Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
All Engines z4508572 or A1096C. . . . . . . . . . . . . . . .
Battery
3100 (Code M) 600 CCA. . . . . . . . . . . . . . . . . . . . . . .
3800 (Code K) 690 CCA. . . . . . . . . . . . . . . . . . . . . . .
3800 Supercharged (Code 1) 770 CCA. . . . . . . . . . . .
Engine Oil Filter
All Engines AC Type PF47. . . . . . . . . . . . . . . . . . . . .
PCV Valve
All Engines CV892C. . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Cap
All Engines AC Type RC27. . . . . . . . . . . . . . . . . . . . . Spark Plugs
3100 (Code M) AC Type 41
-940 . . . . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
3800 (Code K) AC Type 41
-921 . . . . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
3800 Supercharged
(Code 1) AC Type 41
-921 or NGK . . . . . . . . . . . .
Type PTR4B
-15
Gap: 0.060 inches (1.52 cm)
Wiper Blades
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 20 inches (50.8 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 110.5 inches (280.7 cm). . . . . . . . . . . . . .
Tread Width
Front 62.0 inches (157.5 cm). . . . . . . . . . . . . . . . . .
Rear 61.5 inches (156.1 cm). . . . . . . . . . . . . . . . . . .
Length 196.5 inches (499.1 cm). . . . . . . . . . . . . . . . .
Width 72.7 inches (184.5 cm). . . . . . . . . . . . . . . . . . .
Height 54.7 inches (139.0 cm). . . . . . . . . . . . . . . . . . .
Scheduled Maintenance
yellowblue
7-12
97,500 Miles (162 500 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
100,000 Miles (166 000 km)
Inspect spark plug wires.
An Emission Control Service.
Replace spark plugs.
An Emission Control Service.
Change automatic transaxle fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches 90F
(32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you haven't used your vehicle under severe service conditions listed
previously and, therefore, haven't changed your automatic transaxle fluid,
change both the fluid and filter.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
