1999 FORD MUSTANG Owners Manual

3Ensure the correct automatic transmission fluid is
used. Transmission fluid requirements are indicated
on the dipstick or on the dipstick handle. MERCONt
and MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to your
Scheduled Maintenance Guide to determine the
correct service interval.
4Service refill capacity is determined by filling the
transmission to the bottom of the filler hole with the
vehicle on a level surface.
LUBRICANT SPECIFICATIONS
Item Ford part
nameFord part
numberFord
speci-
fication
Brake fluid High Per-
formance
DOT 3
Motor
Vehicle
Brake FluidC6AZ-
19542-ABESA-
M6C25-A
and DOT 3
Door
weather-
stripsSilicone
LubricantF7AZ-
19G208-BA
and F5AZ-
19553-AAESR-
M13P4-A
Door latch,
hood latch,
auxiliary
hood latch,
door
hinges,
striker
plates, seat
tracks and
fuel filler
door hingeMulti-
Purpose
GreaseD0AZ-
19584-AA
or F5AZ-
19G209-AAESB-
M1C93-B
or ESR-
M1C159-A
Capacities and specifications
185

Item Ford part
nameFord part
numberFord
speci-
fication
Engine
coolantFord
Premium
Engine
CoolantE2FZ-
19549-AA
(in Oregon,
F5FZ-
19549-CC,
in Canada,
Motorcraft
CXC-10)ESE-
M97B44-A
Engine oil Motorcraft
5W-30
Super
Premium
Motor OilXO-
5W30-QSPWSS-
M2C153-G
with API
Certification
Mark
Lock
cylindersPenetrating
and Lock
LubricantE8AZ-
19501-Bnone
Power
steering
fluid and
convertible
top fluid (if
equipped)Motorcraft
MERCONt
AT FXT-5-QM MERCONtV
Rear axle
lubricantMotorcraft
SAE 80W90
Premium
Rear Axle
Lubricant
1
XY-
80W90-QLWSP-
M2C197-A
Automatic
transmission
fluidMotorcraft
MERCONtV
AT FXT-5-QM MERCONtV
Capacities and specifications
186

Item Ford part
nameFord part
numberFord
speci-
fication
Manual
transmission
fluidMotorcraft
MERCONt
AT FXT-2-QDX MERCONt
Disc brake
caliper railsSilicone
Brake
Caliper and
Dielectric
compoundD7AZ-
19A331-A
(Motorcraft
WA-10)ESE-
M1C171-A
Windshield
washer
fluidUltra-Clear
Windshield
Washer
ConcentrateC9AZ-
19550-ACESR-
M17P5-A
1Add 118 ml (4 oz.) of additive friction modifier
C8AZ-19B546±A, Ford specification EST-M2C118±A
for complete refill of Traction-Lok axles.
Ford design rear axles contain a synthetic lubricant
that does not require changing unless the axle has
been submerged in water.
Capacities and specifications
187

ENGINE DATA
Engine 3.8L OHV V6
engine4.6L SOHC V8
engine
Cubic inches 232 281
Horsepower 190 @
5250 rpm260 @
5250 rpm
Torque 220 lb.-ft. @
2750 rpm302 lb.-ft. @
4000 rpm
Required fuel 87 octane 87 octane
Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm
(0.052-
00.056 inch)1.3-1.4 mm
(0.052-
00.056 inch)
Ignition system EDIS Coil on plug
Compression
ratio9.4:1 9.0:1
VEHICLE DIMENSIONS
Vehicle
dimensionsCoupe mm
(in)Convertible
mm (in)
(1) Overall
length4 653.3 (183.2) 4 653.3 (183.2)
(2) Overall
width1 856.7 (73.1) 1 856.7 (73.1)
(3) Overall
height1 353.8 (53.3)
11 356.4 (53.4)2
(4) Wheelbase 2 573.0 (101.3) 2 573.0 (101.3)
(5) Track -
Front1 534.2 (60.4)31 534.2 (60.4)3
(5) Track -
Rear1 539.2 (60.6)41 539.2 (60.6)4
1
1 358.9 mm (53.5 in) for Mustang GT
21 361.4 mm (53.6 in) for Mustang GT
31 521.5 mm (59.9 in) for Mustang GT
41 526.5 mm (60.1 in) for Mustang GT
Capacities and specifications
188

