1999 DODGE RAM engine coolant

cylinder block, above oil
pan rail.
Engine Coolant Temperature
Sensor (Diesel) On front of cylinder head,
near thermostat housing.
Engine Coolant Temperature
Sensor (3.9L) In water jacket, at front of
intake manifold.

Engine Coolant Temperature
Sensor (5.2L) In water jacket, at front of
intake manifold.
Engine Coolant Temperature
Sensor (5.9L) In water jacket, at front of
intake manifold.
Engine Coolant Temperature

Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Refer to manufacturer's diagnostic trouble code procedure
and require repair or replacement of affected
component(s).
( 2) - Determine cause and correct prior to repair or replacement
of part.
( 3) - Determine source of contamination, such as engine
coolant, fuel, metal particles, or water. Require
repair or replacement.
( 4) - Inoperative includes intermittent operation or out of OEM
specification. Some components may be serviceable; check
for accepted cleaning procedure.









\









\









\









\









\









\









\


CRUISE CONTROL BRAKE SWITCHES
See SWITCHES.
CRUISE CONTROL CABLES
See CRUISE CONTROL LINKAGES AND CABLES .
CRUISE CONTROL CLUTCH SWITCHES
See SWITCHES.
CRUISE CONTROL LINKAGES AND CABLES
CRUISE CONTROL LINKAGE AND CABLE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Bent .................... A .. Require repair or replacement.
Binding ................. A .. Require repair or replacement.
Bracket bent, affecting
performance ............ A .. Require repair or replacement.
Bracket bent, not
affecting performance .. .. ........ No service suggested or
required.
Bracket broken, affecting
performance ............ A ............ Require replacement.
Bracket broken, not
affecting performance .. .. ........ No service suggested or
required.
Bracket corroded,
affecting performance .. A .. Require repair or replacement.
Bracket corroded, not
affecting performance .. 2 .. Suggest repair or replacement.

These 3 orifices are opened and closed by electric solenoids. The
solenoids are, in turn, controlled by the Electronic Control Module
(ECM). When a solenoid is energized, the armature with attached shaft
and swivel pintle is lifted, opening the orifice. See Fig. 11.
The ECM uses inputs from the Coolant Temperature Sensor
(CTS), Throttle Position Sensor (TPS) and Mass Airflow (MAF) senso\
rs
to control the EGR orifices to make 7 different combinations for
precise EGR flow control. At idle, the EGR valve allows a very small
amount of exhaust gas to enter the intake manifold. This EGR valve
normally operates above idle speed during warm engine operation.
Verify EGR valve is present and not modified or purposely
damaged. Ensure thermal vacuum switches, pressure transducers, speed
switches, etc., (if applicable) are not by-passed or modified. Ensure
vacuum hose(s) to EGR valve is not plugged. Ensure electrical
connector to EGR valve is not disconnected.
Fig. 11: Typical Digital EGR Valve
Courtesy of General Motors Corp.
Integrated Electronic EGR Valve
This type functions similar to a ported EGR valve with a

COOLING SYSTEM BLEEDING
GASOLINE ENGINES
Air in system will collect under radiator cap. As engine
reaches operating temperature, coolant and any trapped air will enter
reserve tank. As engine cools, a vacuum will be created which will
draw only coolant into cooling system. After engine has gone through a
warm-up and cooling cycle, run engine until it again reaches operating
temperature. Ensure coolant in reserve tank is at warm coolant mark on
reserve tank or dipstick.
5.9L DIESEL ENGINE
For bleeding procedures on 5.9L diesel, see appropriate 12-
valve or 24-valve engine article in ENGINES. DO NOT operate engine
while filling cooling system.
SPECIFICATIONS
COOLING SYSTEM SPECIFICATIONS
COOLING SYSTEM SPECIFICATIONS - CARS








\









\









\









\









\









\









\







Application Specification
Avenger & Sebring Coupe
Coolant Replacement Interval ........... 30,000 Miles Or 24 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap .............................................. 16 psi
Thermostat
DOHC
Starts To Open ................................... 195
F (91C)
Fully Opens ..................................... 216F (102C)
SOHC
Starts To Open ................................... 180
F (82C)
Fully Opens ...................................... 203F (95C)
Breeze, Cirrus, Sebring Convertible & Stratus
Coolant Replacement Interval ........... 45,000 Miles Or 36 Months
Coolant Capacity
2.0L ............................................ 8.5 Qts. (8.0L)\
2.4L ............................................ 9.0 Qts. (8.5L)\
2.5L .......................................... 10.5 Qts. (10.0L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)
Concorde, Intrepid, LHS & 300M
Coolant Replacement Interval ....................... 120,000 Miles
Coolant Capacity ................................. 9.4 Qts. (8.9L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)
Neon
Coolant Replacement Interval ........... 45,000 Miles Or 36 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)

Talon
Coolant Replacement Interval ........... 30,000 Miles Or 24 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap
VIN F ................................................. 11-15 psi
VIN Y ................................................. 14-18 psi
Thermostat
Starts To Open
VIN F ............................................ 180
F (82C)
VIN Y ............................................ 195F (91C)
Fully Opens
VIN F ............................................ 203
F (95C)
VIN Y ........................................... 216F (102C)








