F01852
F01848Matchmarks
SR±16± STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2186 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
8. INSTALL COLUMN UPPER BRACKET
(a) Install the column upper bracket with 2 new tapered±
head bolts.
(b) Tighter the 2 tapered±head bolts until the bolt heads
break off.
9. INSTALL NO.2 INTERMEDIATE SHAFT ASSEMBLY
(a) Align the matchmarks on the No.2 shaft and main shaft.
(b) Install the bolt.
Torque: 35 N´m (360 kgf´cm, 26 ft´lbf)
10. INSTALL KEY CYLINDER ILLUMINATION
11. INSTALL TRANSPONDER KEY COIL
Install the transponder key coil with the screw.
F09281
No.2 Intermediate Shaft
Assembly
Tilt and Telescopic ECUNo.2 BracketSteering Column
Protector
No.1 Bracket Column Tube SupportIgnition Switch Tapered±Head Bolt
Tilt Steering Gear
Assembly with MotorTurn Signal
Bracket Key Interlock
SolenoidKey Unlock Warning
Switch
Key Cylinder
Illumination
Key Cylinder
35 (360, 26)
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
20 (204, 15)
Tube Attachment
Column Upper
BracketTransponder Key coil
Transponder Key
Amplifier
Plate
Tilt Slider
Assembly23 (230, 17)
Bushing
23 (230, 17)
Plate
Bushing
Washer
Washer
SR±10± STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2180 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
