Fuse Description
30 Alt Sense
31 Torque Converter Clutch (TCC)
32 Fuel Pump
33 Electronic Control
Module/Powertrain Control
Module
34 Spare
35 Fog Lamps
36 Horn
37 Chime/Mall Module, Taillamps,
Parking Lamps, Sidemarker
Lamps, Dimmable Lamps
38 Spare Fuse
39 Fog Lamps
40 Spare
Air Conditioning Clutch Diode Relay Description
9 Cooling Fan
10 Cooling Fan 2
11 Ignition Main
12 Cooling Fan 1
13 Air Conditioning Clutch
14 Fuel Pump
15 Fuel Pump Speed Cont
16 Horn
17 Fog Lamp

yellowblue
6-66
Replacement Bulbs
Exterior Lamps Bulb Number. . . . . . . . . . . . . . . . .
Back
-Up 3156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 1141. . . . . . . . . . . . . . . .
Front Parking/Turn Signal 3357 NAK. . . . . . . . . . . . .
Headlamps High/Low Beam 9007. . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Front Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
Automatic Transaxle with Overdrive
Pan Removal and Replacement 8.0 quarts (7.5 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
*When draining/replacing converter or auxiliary
cooler, more fluid may be needed.Cooling System Including Reservoir
3100 (Code M) 11.0 quarts (10.42 L). . . . . . . . . . . . . .
3800 (Code K) 12.3 quarts (11.7 L). . . . . . . . . . . . . . .
3800 Supercharged (Code 1) 12.3 quarts (11.7 L). . . .
Refrigerant (R
-134a),
Air Conditioning*1.9 lbs. (0.85 kg) . . . . . . . . . . . .
Engine Crankcase (Oil Change with Filter Change)
3100 (Code M) 4.5 quarts (4.3 L). . . . . . . . . . . . . . . .
3800 (Code K) 4.5 quarts (4.3 L). . . . . . . . . . . . . . . .
3800 Supercharged (Code 1) 4.5 quarts (4.3 L). . . . .
Fuel Tank17.7 gallons (67 L) . . . . . . . . . . . . . . . . . .
*See ªAir Conditioning Refrigerantsº later in
this section.
Note: All capacities are approximate. When adding
fluid, be sure to fill to the appropriate level, as
recommended in this manual. Recheck fluid level after
filling. See ªRecommended Fluids and Lubricantsº in
the Index for more information.

yellowblue
6-67 3100 (Code M) Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID (3.1L L82). . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower 160. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3800 (Code K) Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 231 CID (3.8L L36). . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3800 Supercharged (Code 1)
Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 231 CID (3.8L L67). . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower 240. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
6-68
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
All Engines z4508572 or A1096C. . . . . . . . . . . . . . . .
Battery
3100 (Code M) 600 CCA. . . . . . . . . . . . . . . . . . . . . . .
3800 (Code K) 690 CCA. . . . . . . . . . . . . . . . . . . . . . .
3800 Supercharged (Code 1) 770 CCA. . . . . . . . . . . .
Engine Oil Filter
All Engines AC Type PF47. . . . . . . . . . . . . . . . . . . . .
PCV Valve
All Engines CV892C. . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Cap
All Engines AC Type RC27. . . . . . . . . . . . . . . . . . . . . Spark Plugs
3100 (Code M) AC Type 41
-940 . . . . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
3800 (Code K) AC Type 41
-921 . . . . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
3800 Supercharged
(Code 1) AC Type 41
-921 or NGK . . . . . . . . . . . .
Type PTR4B
-15
Gap: 0.060 inches (1.52 cm)
Wiper Blades
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 20 inches (50.8 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 110.5 inches (280.7 cm). . . . . . . . . . . . . .
Tread Width
Front 62.0 inches (157.5 cm). . . . . . . . . . . . . . . . . .
Rear 61.5 inches (156.1 cm). . . . . . . . . . . . . . . . . . .
Length 196.5 inches (499.1 cm). . . . . . . . . . . . . . . . .
Width 72.7 inches (184.5 cm). . . . . . . . . . . . . . . . . . .
Height 54.7 inches (139.0 cm). . . . . . . . . . . . . . . . . . .

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How this Section is Organized
7
-3 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance7
-14 Part B: Owner Checks and Services
7
-18 Part C: Periodic Maintenance Inspections
7
-20 Part D: Recommended Fluids and Lubricants
7
-22 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.

yellowblue
7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you are skilled enough to do some work on your
vehicle, you will probably want to get the service
information. See ªService and Owner Publicationsº in
the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains what
you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº
explains important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº
lists some recommended products to help keep your
vehicle properly maintained. These products, or their
equivalents, should be used whether you do the work
yourself or have it done.
ªPart E: Maintenance Recordº provides a place
for you to record the maintenance performed on your
vehicle. Whenever any maintenance is performed, be
sure to write it down in this part. This will help you
determine when your next maintenance should be done.
In addition, it is a good idea to keep your maintenance
receipts. They may be needed to qualify your vehicle for
warranty repairs.

yellowblue
7-4
Part A: Scheduled Maintenance