\









\









\









\









\









\









\







COOLING SYSTEM SPECIFICATIONS - TRUCKS








\









\









\









\









\









\









\







Application Specification
Coolant Replacement Interval ............. 45,000 Miles Or 36 Months
Coolant Capacity ( 1)
Caravan, Town & Country, & Voyager
2.4L ...................................... ( 2) 11.2 Qts. (10.6L)
3.0L ...................................... ( 2) 13.0 Qts. (12.3L)
3.3L & 3.8L ............................... ( 2) 13.2 Qts. (12.5L)
Dakota
2.5L ............................................ 9.8 Qts. (9.3L)\
3.9L .......................................... 14.0 Qts. (13.2L)\
5.2L .......................................... 14.3 Qts. (13.5L)\
5.9L ................................................. 14.6L (13.7L)\
Durango
3.9L .......................................... 14.0 Qts. (13.2L)\
5.2L & 5.9L ...................................... 14.3 Qts. (13.5L)\
Ram Pickup
3.9L, 5.2L & 5.9L (Gasoline) .................. 20.0 Qts. (18.9L\
)
5.9L (Diesel) ................................. 24.0 Qts. (22.7L\
)
8.0L .......................................... 26.0 Qts. (24.6L)\
Ram Van/Wagon
3.9L ........................................... 10.4 Qts. (9.8L)\
5.2L .......................................... 13.1 Qts. (12.4L)\
5.9L
With Rear Heater ............................ 14.1 Qts. (13.3L)\
Without Rear Heater ......................... 13.1 Qts. (12.4L)\
Pressure Cap ............................................. 14-16 psi
Thermostat
Diesel Engines
Starts To Open ..................................... 181
F (83C)
Fully Open ............................................ 203F (95C)
Gasoline Engines
Starts To Open ..................................... 192
F (89C)
Fully Opens ....................................... 220F (104C)
( 1) - Capacities listed are approximate.
( 2) - Capacity includes heater and coolant recovery tank. Add 2 qts.
(1.9L) for models equipped with rear heater.









\









\









\









\









\









\









\

Fig. 2: Identifying Retainer Type Fuel Line Disconnect Fittings
Courtesy of Chrysler Corp.
ENGINE
Removal (Ram Van/Wagon)
1) Release fuel pressure. See FUEL PRESSURE RELEASE.
Disconnect negative battery cable. Drain cooling system and engine
oil. Remove and discard oil filter.
2) Remove engine cover, air cleaner and oil dipstick.
Discharge A/C system (if equipped) using approved refrigerant
recovery/recycling equipment. Disconnect A/C lines at condenser, and
plug openings. Remove A/C compressor. Disconnect fan shroud.
3) Remove front bumper, grille and support brace. Disconnect
coolant hoses. Remove radiator, condenser and support as an assembly.
4) Remove upper fan shroud. Remove power steering pump with
hoses attached, and set aside. Remove air pump, spark plug wires and
distributor cap. Disconnect necessary electrical wiring, coolant hoses
and vacuum hoses. Disconnect fuel lines. See FUEL LINE DISCONNECT

FITTINGS. Remove air cleaner, throttle body, drive belts, generator,
fan and fan pulley. Remove lower fan shroud.
CAUTION: When removing engine, DO NOT lift engine by intake manifold.
5) Remove intake manifold. See INTAKE MANIFOLD. Raise and
support vehicle. Remove starter. Remove exhaust pipe and heat shields.
Disconnect transmission shift linkage. Remove crank sensor.
6) On A/T models, remove transmission inspection cover. Mark
torque converter-to-flexplate position for installation reference.
Remove torque converter-to-flexplate bolts. On M/T models, disconnect
clutch release mechanism at clutch housing.
7) Attach engine hoist to cylinder heads (at intake manifold
flanges). On all models, support transmission using a floor jack.
Remove transmission or clutch housing-to-cylinder block bolts. Remove
engine mount bolts. Remove engine out front of vehicle.
Installation
To install, reverse removal procedure. Tighten bolts/nuts to
specification. See TORQUE SPECIFICATIONS table. On A/T models, ensure
reference marks on torque converter and flexplate are aligned.
Evacuate and charge A/C system.
Removal ( Dakota 2WD, Durango 2WD, Grand Cherokee & Ram
Pickup)
1) Release fuel pressure. See FUEL PRESSURE RELEASE.
Disconnect and remove battery. On all except Pickup, scribe hood
hinges for installation reference and remove hood.
2) On all models, drain cooling system. Disconnect coolant
hoses. Remove radiator, fan and shroud. Discharge A/C system (if
equipped) using approved refrigerant recovery/recycling equipment.
Disconnect A/C lines, and plug openings. On Pickup, remove upper core
support, transmission cooler and A/C condenser. On all models, remove
belt, air cleaner, vacuum lines, distributor cap and wiring.
3) Disconnect necessary electrical wiring. Disconnect fuel
lines. See FUEL LINE DISCONNECT FITTINGS. Remove throttle body and
linkage. Remove intake manifold. Remove starter, generator, charcoal
canister and horns. Disconnect power steering hoses (if equipped).
Raise and support vehicle. Drain oil. Disconnect exhaust pipe at
exhaust manifold.
4) On A/T models, remove transmission housing inspection
plate. Mark torque converter-to-flexplate position for installation
reference. Remove torque converter-to-flexplate bolts. Remove bracket
for transmission cooler lines.
NOTE: It may be necessary to remove manual transmission if
transmission cannot be supported using floor jack.
5) On M/T models, disconnect clutch release mechanism at
clutch housing. On all models, support transmission using a floor
jack. Remove transmission or clutch housing-to-cylinder block bolts.
Install engine lifting fixture, and attach chain.
CAUTION: When removing engine, DO NOT lift engine by intake manifold.
6) On Ram Pickup and Grand Cherokee, remove front engine
mount bolts. Remove engine from vehicle. On Dakota 2WD and Durango 2WD
models, remove front engine mount through-bolts. See Fig. 3. Remove
engine from vehicle.
Installation
To install, reverse removal procedure. Tighten bolts/nuts to
specification. See TORQUE SPECIFICATIONS table. On A/T models, ensure
