2000 PONTIAC BONNEVILLE keyless entry

Table of Contents
Keys and Door Locks
Remote Keyless Entry System (If Equipped)
Trunk Release
Automatic Transaxle
Parking Brake
Windows
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield Wipers
Cruise Control
Interior and Exterior LampsMirrors
Storage Compartments
Convenience Net (Option)
Accessory Power Outlet
Sunroof (Option)
HomeLink® Transmitter (If Equipped)
Instrument Panel, Warning Lights and Gages
Head-Up Display (Option)
Driver Information Center (Option)
Memory and Personalization Seats and Seat Controls
Safety BeltsAir Bag Systems
Child Restraints
Section
1
Section
2
Seats and Restraint Systems
Features and Controls
ii

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-9 Remote Keyless Entry (If Equipped)
2
-14 Trunk
2
-15 Theft
2
-16 Universal Theft-Deterrent (Option)
2
-17 PASS-Key
III
2
-19 New Vehicle ªBreak-Inº
2
-20 Ignition Positions
2
-21 Starting Your Engine
2
-22 Engine Coolant Heater (If Equipped)
2
-23 Automatic Transaxle Operation
2
-26 Parking Brake
2
-27 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)
2
-31 Parking Over Things That Burn
2
-31 Engine Exhaust2
-32 Running Your Engine While You're Parked
2
-33 Windows
2
-33 Horn
2
-34 Tilt Wheel
2
-34 Turn Signal/Multifunction Lever
2
-41 Exterior Lamps
2
-43 Interior Lamps
2
-47 Mirrors
2
-50 Storage Compartments
2
-51 Sun Visors
2
-52 Air Inflator System (Option)
2
-54 Express Sunroof (Option)
2
-58 The Instrument Panel -- Your
Information System
2
-64 Warning Lights, Gages and Indicators
2
-79 Head-Up Display (Option)
2
-84 Driver Information Center (DIC) (Option)

2-4
Door Locks
CAUTION:
Unlocked doors can be dangerous.
Passengers -- especially children -- can easily
open the doors and fall out. When a door is
locked, the inside handle won't open it.
Outsiders can easily enter through an unlocked
door when you slow down or stop your vehicle.
This may not be so obvious: You increase the
chance of being thrown out of the vehicle in a
crash if the doors aren't locked. Wear safety belts
properly, lock your doors, and you will be far
better off whenever you drive your vehicle.
There are several ways to lock and unlock your vehicle.
From the outside, use your key or remote keyless entry
transmitter, if your vehicle has this feature. With your
door key, turning the key toward the rear of the vehicle
will unlock the door and turning the key toward the
front of the vehicle will lock it.If your vehicle has a theft
-deterrent system and it is
activated, unlock the doors only with the key or remote
keyless entry system. This will avoid setting off the
alarm. See ªUniversal Theft
-Deterrentº in the Index for
more information.
To lock the door from the inside, push the manual
locking lever forward. To unlock the door, push the
manual locking lever rearward.

2-6
Mode 3: All doors automatically lock when shifted
out of PARK (P). All doors automatically unlock when
shifted into PARK (P).
Mode 4: All doors automatically lock when shifted out of
PARK (P). Only the driver's door automatically unlocks
when the key is turned to OFF. (DIC equipped vehicles only)
Mode 5: All doors automatically lock when shifted out
of PARK (P). All doors automatically unlock when the
key is turned to OFF. (DIC equipped vehicles only)
Vehicles are delivered programmed in Mode 3.
If your vehicle is not equipped with remote keyless
entry, use the following procedure to change modes:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 3.
3. Cycle the shift lever, starting in PARK (P), out of
PARK (P) and then back into PARK (P), to advance
by one mode for each cycle.
After the first cycle, you will hear a door locking
action, which identifies the current mode.
4. Release the power door lock switch. The automatic door
locks will remain in the most recent mode selected.If your vehicle is equipped with remote keyless entry,
use the following procedure to change modes:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 4.
3. Press the button with the lock symbol on the remote
keyless entry transmitter. The automatic door locks
will remain in the current mode.
4. Press the button with the lock symbol on the
transmitter again. Each time the transmitter's lock
button is pressed, the mode will advance by one,
going from 3 to 0 to 1, etc.
The door locks will cycle according to the mode
entered. (Mode ª0º has no feedback.)
5. Release the power door lock switch. The automatic door
locks will remain in the most recent mode selected.
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through the
DIC. See ªDriver Information Center Personalization
Programmingº in the Index.

