1999 TOYOTA TERCEL Owners Manual

'99 TERCEL (U)
192
Fuel
Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 45 (11.9, 9.9) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.31Ð0.41 (0.012Ð0.016)
Spark plug type: DENSO K16TR11
NGK BKR5EKB11
Spark plug gap, mm (in.): 1.1 (0.043)
Drive belt tension measured with Borroughs
drive belt tension gauge No.BT- 33- 73F
(used belt), Ibf: 100 20
ENGINE LUBRICATION
Oil capacity (drain and refill), L (qt., Imp. qt.):
With filter 2.8 (3.0, 2.5)
Without filter 2.6 (2.7, 2.3)
Oil grade: API grade SJ, ºEnergy- Conservingº or
ILSAC multigrade engine oil is recom-
mended. Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Automatic transmission Vehicles sold in Puerto Rico
4.8 (5.1, 4.2)
Vehicles sold outside Puerto Rico 5.3 (5.6, 4.7)
Manual transmission 4.9 (5.2, 4.3)
Coolant type: ºToyota Long Life Coolantº or equivalent
With ethylene- glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.

'99 TERCEL (U)193
BATTERY

Maintenance type battery
Specific gravity reading at 20 C(68 F):
1.250Ð1.290 Fully charged
1.160Ð1.200 Half charged
1.060Ð1.100 Discharged

Non−maintenance battery Open voltage *
at 20 C (68 F):
12.6 VÐ12.8 V Fully charged
12.2 VÐ12.4 V Half charged
11.8 VÐ12.0 V Discharged
* : Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off
Charging rates:
Non−maintenance battery 5 A max .
Maintenance type battery Quick charge 15 A max.
Slow charge 5 A max.
CLUTCH
Pedal freeplay, mm (in.): 5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3 MANUAL TRANSAXLE
Oil capacity, L (qt., Imp. qt.):
1.9 (2.0, 1.7)
Oil type: Gear oil API GL- 4 or GL- 5
Recommended oil viscosity: SAE 75W- 90
AUTOMATIC TRANSAXLE
3- speed type automatic transmission Automatic transmission Fluid capacity (drain and ref ill),
L (qt., Imp. qt.):
Up to 2.5 (2.6, 2.2)
Differential Fluid capacity, L (qt., Imp. qt.): 1.4 (1.5, 1.2)
4- speed type automatic transmission Fluid capacity (drain and ref ill),
L (qt., Imp. qt.): Up to 3.1 (3.3, 2.7)
Fluid type: Automatic transmission fluid D- II or DEXRON III (DEXRON II) BRAKES
Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.):
With anti- lock brake system 55 (2.2)
Without anti- lock brake system 60 (2.4)
Pedal freeplay, mm (in.): 1Ð6 (0.04Ð0.24)
Pad wear limit, in. (mm): 1.0 (0.04)
Lining wear limit, in. (mm): 1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf): 5Ð8 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel freeplay: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II or III

'99 TERCEL (U)
194
Tires
Tire size:
Spare tire T115/70D14 88M
T105/70D14 83M
Except spare tire 155SR13 (155/80R 79S)
P185/60R14 82H
P175/65R14 81S
Tire pressure, kPa (kgf/cm 2
or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire 155SR13 (155/80R 79S) Front 240 (2.4, 34)
Rear 220 (2.2, 32)
P185/60R14 82H
180 (1.8, 26)
P175/65R14 81S 200 (2.0, 28)
Wheel size: Spare tire 14 4T
Except spare tire 155 SR13 13 4 1/2J
P185/60R14 82H 14 5 1/2J
P175/65R14 81S 14 5 1/2J
Wheel nut torque, N´m (kgf´m, ft´lbf):
103 (10.5, 76) Fuses
Engine compartment (U.S.A.)
Fuses (type A) 1. HEAD (LH) 10 A: Left- hand headlight
2. HEAD (RH) 10 A: Right- hand headlight
3. AM2 15 A: Ignition system, charging
system, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, seat belt
pretensioners, starter system
4. HAZ- HORN 15 A: Horns, emergency
flashers, theft deterrent system
5. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
systemEngine compartment (Canada)
6. DOME 10 A: Interior lights, open door
warning light, clock, car audio system,
theft deterrent system, daytime running
light system
7. OBD- II 7.5 A: On- board diagnosis sys-
tem
8. ALT- S 5 A: Charging system
9. DRL 5 A: Daytime running light system
10. HEAD (RH- LWR) 10 A: Right- hand
headlight (low beam)
11. HEAD (LH- LWR) 10 A: Left- hand
headlight (low beam)
12. HEAD (RH- UPR) 10 A: Right- hand
headlight (high beam)

