2000 PONTIAC BONNEVILLE keyless entry

2-12
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through the
DIC. See ªDriver Information Center Personalization
Programmingº in the Index.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have only four transmitters
matched to it.
See your dealer to match additional transmitters to
your vehicle.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to touch any
of the circuitry. Static from your body transferred to
these surfaces may damage the transmitter.

2-13
For battery replacement, use one Duracell
battery,
type DL
-2032, or a similar type.
To replace the battery:
1. Insert a coin into the notch near the key ring. Turn
the coin counterclockwise to separate the two halves
of the transmitter.
2. Once the transmitter is separated, use a pencil eraser
to remove the old battery. Do not use a metal object.
3. Remove and replace the battery. Replace it as the
instructions inside the cover indicate.4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Test the operation of the transmitter with your
vehicle. If the transmitter does not work,
resynchronize the transmitter. See
ªResychronizationº following.
Resynchronization
Pressing the transmitter button numerous times
(approximately 250 times) out of the vehicle's operating
range may cause the transmitter not to work. Replacing
the battery and pressing the transmitter buttons out of
range will also cause the transmitter not to work. If only
the instant alarm works, the transmitter needs to be
resynchronized to the receiver. To resynchronize the
remote keyless entry transmitter, press and hold both the
button with the lock symbol and the button with the
unlock symbol at the same time for about eight seconds.
You must be within range of the vehicle.
Once the transmitter has been resynchronized, the locks
will cycle (the horn may chirp and the exterior lamps
may flash depending on security feedback settings).
The system should now operate properly.

2-14
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on OUTSIDE AIR or with RECIRC turned
off. That will force outside air into your
vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
To unlock the trunk from the outside, insert the master
key and turn it.
Remote Trunk Release (Option)
If you have this option,
press the trunk release
button located in the glove
box to open the trunk lid.
The key does not have to be in the ignition for the
remote trunk button to work. The transaxle must be in
PARK (P) or NEUTRAL (N). The system also works
with the remote keyless entry system, if your vehicle has
this feature.

2-15 Remote Trunk Release Lockout (Option)
To secure items in the trunk, lock the glove box with the
master key and take your key and remote keyless entry
transmitter with you. The gray valet key cannot open the
trunk or the glovebox.
Trunk Security Override (Option)
Pressing the trunk symbol on the remote keyless entry
transmitter opens the trunk even if the glove box is locked.
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make it
impossible to steal. However, there are ways you can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
With the ignition off and the driver's door open, you'll
hear a tone reminding you to remove your key from the
ignition and take it with you. Always do this. Your
ignition and transaxle will be locked. And remember to
lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key?

If possible, park in a busy, well lit area.

Put your valuables in a storage area, like your trunk
or glove box. Be sure to close and lock the
storage area.

Close all windows.

Lock the glove box.

Lock all doors except the driver's.

Give the valet key to the valet. Then take the master
key with you.

2-16
Universal Theft-Deterrent (Option)
If your vehicle has this option, it has a theft-deterrent
alarm system. With this system, the SECURITY light
will flash as you open the door (if your ignition is
in OFF).
This light on the instrument
panel cluster reminds you to
activate the theft
-deterrent
system when leaving
your vehicle.
To activate the system:
1. Open the door.
2. Lock the door with the power door lock switch while
the door is open, or use the remote keyless entry
transmitter. The SECURITY light should come on
and stay on.
3. Close all doors. The SECURITY light should go off
after about 30 seconds and the system will then
be armed.If the SECURITY light comes on for one minute and
then shuts off while the ignition is on, the security system
has detected a problem. See your dealer for service.
Once the theft system is armed, the THEFT light on the
Twilight Sentinel

dimmer switch will flash to indicate
the system is armed.
If a door is opened without the key or remote keyless
entry transmitter, or if the door key cylinders are
damaged, the alarm will go off. The exterior lamps will
flash and the horn will sound for 30 seconds, then will
go off in order to save battery power.
Remember, the theft
-deterrent system won't activate if
you lock the doors with a key or manual door lock. It
activates only if you use a power door lock switch while
the door is open, or the remote keyless entry transmitter.
Avoid setting off the alarm by accident.
Always unlock a door with a key, or use the remote
keyless entry system transmitter. Unlocking a door any
other way will set off the alarm.
If you set off the alarm by accident, unlock any door
with your key. You can also turn off the alarm by
pressing the button with the unlock symbol on the
remote keyless entry transmitter. The alarm won't stop
if you try to unlock a door any other way.

