1999 FORD MUSTANG Owners Manual

Fluid capacities ....... 183
Foglamps ................... 53
Fuel .......................... 158
calculating fuel
economy ................ 164
cap ......................... 161
capacity ................. 183
choosing
the right fuel ......... 162
comparisons with
EPA fuel economy
estimates ............... 168
detergent in fuel ... 163
filling your vehicle
with fuel .. 158,161,164
filter,
specifications . 163,182
fuel pump shut-off
switch .................... 112
gauge ....................... 12
improving fuel
economy ................ 164
low fuel
warning light ............. 9
octane rating .. 162,188
quality .................... 162
running
out of fuel ............. 163
safety information
relating to
automotive fuels ... 158
Fuses ................. 113,114
Gas cap
(see Fuel cap) ......... 161
Gas mileage(see
Fuel economy) ........ 164
Gauges .................. 11,12
battery voltage
gauge ....................... 15
engine coolant
temperature gauge . 12engine oil pressure
gauge ....................... 15
fuel gauge ................ 12
odometer ................. 13
speedometer ........... 13
tachometer .............. 14
trip odometer .......... 14
GAWR (Gross Axle
Weight Rating) ........ 106
definition ............... 106
driving with
a heavy load .......... 106
location .................. 106
GVWR (Gross Vehicle
Weight Rating) ........ 106
calculating ............. 106
definition ............... 106
driving with
a heavy load .......... 106
location .................. 106
Hazard flashers ....... 112
Head restraints ......... 64
Headlamps ................. 16
aiming ............. 175,176
bulb
specifications ........ 175
daytime
running lights .......... 16
flash to pass ............ 45
high beam ............ 7,45
turning on and off .. 16
warning chime ........ 11
Heating ...................... 18
heating and air
conditioning
system ..................... 18
Hood ........................ 132
Ignition ..................... 188
positions of the
ignition .................... 45
removing the key .. 105
Index
209

Infant seats
(see Safety seats) ..... 81
Inspection/maintenance
(I/M) testing ............ 169
Instrument panel ........ 6
cleaning ................. 180
lighting up panel
and interior ............. 17
location of
components ............... 6
Jump-starting your
vehicle ...................... 123
Keys
key in ignition
chime ....................... 11
positions of the
ignition .................... 45
removing from the
ignition .................. 105
Lamps
cargo lamps ............. 17
daytime
running light ........... 16
fog lamps ................. 53
headlamps ........ 16,171
headlamps,
flash to pass ............ 45
instrument panel,
dimming ................... 17
interior lamps ......... 50
174,175
replacing
bulbs ............... 170,171
172,173,174
Lane change indicator
(see Turn signal) ...... 44
Lights, warning and
indicator ...................... 6
air bag ........................ 7
anti-lock brakes
(ABS) ................. 10,93
anti-theft ................... 7brake ........................ 10
charging system ........ 7
check coolant .......... 10
high beam ................. 7
low fuel ...................... 9
overdrive off .............. 9
safety belt ................. 7
service engine soon .. 8
traction
control active .......... 10
turn signal
indicator .................... 6
Load limits ............... 106
GAWR .................... 106
GVWR .................... 106
trailer towing ........ 106
Locks
doors ........................ 51
Lubricant
specifications .... 185,188
Lumbar support,
seats ........................... 66
Manual
transmission ............ 102
fluid capacities ...... 183
lubricant
specifications ........ 188
reverse ................... 104
Mirrors
side view mirrors
(power) ................... 51
Motorcraft
parts .................. 163,182
Octane rating .......... 162
Odometer ................... 13
Panic alarm feature,
remote entry
system ........................ 58
Parking brake ............ 94
Parts (see
Motorcraft parts) .... 182
Index
210

