the
next track. If the button is pressed more than once, the
player will continue moving backward or forward
through the disc.
TRACK SCAN: Press and hold one of the SEEK
arrows for two seconds until TRACK SCAN appears on
the display and you hear a beep. You will hear the first
few seconds of each track on the current disc. The sound
will mute while scanning. The SCAN icon will be lit
and the ªTº will blink to indicate track scan mode.
Press SEEK again to stop TRACK SCAN.
DISC SCAN: Press and hold one of the SEEK arrows
for four seconds until DISC SCAN appears on the
display and you hear a double beep. You will hear the
first few seconds of track one on each disc. The sound
will mute while scanning. The SCAN icon will be lit
and the ªDº will blink to indicate disc scan mode.
Press SEEK again to stop DISC SCAN.

3-40
Theft-Deterrent Feature RDS Radios
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOCKED will be displayed.
With THEFTLOCK activated, your radio will not
operate if stolen.
Audio Steering Wheel Controls
(If Equipped)
If your vehicle has this feature, you can control certain
radio functions using the buttons on your steering wheel.
SEEK: Press the up or
down arrow to go to the
next higher or lower radio
station and stay there.
If a cassette tape is playing, press the up arrow to search
for the next selection on the tape. Press the down arrow
to search for the previous selection on the tape. Your
tape must have at least three seconds of silence between
each selection for SEEK to work. If a compact disc is
playing, press the up arrow to go to the start of the next
track. Press the down arrow to go to the start of the
current track if more than eight seconds have played.
If less than eight seconds have played, press the down
arrow to go to the previous track.

3-41
AM-FM: Press this button to select AM, FM1 or FM2.
The band you select will be displayed. The frequency
will also be displayed and, if the station is in stereo, the
stereo indicator will also be displayed. If a cassette tape
or compact disc is playing, the tape or disc will stop
playing and the radio will play.
PRESET: Press this button to hear the radio stations
that are set on your pushbuttons. If a cassette tape is
playing, press this button to play the other side of the
tape. If a compact disc is playing in the CD changer,
press this button to select the next loaded disc.
VOL: Press the up or
down arrow to increase
or decrease volume.PLAY: Press this button to play a cassette tape or
compact disc when the radio is playing.
MUTE: Press this button to silence the system. Press it
again, or any other radio button, to turn on the sound.
Understanding Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km). Tall
buildings or hills can interfere with FM signals, causing
the sound to come and go.

3-43 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLEAN
PLAYER to indicate that you have used your tape player
for 50 hours without resetting the tape clean timer. If
this message appears on the display, your cassette tape
player needs to be cleaned. It will still play tapes, but
you should clean it as soon as possible to prevent
damage to your tapes and player. If you notice a
reduction in sound quality, try a known good cassette to
see if it is the tape or the tape player at fault. If this other
cassette has no improvement in sound quality, clean the
tape player.
The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealership (GM Part No. 12344789).You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
After you clean the player, press and hold EJECT for
two seconds to reset the CLEAN PLAYER indicator.
The radio will display CLEANED to show the indicator
was reset.
Cassettes are subject to wear and the sound quality may
degrade over time. Always make sure the cassette tape
is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.

3-44 Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Diversity Antenna System
Your AM-FM antennas are located in the front
windshield and rear window. Be sure that the inside
surfaces of the front windshield and rear window are not
scratched and that the lines on the glass are not
damaged. If the inside surfaces are damaged, they could
interfere with radio reception.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid and affect your radio's
ability to pick up stations clearly. The repairs
wouldn't be covered by your warranty.
If, when you turn on your rear window defogger, you
hear static on your radio station, it could mean that a
defogger grid line has been damaged. If this is true, the
grid line must be repaired.
If you choose to add an aftermarket cellular telephone to
your vehicle, and the antenna needs to be attached to the
glass, be sure that you do not damage the grid lines for
the AM
-FM antennas or place the cellular telephone
antenna over the grid lines.
Chime Level Adjustment
The volume level of the vehicle's chimes can be
controlled by the radio. To change the volume level,
press and hold pushbutton six with the ignition on and
the radio power off. The chime volume level will change
from the normal level to loud, and LOUD will be
displayed on the radio. To change back to the default or
normal setting, press and hold pushbutton six again.
The chime level will change from the loud level to
normal, and NORMAL will be displayed.

6-15
If none of them is true, use the long trip/highway
maintenance schedule. Change the oil and filter every
7,500 miles (12 500 km) or 12 months
-- whichever
occurs first. Driving a vehicle with a fully warmed
engine under highway conditions causes engine oil to
break down slower.
When to Change Engine Oil (Vehicles With
the GM Oil Life System
Option)
If so equipped, your vehicle has a computer that lets you
know when to change your engine oil. This is not based
on mileage, but on engine revolutions and engine
operating temperature. When the computer has
calculated that the oil needs changing, the GM Oil Life
System
will indicate that a change is necessary.
The mileage between oil and filter changes will vary
depending on how you drive your vehicle
-- usually
between 3,000 miles (5 000 km) and 7,500 miles
(12 500 km) since your last oil and filter change.
Under severe conditions, the system may come on
before 3,000 miles (5 000 km). Never drive your vehicle
more than 7,500 miles (12 500 km) or 12 months
(whichever occurs first) without an oil change.
The system won't detect dust in the oil. So, if you drive
in a dusty area, be sure to change your oil and filter
every 3,000 miles (5 000 km) or sooner. Remember to
reset the Oil Life System whenever the oil is changed.How to Reset the Oil Life System (If Equipped)
Always reset the engine oil life to 100% after every oil
change. It will not reset itself. To reset the Oil Life
System, press and hold the RESET button for more than
five seconds while the OIL LIFE is being displayed on
the DIC. The oil life will change to 100%.
What to Do with Used Oil
Did you know that used engine oil contains certain
elements that may be unhealthy for your skin and could
even cause cancer? Don't let used oil stay on your skin
for very long. Clean your skin and nails with soap and
water, or a good hand cleaner. Wash or properly throw
away clothing or rags containing used engine oil.
(See the manufacturer's warnings about the use and
disposal of oil products.)
Used oil can be a real threat to the environment. If you
change your own oil, be sure to drain all free
-flowing oil
from the filter before disposal. Don't ever dispose of oil
by putting it in the trash, pouring it on the ground,
into sewers, or into streams or bodies of water. Instead,
recycle it by taking it to a place that collects used oil.
If you have a problem properly disposing of your used
oil, ask your dealer, a service station or a local recycling
center for help.
