4. Allow the belt to retract. Pull up on the
shoulder belt to remove any slack in the
belt.5. Before placing the child in the child re-
straint, use force to tilt the child restraint
from side to side, and tug it forward to
make sure it is securely held in place.
6. Check that the retractor is in the auto-
matic locking mode by trying to pull more
belt out of the retractor. If you cannot pull
any more belt webbing out of the retrac-
tor, the belt is in the automatic locking
mode.
7. Check to make sure the child restraint is
properly secured prior to each use. If the
belt is not locked, repeat steps 3 through
6.After the child restraint is removed and the
seat belt is fully retracted (for the passenger
side of the two-passenger bench seat, the
auxilliary buckle must also be released), the
automatic locking mode (child restraint
mode) is canceled.
ARS1184ARS1185
1-50Seats, restraints and supplemental air bag systems
ZX

A child restraint anchored with a top tether
strap can be installed on the second row
bench seat, second row bucket seat, or
three-passenger bench seat in the second
or third row. The chart indicates where the
tether strap must be attached and the sec-
tion of this manual that contains the instruc-
tions for tethering.Seat type Position Tether to Reference
Bucket seat Second row; center of
seatAnchor bracket on
back of bucket seatPage 1-52, Tethering
to second row bench
or bucket seat
Two passenger bench
seatSecond row; outboard
seating positionsAnchor bracket on
back of second row
bench seatPage 1-52, Tethering
to second row bench
or bucket seat
Two-passenger bench
seat with integrated
child safety seatSecond row; driver
side seating positionAnchor bracket on
back of second row
bench seatPage 1-52, Tethering
to second row bench
or bucket seat
Two-passenger bench
seat with integrated
child safety seatSecond row; passen-
ger side seating posi-
tionCANNOT BE
TETHEREDÐ
Three-passenger
bench seatSecond row; outboard
seating positionTongue of third row
lap/shoulder belt di-
rectly behind the child
seat positionPage 1-54, Tethering
to lap/shoulder belt
tongue
Three-passenger
bench seatSecond row; center
seating positionCANNOT BE
TETHEREDÐ
Three-passenger
bench seatThird row; outboard
or center seating posi-
tion*Floor anchor directly
behind child seat posi-
tionPage 1-56, Tethering
to floor
* The parcel shelf (if so equipped) must be removed prior to tethering the child seat.
CHILD RESTRAINT WITH TOP
TETHER STRAP
Seats, restraints and supplemental air bag systems1-51
ZX

INSTALLATION ON SECOND
ROW BENCH OR BUCKET SEAT
A child restraint with a top tether strap may
be placed on the second row bench or
bucket seats. Once the child restraint is
properly secured to the seat (see ``Front
facing installation at second and third row
outboard positions'' earlier in this section),
follow the directions to attach the tether
strap to the tether strap anchor bracket, or
the third row lap/shoulder belt tongue (lo-
cated on the same side of the vehicle as the
child restraint).
Tethering to second row bench or
bucket seat
To attach a tether strap to a second row
bench or bucket seat:
1. Route the tether strap under the head
restraint and between the head restraint
supports.
cThe head restraint on the second row
bucket seat with the integrated child seat
is not adjustable, but there is an opening
under the head restraint to route the
tether strap through. Gently lift the head
restraint and route the tether strap underthe center of the head restraint through to
the back side of the seat.
APD0839
1-52Seats, restraints and supplemental air bag systems
ZX

2. Hook the tether strap into the slot in the
anchor bracket on the second row seat
(located on the lower back of the seat, in
line with the head restraint).
ARS1194ARS1193ARS1199
Seats, restraints and supplemental air bag systems1-53
ZX