'99 TERCEL (U)195
Engine compartment (Canada only)
13. HEAD (LH- UPR) 10 A: Left- hand
headlight (high beam)
14. STOP 10 A: Stop lights, high mounted
stoplight, anti- lock brake system, shift
lock control system
15. A/C 10 A: Air conditioning system
16. TAIL 15 A: Tail lights, parking lights,
license plate lights, instrument panel
lights, air conditioning system, emer-
gency flashers, air conditioning system,
rear window defogger, car audio sys-
tem, cigarette lighter, clockInstrument panel
17. GAUGE 10 A: Gauge and meters, ser-
vice reminder indicator (except head-
light high beam indicator) and warning
buzzers (except discharge, open door
and SRS warning lights), back- up
lights, rear window defogger, power
windows
18. TURN 7.5 A: Turn signal lights
19. WIPER 20 A: Windshield wipers and
washer
20. ECU- IG 5 A: Anti- lock brake system,
air conditioning system, shift lock con-
trol system, daytime running light sys-
temInstrument panel
21. CIG&RADIO 15 A: Cigarette lighter,
car audio system, clock, theft deterrent
system, shift lock control system, SRS
airbag system, seat belt pretensioners
22. IGN 5 A: Charging system, discharge
warning light, multiport fuel injection
system/s equential multiport fuel injec-
tion system, SRS airbag system, seat
belt pretensioners
23. ECU- B 5 A: SRS airbag warning light
Fuses (type B)
24. CDS FAN 30 A: Electric cooling fans
25. RAD FAN 30 A: Electric cooling fans

'99 TERCEL (U)
196
26. HEATER 40 A:
Air conditioning system,
``A/C'' fuses
27. DIMMER 30 A: ºHEAD RL (LWR)º,
ºHEAD LL (LWR)º, ºHEAD RH (UPR)º
and ºHEAD LH (UPR)º fuses
28. MAIN 30 A: Starter system
29. DEF 30 A: Rear window defogger
30. PWR 30 A: Power windows, power
door lock system
Fuses (type C)
31. ABS 60 A: Anti- lock brake system
32. AM1 50 A: ºDEFº, ºWIPERº, ºGAUGEº,
ºECU- IGº, ºTURNº, ºIGNº, ºPWRº and
ºCIG&RADIOº fuses
33. ALT 100 A: ºABSº, ºSTOPº, ºTAILº,
ºECU- Bº, ºDEFº, ºAM1º, ºWIPERº,
ºGAUGEº, ºECU- IGº, ºTURNº, ºPWRº
and ºCIG&RADIOº fuses

'99 TERCEL (U)197
Part 9
REPORTING SAFETY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for U.S.
owners
Uniform tire quality grading
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc.
(Toll- free: 1- 800- 331- 4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either
call the Auto Safety Hotline toll- free
at 1- 800- 424- 9393 (or 366- 0123 in
Washington, D.C. area) or write to:
NHTSA. U.S. Department of Trans-
portation. Washington, D.C. 20590.
You can also obtain other information
about motor vehicle safety from the
Hotline.
Reporting safety defects
for U.S. owners

'99 TERCEL (U)
198
Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesÐAll passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. These quality grades are
molded on the sidewall.
TreadwearÐ
The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1- 1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate. Traction AA, A, B, CÐ
The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire's
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straighta-
head) traction tests and does not include
cornering (turning) traction.
Temperature A, B, CÐ The temperature
grades are A (the highest), B, and C,
representing the tire's resistance to the
generation of heat and its ab ility to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law. Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.

'99 TERCEL (U)
ii
New vehicle warranty
Your new vehicle is covered by the following Toyota
limited warranties: New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the separate
ºOwner 's Warranty Information Bookletº or ºOwner 's
Manual Supplementº.
Your responsibility for maintenance
It is owner 's responsib ility to make sure that the speci-
fied maintenance is performed. Part 6 gives details of
these maintenance requirements. Also included in Part 6
is general maintenance. For scheduled maintenance in-
formation, place refer to the separate ºScheduled Main-
tenance Guideº or ºOwner 's Manual Supplementº.
Accessories, spare parts and
modification of your Toyota
A wide variety of non- genuine spare parts and accesso-
ries for Toyota vehicles are currently available in the
market. You should know that Toyota does not warrant
these products and is not responsible either for their
performance, repair or replacement, or for any damage
they may cause to, or adverse effect they may have on,
your Toyota vehicle.
This vehicle should not be modified with non- genuine
Toyota products. Modification with non- genuine Toyota
products could affect its performance, safety or durabili-
ty, and may even violate governmental regulations. In
addition, damage or performance problems resulting from
the modification may not be covered under warranty.
Important Information About Your Toyota