2-7 Delayed Locking
This feature lets the driver delay the actual locking of the
vehicle. When the driver's power door lock switch or the
remote keyless entry lock button is pressed, with the key
removed from the ignition and the driver's door open, a
chime will sound three times to signal that the delayed
locking system is active. When all doors have been closed,
the doors will lock automatically after five seconds. If any
door is opened before this, the five
-second timer will reset
itself once all the doors have been closed again.
Pressing the driver's/passenger's door lock switch or the
remote keyless entry lock button again will override
this feature.
Personalization Programming
The delayed locking feature can be turned on or off.
Vehicles are delivered with delayed locking off.
If your vehicle is not equipped with remote keyless
entry, the delayed locking feature can be turned on or off
by using the following procedure:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 4.3. Cycle the park lamp switch from off to on six times.
On the sixth cycle, the doors will unlock to confirm
that the feature has been turned on. Your doors will
remain locked if delayed locking is off.
4. To change modes, cycle the park lamp switch once
more. A locking action will confirm the new mode.
5. Release the power door lock switch.
To turn the feature off, repeat the previous procedure.
If your vehicle is equipped with remote keyless entry,
your vehicle can be programmed to each driver's
preference for each of the transmitters. Use the
following procedure to turn the feature off using the
corresponding transmitter:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the power door lock switch in the
LOCK position throughout this procedure. All the
doors will lock.
3. Press the button with the unlock symbol on the
transmitter. The lock delay is still on and all the
doors will unlock.
4. Press the button with the unlock symbol on the
transmitter again. Lock delay is now off and all the
doors will lock.
5. Release the power door lock switch.

2-9 Leaving Your Vehicle
If you are leaving the vehicle, take your keys, open your
door and set the locks from the inside. Then get out and
close the door. You may also use the lock button on the
remote keyless entry transmitter after shutting the doors.
If your vehicle has a theft
-deterrent system, see
ªUniversal Theft
-Deterrentº in the Index.
Remote Keyless Entry (If Equipped)
If your vehicle has this feature, you can lock and unlock
your doors or unlock your trunk from about 3 feet (1 m)
up to 30 feet (9 m) away using the remote keyless entry
transmitter supplied with your vehicle.
Your remote keyless entry system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation of the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.

If you're still having trouble, see your dealer or a
qualified technician for service.

2-10
Operation
The driver's door will
unlock and the exterior
lamps may flash twice
when the button with
the unlock symbol
is pressed.
The fuel door will also unlock when unlock is pressed,
if you have the optional fuel door lock.
If the button with the unlock symbol is pressed again
within five seconds, all doors will unlock. Pressing the
unlock button will also illuminate the interior lamps.
See ªIlluminated Entryº and ªSecurity Feedbackº
in the Index.All doors will lock, the exterior lamps may flash once
and the horn may chirp when the button with the lock
symbol is pressed. See ªSecurity Feedbackº in the
Index. Pressing the lock button may also turn off the
interior lamps if illuminated.
The trunk will unlock when the trunk symbol is pressed
when the ignition is in OFF. The trunk symbol will
also work when the ignition is on, but only while in
PARK (P) or NEUTRAL (N).
Instant Alarm
When the button with the horn symbol on the remote
keyless entry transmitter is pressed, the horn will sound
and the headlamps and taillamps will flash for up to
30 seconds. This can be turned off by pressing the
instant alarm button again or by turning the ignition to
ON. If your vehicle is equipped with the Universal
Theft
-Deterrent feature, you may also turn off the alarm
by unlocking the vehicle with a key. See ªUniversal
Theft
-Deterrentº in the Index.

2-11
Personalization Features
The following list of features that are available on your
vehicle can be programmed to each driver's preference
for each of the remote keyless entry transmitters:

Programmable Automatic Door Locks

Security Feedback

Delayed Locking

Perimeter Lighting

Seat and Mirror Recall
For more detailed information and programming
instructions, refer to the Index for each individual
feature listed above.
Security Feedback
This provides feedback to the driver when the vehicle
receives a command from the remote keyless entry
transmitter. The following modes may be selected:

Mode 1: No feedback when locking or
unlocking vehicle.

Mode 2: Parking lamps and the daytime running
lamps will flash twice when unlocking the vehicle
and flash once when locking the vehicle.
Mode 3: Horn chirps when all doors are unlocked
(second unlock button press) and when locking
the vehicle.

Mode 4: Parking lamps and the daytime running
lamps will flash twice each time the button with the
unlock symbol is pressed; the horn chirps when all
doors are unlocked. Parking lamps and the exterior
lamps flash once and the horn chirps when locking
the vehicle.
Vehicles are delivered programmed in Mode 2. To change
to another mode:
1. Keep all doors closed, vehicle in PARK (P) and the
ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
the LOCK position through Step 4.
3. Press the button with the trunk symbol on the transmitter.
The transmitter will remain in its current mode.
4. Press the button with the trunk symbol again. Each
time the transmitter's trunk button is pressed, the
mode will advance by one, going from Mode 2 to 3
to 4, etc. and the horn will chirp as feedback.
5. Release the power door lock switch. The security
feedback will remain in the most recent mode selected.