3. Tighten the tether strap to remove any
slack.
4. Before placing the child in the child re-
straint, use force to tilt the child restraint
from side to side, and tug it forward to
make sure it is securely held in place.
5. Check to make sure the child restraint is
properly secured prior to each use. If not
secure, repeat steps two through four.INSTALLATION ON THREE-
PASSENGER BENCH SEAT IN
SECOND ROW
WARNING
A third seat occupant should never sit
at a seating location where the lap/
shoulder belt is being used to attach
the child seat. Occupants should sit at
locations where seat belts can be used.
Remember to always wear your seat
belt.
A child restraint with a top tether strap may
be placed at the outboard positions on the
three-passenger bench seat when the bench
seat is in the second row location. Once the
child restraint is properly secured to the seat
(see ``Front facing installation at second and
third row outboard positions'' earlier in this
section), follow the directions to attach the
tether strap to the third row lap/shoulder belt
tongue (located on the same side of the
vehicle as the child restraint).
ARS1192APD0839
1-54Seats, restraints and supplemental air bag systems
ZX

Tethering to lap/shoulder belt tongue
To attach a tether strap to a third row
lap/shoulder belt:
1. Route the tether strap under the head
restraint and between the head restraint
supports.
2. Hook the tether strap into the large hole
on the tongue of the third row lap/
shoulder belt (located near the upper and
lower rear corners of the vehicle).
3. Adjust the tether strap until the hook is
about one foot behind the seatback.4. Pull on the third row shoulder belt until all
of the belt is fully extended. At this time,
the belt retractor is in the automatic lock-
ing mode (child restraint mode).
5. Allow the belt to retract. Tighten the
tether strap to remove any slack.
6. Before placing the child in the child re-
straint, use force to tilt the child restraint
from side to side, and tug it forward to
make sure it is securely held in place.
7.
Check that the retractor is in the automatic
locking mode by trying to pull more belt
out of the retractor. If you cannot pull anymore belt webbing out of the retractor, the
belt is in the automatic locking mode.
8. Check to make sure the child restraint is
properly secured prior to each use. If the
belt is not locking, repeat steps 4 through
7.
APD0835ARS1198
Seats, restraints and supplemental air bag systems1-55
ZX

INSTALLATION ON THREE-
PASSENGER BENCH SEAT IN
THIRD ROW
A child restraint with a top tether strap may
be placed on the three-passenger bench
seat when the bench seat is in the third row
location. Once the child restraint is properly
secured to the seat (see ``Front facing in-
stallation at second and third row outboard
positions'' or ``Front facing installation at
three-passenger bench seat center posi-
tion'' earlier in this section), follow the direc-
tions to attach the tether strap to one of the
anchor point locations.
Tethering to floor
When installing a child restraint on the
three-passenger bench seat in the third row
position, first install the floor anchor bracket
(available at an authorized NISSAN dealer)
to the provided anchor point.
Bracket part #88894-89900
To gain access to an anchor point, cut along
the perforated floor carpeting of the cargo
area.
Installing the anchor bracket requires re-
moving the bolt already installed at the
anchor point and using a metric bolt of the
dimensions listed below:
Bolt diameter: 8.0 mm
Bolt length: at least 1.18 in (30 mm)
Thread pitch: 1.25 mm
WARNING
cBolts should be installed at all times
to prevent the possibility of exhaust
fumes entering the passenger com-
partment through the holes.cChild restraint anchor points are de-
signed to withstand only those loads
imposed by correctly fitted child re-
straints. Under no circumstances
are they to be used for adult seat
belts or harnesses.
cThe parcel shelf (if so equipped)
must be removed from the vehicle if
installing a child restraint on the
three-passenger bench seat that re-
quires the use of a top tether strap
that is anchored to the vehicle floor.
Failure to remove the parcel shelf
can increase the severity of injury to
the child in an accident.
Latch the tether strap hook onto the appro-
priate anchor bracket. The tether strap
should be secured to the floor anchor
bracket which provides the straightest in-
stallation.
ARS1200
1-56Seats, restraints and supplemental air bag systems
ZX

Anchor point locations
Anchor point attaching bolts are located
under the carpet of the rear luggage area
floor.
WARNING
The anchor bolt should be installed at
all times to prevent the possibility of
exhaust fumes entering the passenger
compartment through the holes.
ARS1214
