Tires
Replacing Tires and Wheels
The tires that came with your car were selected to match the perform- ance capabilities of the car while
providing the best combination of
handling, ride comfort, and long life.
You should replace them with radial tires of the same size, load range, speed rating, and maximum cold tire
pressure rating (as shown on the
tire's sidewall). Mixing radial and
bias-ply tires on your car can reduce its braking ability, traction, andsteering accuracy. It is best to replace all four tires at
the same time. If that is not possible
or necessary, then replace the two
front tires or the two rear tires as a
pair. Replacing just one tire can seriously affect your car's handling. The ABS works by comparing the
speed of the wheels. When replacing
tires, use the same size originally supplied with the car. Tire size and
construction can affect wheel speed and may cause the system to work in-
consistently.
If you ever need to replace a wheel,
make sure the wheel's specifications
match those of the original wheel
that came on your car. Replacement
wheels are available at your Honda dealer.

Maintenance

Installing improper tires on your
car can affect handling and
stability. This can cause a crash in which you can be seriouslyhurt or killed.
Always use the size and type of
tires recommended in this owner's manual.Main Menu Table of Contents s t

Lights

Replacing a Headlight Bulb
Your car has halogen headlight bulbs, one on each side. When
replacing a bulb, handle it by its steel
base and protect the glass fromcontact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean

cloth.

Halogen headlight bulbs get very hot when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
1. Open the hood.
If you need to change the head-
light bulb on the driver's side, remove the power steeringreservoir tank by pulling it out of
its holder.
2. Remove the electrical connector

from the bulb by squeezing theconnector on both sides to unlock
the tab. Pull the connector straight
off.

3. Remove the rubber weather seal by pulling on the tab.

Maintenance

NOTICE

HOLDER


WEATHER SEAL


BULB

CONNECTOR

HOLD-DOWN WIREMain Menu Table of Contents s t

Lights

4. Unclip the end of the hold-down wire from its slot. Pivot it out ofthe way and remove the bulb.
5. Insert the new bulb into the hole, making sure the tabs are in theirslots. Pivot the hold-down wire
back in place and clip the end into
the slot.
6. Install the rubber seal over the back of the headlight assembly.Make sure it is right side up; it is

marked "TOP."

7. Push the electrical connector onto the tabs of the new bulb. Makesure it locks in place.
Turn on the headlights to test the new bulb.
8. (Driver's side) Reinstall the power steering

reservoir.
Replacing the Front Side Marker/
Turn Signal and Parking Light Bulb
1. If you are changing the bulb on the driver's side, start the engine,
turn the steering wheel all the way
to the right, and turn off the
engine. If you are changing the
bulb on the passenger's side, turn
the steering wheel to the left. 2. Use a flat-tipped screwdriver to
remove the holding clip from the
inner fender.
3. Pull the inner fender cover back.
4. Remove the socket from the headlight assembly by turning it
one-quarter turn counterclockwise.
CONTINUED

Maintenance

HOLDING

CLIPMain Menu Table of Contents s t

Emergency Towing

If your vehicle needs to be towed,
call a professional towing service or, if you belong to one, an
organization that provides roadside
assistance. Never tow your vehicle
behind another vehicle with just a rope or chain. It is very dangerous.
There are three popular types of
professional towing equipment.
Flat-bed Equipment — The operator loads your vehicle on the back of a
truck. This is the best way to
transport your Honda.
Wheel-Lift Equipment — The tow
truck uses two pivoting arms that
go under the tires (front or rear) and
lift them off the ground. The other
two tires remain on the ground. This is an acceptable way to tow
your Honda.
Sling-type Equipment — The tow truck uses metal cables with hooks on the ends. These hooks go around
parts of the frame or suspension and
the cables lift that end of the vehicle
off the ground. Your vehicle's suspension and body can beseriously damaged. This method of

towing is unacceptable.