25
3
4
1
Capacities and specifications
189

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway
Traffic Safety
Administration
Regulations require
that a Certification
Label be affixed to a
vehicle and prescribe
where the Certification
Label may be located.
The Certification Label
is located on the front
door latch pillar on the driver's side.
Vehicle identification number
The vehicle
identification number
is attached to a metal
tag and is located on
the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the
vehicle identification number) is stamped on the
engine block, transmission, frame and transfer case
(if equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXXTHIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXXAIR BAG
Capacities and specifications
190

GETTING ROADSIDE ASSISTANCE
To fully assist you should you have a vehicle
concern, Ford offers a complimentary roadside
assistance program. This program is separate from
the New Vehicle Limited Warranty. The service is
available:
²24±hours, seven days a week
²for the Basic warranty period (Canada) or New
Vehicle Limited Warranty period (U.S.) of three
years or 60,000 km (36,000 miles), whichever
comes first on Ford and Mercury vehicles, and
four years or 80,000 km (50,000 miles) on Lincoln
vehicles
In the United States, you may purchase additional
roadside assistance coverage beyond this period
through the Ford Auto Club by contacting your Ford
or Lincoln-Mercury dealer.
Roadside assistance will cover:
²changing a flat tire
²jump-starts
²lock-out assistance
²fuel delivery
²towing to the nearest Ford of Canada or Ford
Motor Company dealership, or towing to your
selling dealership if within 56 km (35 miles). Even
non-warranty related tows, like accidents or
getting stuck in the mud or snow, are covered
(some exclusions apply, such as impound towing
or repossession).
Using roadside assistance
Complete the roadside assistance identification card
and place it in your wallet for quick reference. In the
United States, this card is found in the Owner Guide
portfolio in the glove compartment in Ford vehicles
and is mailed to you if you own a Mercury or
Lincoln. In Canada, it's found in the Roadside
Assistance book in the glove compartment.
Customer assistance
191

To receive roadside assistance in the United States
for Ford or Mercury vehicles, call 1-800-241-3673 or
if you own a Lincoln vehicle, call 1±800±521±4140.
In Canada call 1±800±665±2006.
Should you need to arrange assistance for yourself,
Ford will reimburse a reasonable amount. To obtain
information about reimbursement, call
1-800-241-3673 in the United States for Ford or
Mercury vehicles; or if you own a Lincoln vehicle,
call 1±800±521±4140. Call 1±800±665±2006 in
Canada.
Ford extended service plan
You can get more protection for your new car or
light truck by purchasing Ford Extended Service
Plan (Ford ESP) coverage. Ford ESP is an optional
service contract which is backed by Ford Motor
Company or Ford Motor Service Company (in the
U.S.) and Ford of Canada (in Canada). It provides:
²Protection against repair costs after your New
Vehicle Limited Warranty period expires;
and
²Other benefits during the warranty period (such
as reimbursement for rentals and towing.)
You may purchase Ford ESP from any participating
Ford or Lincoln-Mercury or Ford of Canada dealer.
There are several plans available in various time,
distance and deductible combinations which can be
tailored to fit your own driving needs. Ford ESP also
offers reimbursement benefits for towing and rental
coverage. (In Hawaii, rules vary. See your dealer for
details.)
When you buy Ford ESP, you receive Peace-of-Mind
protection throughout the United States and Canada,
provided by a network of more than 5,200
participating Ford, Lincoln-Mercury and Ford of
Canada dealers.
If you did not take advantage of the Ford Extended
Service Plan at the time of purchasing your vehicle,
Customer assistance
192