Power distribution box
(see Fuses) ............. 117
Power door locks ...... 51
Power steering .......... 96
fluid, checking
and adding ............ 144
fluid, refill
capacity ................. 183
fluid,
specifications . 185,188
Radio .......................... 21
Relays ...................... 113
Remote entry
system ................... 56,58
illuminated entry .... 58
locking/unlocking
doors ........................ 57
opening the trunk ... 58
panic alarm ............. 58
replacement/
additional
transmitters ............. 59
replacing the
batteries .................. 59
Roadside
emergencies ......... 60,62
Safety belts (see
Safety restraints) ...... 11
68,69,70,71,72
Safety Compliance
Certification Label .. 190
Safety defects,
reporting .................. 206
Safety restraints ... 68,69
70,71,72
cleaning the safety
belts .................. 73,181
extension
assembly .................. 72
for adults .. 69,70,71,72
for children ........ 79,80warning light and
chime .......... 7,11,72,73
Safety seats
for children ................ 81
Seat belts (see Safety
restraints) .................. 68
Seats .......................... 64
child safety seats .... 81
cleaning ................. 180
Seats-easy access/
easyout feature ......... 67
Servicing your
vehicle ...................... 130
Spark plugs,
specifications .... 182,188
Special notice .............. 3
Specification chart,
lubricants .......... 185,188
Speed control ............ 46
Speedometer ............. 13
Starting your
vehicle .............. 87,88,90
jump starting ........ 123
preparing to start
your vehicle ....... 60,62
Steering wheel
tilting ....................... 46
Tachometer ............... 14
Tilt steering wheel .... 46
Tires .... 119,153,154,155
changing ......... 119,120
checking the
pressure ................. 155
replacing ................ 156
rotating .................. 155
snow tires
and chains ............. 157
tire grades ............. 154
treadwear .............. 154
Towing
trailer towing ........ 108
wrecker .................. 128
Index
211

Traction control ........ 95
active light .............. 10
Traction-lok
rear axle .................. 105
Transmission
automatic
operation ................. 97
fluid, checking
and adding
(automatic) ........... 146
fluid, checking and
adding (manual) ... 149
fluid,
refill capacities ...... 183
lubricant
specifications ........ 188
manual operation .. 102
Trip odometer ........... 14
Trunk
remote release ... 44,58
Turn signal ............. 6,44
Vehicle dimensions . 188
Vehicle Identification
Number (VIN) ......... 190Vehicle loading ........ 106
Ventilating
your vehicle ............... 91
Warning chimes ......... 11
Warning lights
(see Lights) ................. 6
Washer fluid ............ 140
Water,
Driving through ....... 111
Wheels
anti-theft
lug nuts ................. 123
Windows
power ....................... 50
Windshield washer
fluid and wipers
checking
and cleaning .......... 152
operation ................. 44
replacing
wiper blades .......... 153
Wrecker towing ....... 128
Index
212

213

214

Item Information
Required fuel Unleaded fuel only -
87 octane
Fuel tank capacity 58.7L (15.5 gallons)
Engine oil capacity
(includes filter change)4.7L (5.0 quarts). Use
Motorcraft 5W30 Super
Premium Motor Oil,
Ford specification
WSS-M2C153-G
Tire size and pressure Refer to the
Certification Label.
Hood release Pull handle under the
left side of the
instrument panel.
Coolant capacity-3.8L
OHV V6 engine
111.2L (11.8 quarts)
Coolant capacity-4.6L
SOHC V8 engine
113.3L (14.1 quarts)
Power steering fluid
capacityFill to line on reservoir
or dipstick. Use
Motorcraft MERCONt
AT F.
Manual transmission
fluid capacity-3.8L OHV
V6 engine2.6L (5.6 pints). Use
Motorcraft MERCONt
AT F.
Manual transmission
fluid capacity-4.6L
SOHC V8 engine
2
3.1L (6.6 pints). Use
Motorcraft MERCONt
AT F.
Automatic transmission
fluid capacity-3.8L OHV
V6 engine
3
13.1L (13.9 quarts). Use
Motorcraft MERCONtV
AT F.
Automatic transmission
fluid capacity-4.6L
SOHC V8 engine
3
12.0L (12.8 quarts). Use
Motorcraft MERCONtV
AT F.
Filling station information
215

1Use Ford Premium Engine Coolant (green in
color). DO NOT USE Ford Extended Life Engine
Coolant (orange in color). Refer toAdding engine
coolant, in the Maintenance and Care chapter.
2Service refill capacity is determined by filling the
transmission to the bottom of the filler hole with the
vehicle on a level surface.
3Ensure the correct automatic transmission fluid is
used. Transmission fluid requirements are indicated
on the dipstick or on the dipstick handle. MERCONt
and MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to your
Scheduled Maintenance Guide to determine the
correct service interval.
Filling station information
216