If your Honda cannot be transported

by flat-bed, it should be towed by

wheel-lift equipment with the front

wheels off the ground. If due to
damage, your vehicle must be towed with the front wheels on the ground,
do the following.
5-speed Manual Transmission Release the parking brake.
Shift the transmission to Neutral.
Automatic Transmission Release the parking brake.
Start the engine.
Shift to D4, then to N.
Turn off the engine. Improper towing preparation will
damage the transmission. Followthe above procedure exactly. If youcannot shift the transmission or
start the engine (automatictransmission), your vehicle must be
transported with the front wheels
off the ground.
With the front wheels on the ground, it is best to tow the vehicleno farther than 50 miles (80 km),
and keep the speed below 35 mph
(55 km/h).
If you decide to tow your vehicle
with all four wheels on the ground,
make sure you use a properly-
designed and attached tow bar. Prepare the vehicle for towing as
described above, and leave theignition switch in Accessory (I) so
the steering wheel does not lock.
Make sure the radio and any items
Taking Care of the Unexpected

NOTICEMain Menu Table of Contents s t

Emergency Towing

plugged into the accessory powersocket are turned off so they do not
run down the battery.
Trying to lift or tow your vehicle by
the bumpers will cause serious
damage. The bumpers are not designed to support the vehicle's

weight.

Taking Care of the Unexpected

The steering system can be
damaged if the steering wheel is locked. Leave the ignition switch in
Accessory (I), and make sure the steering wheel turns freely before
you begin towing.
NOTICE
NOTICEMain Menu Table of Contents s t

Index

Accessories and Modifications.... 130 Accessories................................. 130Additional Safety Precaution.... 131 Modifications............................. 131
ACCESSORY (Ignition Key Position)........................................ 70
Accessory Power Socket................ 85
Adding Automatic Transmission

Fluid........................................ 180

Brake Fluid................................. 183 Clutch Fluid................................ 183
Engine Coolant........................... 175

Engine Oil................................... 171

Manual Transmission Fluid..... 182
Power Steering Fluid................. 184
Windshield Washer Fluid......... 180
Additional Information About Your Seat Belts........................ 42
Lap Belt......................................... 43
Lap/Shoulder Belt....................... 42
Seat Belt Maintenance................ 44
Seat Belt System Components... 42 Additional Information About
Your SRS................................... 45
Additional Safety Precautions.... 48 How Your Airbags Work............ 45
How Your SRS Indicator
Works........................................ 47

SRS Components......................... 45

Additives, Engine Oil..................... 171

Adjustments
Head Restraints........................... 77

Mirrors.......................................... 81

Seats.............................................. 76

Steering Wheel............................ 65

Airbag (SRS)...................................... 9
Air Cleaner Element...................... 185 Air Conditioning............................... 88 Maintenance............................... 193
Usage............................................. 90
Air Outlets (Vents).......................... 90
Air Pressure, Tires........................ 196 High Speed Driving................... 250
Normal Driving.......................... 196
Alcohol in Gasoline........................ 252
Antifreeze....................................... 175
Anti-lock Brakes (ABS) Indicator Light.................... 55, 153
Operation.................................... 152

Anti-theft Steering Column
Lock............................................... 70

Appearance Care........................... 213
Ashtrays (Optional)......................... 85

Audio System................................... 96

Automatic Speed Control................ 66
Automatic Transmission............... 140

Capacity, Fluid........................... 247

Checking Fluid Level................ 180

Shifting........................................ 141
Shift Lever Position Indicator.. 140
Shift Lever Positions................. 141
Shift Lock Release..................... 144
Battery Charging SystemIndicator............................ 55, 232
Jump Starting............................. 227 Maintenance............................... 189
Specifications............................. 248
CONTINUEDMain Menu s t

Index

Before Driving............................... 123
Belts, Seat........................................... 8
Beverage Holder.............................. 84
Body Repair.................................... 214
Brakes Anti-lock System (ABS)............ 151Break-in, New Linings .............. 124
Fluid............................................ 182
Light, Burned-out...................... 206
Parking.......................................... 82
System Indicator.......................... 55
Wear Indicators......................... 150
Brakes, ABS Operation.................................... 150
System Indicator................. 55, 153
Braking System.............................. 150
Break-in, New Car......................... 124
Brightness Control, Instruments... 62
Brights, Headlights......................... 61
Bulb Replacement Back-up Lights........................... 207
Brake Lights ...................... 206, 207
Front Parking Lights................. 205
Front Side Marker Lights......... 205
Headlights.................................. 204
High-mount Brake Light.......... 209
Interior Light.............................. 210