2-17 Testing the Alarm
1. From inside the vehicle, roll down the window.
2. Activate the system by locking the doors with the
power door lock switch while the door is open, or
with the remote keyless entry transmitter.
3. Get out of the vehicle, close the door and wait for the
SECURITY light to go out.
4. Then, reach in through the window, unlock the door
with the manual door lock and open the door.
This should set off the alarm.
If the alarm does not sound when it should, check to
see if the horn works. The horn fuse may be blown.
To replace the fuse, see ªFuses and Circuit Breakersº
in the Index.
If the alarm does not sound, or the exterior lamps do not
flash, see your dealer.
PASS-Key
III
Your vehicle is equipped
with the PASS
-Key III
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key III is a passive
theft
-deterrent system.
This means you don't have to do anything different to
arm or disarm the system. It works when you insert or
remove the key from the ignition.
Your PASS
-Key III system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.

2-43
At night, you can turn off all exterior lamps when you
are in PARK (P) by turning the Twilight Sentinel knob
all the way to OFF. If the knob was already in OFF, it
must be cycled to ON then back to OFF, to turn the
exterior lighting off. The lamps will come back on when
you turn the knob clockwise.
If the Twilight Sentinel lighting is active, it can be
disabled by turning on the manual parking lamps. This
lighting will be disabled until the key is turned from
RUN or until the manual park lamps are turned OFF.
Also, it's possible that your headlamps may go out if
you drive from a dark area into a bright area like a
lighted parking lot. If this happens, turn on your
headlamps with the regular headlamp switch.
Exterior Lighting Battery Saver
If the manual lamp control has been left on, the exterior
lamps will turn off approximately 10 minutes after the
ignition is turned to OFF and any door has been opened.
This protects against draining the battery in case you
have accidentally left the headlamps or parking lamps
on. If you need to leave the lamps on for more than
10 minutes, use the manual control to turn the lamps
back on after turning the ignition to OFF and opening
any door. To delay the lamps from turning off,
see ªTwilight Sentinel

º in the Index.
Interior Lamps
Instrument Panel/Brightness Control
When it is dark outside, you can brighten or dim your
instrument panel cluster lights by turning the DIM knob in
the light control. Turn the knob clockwise to brighten the
instrument panel cluster lights and displays. Turn the knob
clockwise all the way to turn on the interior courtesy lamps.
Turn the knob counterclockwise to dim the instrument panel
cluster lights and displays and to turn off the courtesy lamps.
Courtesy Lamps
If it is dark enough outside, when any door is opened,
several lamps will come on. They make it easier for you
to enter and leave the vehicle. Turn the dimmer knob all
the way clockwise to turn the interior courtesy lamps on.
Illuminated Entry
If it is dark enough outside and you press the button with
the unlock symbol on the remote keyless entry transmitter,
the interior courtesy lamps will come on and stay on for
approximately 40 seconds. The lamps will turn off
immediately by pressing the button with the lock symbol
on the remote keyless entry transmitter, turning the ignition
key to RUN or activating the power door locks.
If a door is left ajar, your interior lamps will turn off
after 10 minutes to save your battery.

2-44
Delayed Entry Lighting
When you open the door to enter your vehicle, the
interior lamps will come on if it is dark outside. When
you close the door with the ignition off, the interior
lamps will stay on for 25 seconds or until the ignition is
turned on. Please note that locking the doors with the
power door lock switch, or with the lock button on the
remote keyless entry transmitter, will override the
delayed entry lighting and the lamps will turn
off immediately.
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate turn off after
you remove the key from the ignition.
Delayed Exit Lighting
This feature will turn on the interior lamps for
25 seconds after you remove the key from the ignition
while the doors are closed and it is night. This will give
you time to find the door handle or lock switches as
you exit the vehicle.
This lighting will only be deactivated if the key is
reinserted into the ignition switch or the power door
locks are activated.
Parade Dimming
To activate the instrument panel backlighting during the
day, turn the headlamp switch to the parking lamp or
headlamp position. Dimming of the instrument panel
display is not possible during daylight hours. The
instrument panel display can only be adjusted when the
parking lamps or headlamps are on and it is dark outside.
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter is pressed, the DRL headlamps,
parking lamps and back
-up lamps will turn on if it is
dark enough outside.
Personalization Programming
This feature can be programmed in the on or off mode for
each transmitter. Vehicles are delivered with this feature on.
To turn the feature off:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains on at this time and the horn will
chirp twice.
