Fig. 18: Measuring Connecting Rod Side Clearance - Typical
This Graphic For General Information Only
Check for improper bearing installation, wrong bearing cap
or insufficient bearing clearance if side clearance is insufficient.
Connecting rod may require machining to obtain proper clearance.
Excessive clearance usually indicates excessive wear at crankshaft.
Crankshaft must be repaired or replaced.
MAIN & CONNECTING ROD BEARING CLEARANCE
Plastigage Method
Plastigage method may be used to determine bearing clearance.
Plastigage can be used with an engine in service or during reassembly.
Plastigage material is oil soluble.
Ensure journals and bearings are free of oil or solvent.
Oil or solvent will dissolve material and false reading will be
obtained. Install small piece of Plastigage along full length of
bearing journal. Install bearing cap in original location. Tighten
bolts to specification.
CAUTION: DO NOT rotate crankshaft while Plastigage is installed.
Bearing clearance will not be obtained if crankshaft is
rotated.
Remove bearing cap. Compare Plastigage width with scale on
Plastigage container to determine bearing clearance. See Fig. 19.
Rotate crankshaft 90 degrees. Repeat procedure. this is done to check
journal eccentricity. This procedure can be used to check oil
clearance on both connecting rod and main bearings.
length of cylinder block at several points.
If warpage exceeds specifications, deck must be resurfaced.
If warpage exceeds manufacturer's maximum tolerance for material
removal, replace block.
DECK HEIGHT
Distance from the crankshaft centerline to the block
deck is termed the deck height. Measure and record front and rear main
journals of crankshaft. To compute this distance, install crankshaft
and retain with center main bearing and cap only. Measure distance
from the crankshaft journal to the block deck, parallel to the
cylinder centerline.
Add one half of the main bearing journal diameter to distance
from crankshaft journal to block deck. This dimension should be
checked at front and rear of cylinder block. Both readings should be
the same.
If difference exceeds specifications, cylinder block must be
repaired or replaced. Deck height and warpage should be corrected at
the same time.
MAIN BEARING BORE & ALIGNMENT
For checking main bearing bore, remove all bearings from
cylinder block and main bearing caps. Install main bearing caps in
original location. Tighten bolts to specification. Using inside
micrometer, measure main bearing bore in 2 areas 90 degrees apart.
Determine bore size and out-of-round. If diameter is not within
specification, block must be align-bored.
For checking alignment, place a straightedge along centerline
of main bearing saddles. Check for clearance between straightedge and
main bearing saddles. Block must be align-bored if clearance is
present.
EXPANSION PLUG REMOVAL & INSTALLATION
Removal
Drill a hole in the center of expansion plug. Remove with
screwdriver or punch. Use care not to damage sealing surface.
Installation
Ensure sealing surface is free of burrs. Coat expansion plug
with sealer. Use a wooden dowel or pipe of slightly smaller diameter,
install expansion plug. Ensure expansion plug is evenly located.
OIL GALLERY PLUG REMOVAL & INSTALLATION
Removal
Remove threaded oil gallery plugs using the appropriate
wrench. Soft, press-in plugs are removed by drilling into plug and
installing a sheet metal screw. Remove plug with slide hammer or
pliers.
Installation
Ensure threads or sealing surface is clean. Coat threaded oil
gallery plugs with sealer and install. Replacement soft press-in plugs
are driven in place with a hammer and drift.
CAMSHAFT
* PLEASE READ THIS FIRST *
Fig. 31: Measuring Rotor Clearance - Typical
This Graphic For General Information Only
Install rotors in pump body. Position straightedge across
pump body. Using feeler gauge, measure clearance between rotors and
straightedge. Pump cover wear is measured using a straightedge and
feeler gauge. Replace pump if clearance exceeds specification.
GEAR TYPE
Oil pump gears must be marked for location prior to removal.