License Plate Lights.................. 209

Rear Side Marker Lights.......... 206

Specifications............................. 248

Trunk Light................................ 211

Turn Signal Lights............. 205, 206
Bulbs, Halogen............................... 204
Cables, Jump Starting With.......... 227
Capacities Chart............................. 247
Carbon Monoxide Hazard.............. 49
Carrying Cargo.............................. 132
Cassette Player
Operation.................................... 115

CAUTION, Explanation of............... ii
CD Changer.................................... 100
CD Player........................................ 100

Certification Label......................... 244

Chains............................................. 201

Change Oil
How to......................................... 173

When to....................................... 162

Changing a Flat Tire..................... 221
Changing Engine Coolant............. 177 Charging System Indicator.... 55, 232
Checking
Automatic Transmission
Fluid........................................ 180

Battery Condition...................... 189

Brake Fluid................................. 183

Clutch Fluid................................ 183

Drive Belts.................................. 194
Engine Coolant........................... 128
Engine Oil................................... 127

Fuses........................................... 236
Manual Transmission Fluid ..... 182
Power Steering Fluid................. 184
Checklist, Before Driving............. 136
Cleaner, Air.................................... 185
Cleaning Exterior....................................... 214
Interior........................................ 216 Seat Belts.................................... 216
Vinyl............................................ 216 Windows..................................... 217
Clock, Setting the ............................ 99
Clutch Fluid.................................... 183

CO in the Exhaust......................... 254
Cold Weather, Starting in............. 137
Compact Spare............................... 220Main Menu s t

Index

Ethanol in Gasoline ....................... 252
Evaporative Emissions Controls.. 254

Exhaust Fumes................................ 49

Expectant Mothers, Use of Seat Belts by......................................... 19
Exterior, Cleaning the................... 214
Fabric, Cleaning............................. 216
Fan, Interior...................................... 88
Features, Comfort and Convenience................................. 87
Filling the Fuel Tank..................... 125
Filters Air................................................ 185

Oil................................................ 173

5-speed Manual Transmission
Checking Fluid Level................ 182
Shifting the................................. 138
Flashers, Hazard Warning.............. 64
Flat Tire, Changing a.................... 221
Fluids Automatic Transmission........... 180Brake........................................... 183Clutch.......................................... 183 Manual Transmission............... 182
Power Steering........................... 184
Windshield Washer................... 180
FM Stereo Radio Reception.................................... 120
Folding Rear Seat............................ 78
Foreign Countries, Driving in...... 253
Four-way Flashers........................... 64
Front End, Towing by Emergency Wrecker................. 241

Fuel.................................................. 124

Fill Door and Cap....................... 125Gauge............................................ 58
Octane Requirement................. 124
Oxygenated................................ 252
Reserve Indicator......................... 58
Tank, Filling the......................... 125
Fuses, Checking the...................... 236

Gas Mileage, Improving................ 129
Gasohol........................................... 252

Gasoline.......................................... 124
Fuel Reserve Indicator................ 58
Gauge............................................ 58
Octane Requirement................. 124

Tank, Filling the......................... 125

Gas Station Procedures................. 125

Gauges
Engine Coolant Temperature .... 58

Fuel................................................58
Gearshift Lever Positions
Automatic Transmission........... 140

5-speed Manual
Transmission.......................... 138

Glass Cleaning............................... 217

Glove Box......................................... 83

Halogen Headlight Bulbs.............. 204
Hazard Warning Flashers............... 64
Headlights
Daytime Running Lights............. 61
High Beam Indicator................... 55
High Beams, Turning on............ 61
Low Beams, Turning on............. 61
Reminder Beeper......................... 61
Replacing Halogen Bulbs ......... 204

Turning on.................................... 61

Head Restraints............................... 77Main Menu s t