See Fig. 32 . Remove gears from pump body. Inspect gears for pitting
or damage. Inspect cover for grooving or wear.
Fig. 32: Typical Gear Type Oil Pump
This Graphic For General Information Only
Measure gear diameter and length. Measure gear housing cavity
depth and diameter. See Fig. 33. Replace components if worn or
vacuum connector. Remove heater control panel. To install, reverse
removal procedure.
HEATER CORE
Removal & Installation
Remove heater assembly from vehicle. See HEATER ASSEMBLY.
Disable heater assembly and remove heater core.
INSTRUMENT PANEL
Removal & Installation (Dakota & Durango)
1) Disconnect negative battery cable. Disable air bag system.
See AIR BAG SYSTEM SAFETY article. Place front wheels in straight-
ahead position. Remove sill trim from both doorways. Remove kick panel
covers from both sides of vehicle. Remove mounting bolts for hood
release handle.
2) Remove steering column trim panel and support bracket. If
equipped, remove tilt steering column lever. Remove upper and lower
shrouds from steering column. Remove knee bolster. Unplug driver's
side air bag module. Loosen multifunction switch wiring harness
connector screw and disconnect from switch. Screw will remain in
connector.
3) Disconnect PRNDL cable. Disconnect shift cable from
steering column. Remove steering coupler lock pin. Remove toe plate
retaining bolts. Remove steering column mounting bolts and remove
steering column from vehicle.
4) Remove screw from bulkhead wiring harness connector and
disconnect. Disconnect 2 body wiring harness connectors located next
to bulkhead connector. Disconnect 3 wiring harness connectors located
nearest to dash panel from junction block. Disconnect brake light
switch. If equipped, disconnect Rear Wheel Anti-Lock (RWAL) brake
module, located near steering column support brackets.
5) Disconnect plastic retainer clip from parking brake
linkage rod, located at back of parking brake release handle. Remove
rod end from parking brake handle. Remove instrument panel center
support bracket. Unplug vacuum harness connector located at left end
of heater assembly housing. Disconnect Air Bag Control Module (ACM)
connector.
6) Remove glove box. Reach through glove box opening and
disconnect antenna coaxial cable. Disconnect blower motor connector
located above glove box opening, near support brace for heater
assembly housing. Disconnect radio ground strap. Loosen instrument
panel roll-own bracket bolts about 2 turns (bolts are located at lower
corners, on both sides of instrument panel). Remove 5 bolts across top
of dash panel, at base of windshield, removing center screw last.
7) Roll down instrument panel and install a temporary support
hook that is about 18" (457 mm) in length. Install hook from center
hole in instrument panel to center hole of dash panel. Pull lower
instrument panel outward until both roll-down bracket bolts are in
slotted roll-down position. Instrument panel should now be supported
and away from firewall.
8) Disconnect 2 body wiring harness connectors, located on a
bracket near right end of instrument panel. Disconnect blower motor
resistor. Disconnect temperature control cable from heater assembly
housing and remove from housing. Disconnect defrost duct flexible hose
from heater assembly housing.
9) Ensure all electrical and vacuum connectors are
disconnected and instrument panel is free and clear for removal. With
the aid of an assistant, remove temporary support hook. Lift
instrument panel off of roll-down bracket bolts and remove from
vehicle.
10) To install, reverse removal procedure. Ensure all wiring
HO W T O U SE S YSTE M W IR IN G D IA G RAM S
1999 D odge P ic ku p R 1500
GENERAL INFORMATION
Using Wiring Diagrams
All Models
INTRODUCTION
This CD obtains wiring diagrams and technical service
bulletins, containing wiring diagram changes from the domestic and
import manufacturers. These are checked for accuracy and are all
redrawn into a consistent format for easy use.
In the past, when cars were simpler, diagrams were simpler.
All components were connected by wires and diagrams seldom exceeded 4
pages in length. Today, some wiring diagrams require more than 16
pages. It would be impractical to expect a service technician to trace
a wire from page 1 across every page to page 16.
Removing some of the wiring maze reduces eyestrain and time
wasted searching across several pages. Today the majority of
these
diagrams follow a much improved format, which permits space for
internal switch details.
Wiring diagrams are drawn in a "top-down" format. The
diagrams are drawn with the power source at the top of the diagram and
the ground point at the bottom of the diagram. Components locations
are identified on the wiring diagrams. Any wires that don't connect
directly to a component are identified on the diagram to indicate
where they go.
COLOR ABBREVIATIONS
COLOR ABBREVIATIONS TABLE \
\
\
\
\
\
Color Normal Optional
Black ................ BLK .......................... BK
Blue ................. BLU .......................... BU
Brown ................ BRN .......................... BN
Clear ................ CLR .......................... CR
Dark Blue .......... DK BLU ...................... DK BU
Dark Green ......... DK GRN ...................... DK GN
Green ................ GRN .......................... GN
Gray ................. GRY .......................... GY
Light Blue ......... LT BLU ...................... LT BU
Light Green ........ LT GRN ...................... LT GN
Orange ............... ORG .......................... OG
Pink ................. PNK .......................... PK
Purple ............... PPL .......................... PL
Red .................. RED .......................... RD
Tan .................. TAN .......................... TN
Violet ............... VIO .......................... VI
White ................ WHT .......................... WT
Yellow ............... YEL .......................... YL
\
\
\
\
\
\
IDENTIFYING WIRING DIAGRAM ABBREVIATIONS
NOTE: Abbreviations used on these diagrams are normally
self-explanatory. If necessary see ABBREVIATIONS
METR IC C O NVER SIO NS
1999 D odge P ic ku p R 1500
GENERAL INFORMATION
METRIC CONVERSIONS
METRIC CONVERSIONS
Metric conversions are making life more difficult for the
mechanic. In addition to doubling the number of tools required,
metric-dimensioned nuts and bolts are used alongside English
components in many new vehicles. The mechanic has to decide which tool
to use, slowing down the job. The tool problem can be solved by trial
and error, but some metric conversions aren't so simple. Converting
temperature, lengths or volumes requires a calculator and conversion
charts, or else a very nimble mind. Conversion charts are only part of
the answer though, because they don't help you "think" metric, or
"visualize" what you are converting. The following examples are
intended to help you "see" metric sizes:
LENGTH
Meters are the standard unit of length in the metric system.
The smaller units are 10ths (decimeter), 100ths (centimeter), and
1000ths (millimeter) of a meter. These common examples might help you
to visualize the metric units:
* A meter is slightly longer than a yard (about 40 inches).
* An aspirin tablet is about one centimeter across (.4 inches).
* A millimeter is about the thickness of a dime.
VOLUME
Cubic meters and centimeters are used to measure volume, just
as we normally think of cubic feet and inches. Liquid volume
measurements include the liter and milliliter, like the English quarts
or ounces.
* One teaspoon is about 4 cubic centimeters.
* A liter is about one quart.
* A liter is about 61 cubic inches.
WEIGHT
The metric weight system is based on the gram, with the most
common unit being the kilogram (1000 grams). Our comparable units are
ounces and pounds:
* A kilogram is about 2.2 pounds.
* An ounce is about 28 grams.
TORQUE
Torque is somewhat complicated. The term describes the amount
of effort exerted to turn something. A chosen unit of weight or force
is applied to a lever of standard length. The resulting leverage is
called torque. In our standard system, we use the weight of one pound
applied to a lever a foot long, resulting in the unit called a foot-
pound. A smaller unit is the inch-pound (the lever is one inch long).
Metric units include the meter kilogram (lever one meter long
with a kilogram of weight applied) and the Newton-meter (lever one
meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cm
).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS\
\
\
\
\
\
\
TO CONVERT TO MULTIPLY BY
\b
\
\
\
\
\
\
\
LENGTH
Millimeters (mm) Inches .03937
Inches Millimeters 25.4
Meters (M) Feet 3.28084
Feet Meters .3048
Kilometers(Km) Miles .62137
\b
\
\
\
\
\
\
\
AREA
Square Centimeters (cm ) Square Inches .155
Square Inches Square Centimeters 6.45159
\b
\
\
\
\
\
\
\
VOLUME
Cubic Centimeters Cubic Inches .06103
Cubic Inches Cubic Centimeters 16.38703
Liters Cubic Inches 61.025
Cubic Inches Liters .01639
Liters Quarts 1.05672
Quarts Liters .94633
Liters Pints 2.11344
Pints Liters .47317
Liters Ounces 33.81497
Ounces Liters .02957
\b
\
\
\
\
\
\
\
WEIGHT
Grams Ounces .03527
Ounces Grams 28.34953
Kilograms Pounds 2.20462
Pounds Kilograms .45359
\b
\
\
\
\
\
\
\
WORK
Centimeter Kilograms Inch Pounds .8676
Pounds/Sq. Inch Kilograms/Sq.Centimeter .07031
Bar Pounds/Sq. Inch 14.504
Apply light coat of engine oil on NEW .060" (1.5 mm) thick Copper
sealing washer. Install NEW Copper sealing washer on spray tip of fuel
injector. Engine oil is used to aid holding sealing washer in place.
Install new "O" ring on fuel injector. Apply small amount of engine
oil to "O" ring.
2) Ensure fuel inlet hole on side of fuel injector is
positioned toward injector connector tube. Install injector into
cylinder head bore using care not to allow injector tip to touch sides
of bore. Press fuel injector into cylinder head with finger pressure
only. Install fuel injector hold down clamp into shouldered bolt while
aligning slot in top of injector into groove in bottom of clamp.
Tighten opposite clamp bolt to specification. See TORQUE
SPECIFICATIONS.
3) Apply small amount of clean engine oil to NEW "O" ring.
Install "O" ring to fuel injector connector tube. Using finger
pressure only, press injector connector tube into cylinder head.
Connect and tighten high pressure fuel lines to specification. See
TORQUE SPECIFICATIONS.
NOTE: Fuel line fitting torque is important. Mating surfaces will
not seal if fuel line fitting is under or over-torqued.
4) To install remaining components, reverse removal
procedure. Tighten bolts to specification. See TORQUE SPECIFICATIONS.
Bleed high-pressure fuel lines. See FUEL LINE BLEEDING under FUEL
SYSTEM.
FUEL INJECTION PUMP
CAUTION: High-pressure fuel lines must be clamped securely and routed
so they do not contact each other or any other components. DO
NOT weld or substitute high-pressure fuel lines. High
-pressure lines are same length and proper high-pressure fuel
line must be installed in specified area for proper engine
operation.
Removal
1) Disconnect negative battery cables. Clean fuel lines at
cylinder head and injection pump. Clean fuel injection pump and fuel
lines at side of pump. Disconnect 9-pin electrical connector at Fuel
Pump Control Module (FPCM). Place a rag around overflow valve to catch\
excess fuel. Remove overflow valve and disconnect fuel return line.
Remove banjo bolts and fuel supply line at side of injection pump and
top of fuel filter housing.
2) Remove all high pressure fuel lines, intake air tube,
accelerator pedal position sensor, air intake housing, engine oil
dipstick tube, wiring clips, electrical connectors at intake heaters,
and engine lifting bracket. Unscrew plastic access cap at front gear
cover. Remove injection pump gear-to-injection pump shaft nut and
washer.
3) Engine may be rotated by removing dust plug from
transmission adapter plate and installing Engine Barring Tool (Snap-On
SP371) in transmission adapter plate. See Fig. 9. Rotate engine until
keyway is at 12 o'clock position.
