1999 CHEVROLET METRO display

yellowblue
2-10
Ignition Positions
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate controls or even make the
vehicle move. Don't leave the keys in the vehicle
with children.
With the key in the ignition
switch, you can turn the
switch to four positions.
LOCK (A): This is the only position in which you can
remove the key. This locks your steering wheel, ignition
and automatic transaxle. Press in on the key as you turn
it toward you to LOCK.If you have an automatic transaxle, the ignition switch
can't be turned to LOCK unless the shift lever is in the
PARK (P) position.
ACC (ACCESSORY) (B): In this position, you can
operate some of your electrical power accessories. It
unlocks the steering wheel and ignition. Use this
position if your vehicle must be pushed or towed.
ON (C): This is the position to which the switch returns
after you start your engine and release the switch. The
switch stays in the ON position when the engine is
running. But even when the engine is not running, you
can use ON to operate your electrical power accessories
(including the heater) and to display some instrument
panel warning lights.
START (D): This position starts the engine. When the
engine starts, release the key. The ignition switch will
return to ON for normal driving.
Note that even if the engine is not running, ACC and
ON are on positions that allow you to operate your
electrical accessories, such as the radio.
A warning tone will sound if you open the driver's door
when the ignition is in ACC or LOCK and the key is in
the ignition.

yellowblue
2-36 Speedometer and Odometer
Your speedometer lets you see your speed in both miles
per hour (mph) and kilometers per hour (km/h). Your
odometer shows how far your vehicle has been driven,
in either miles (used in the United States) or kilometers
(used in Canada).
You may wonder what happens if your vehicle needs a
new odometer installed.
If the new one can be set to the mileage total of the old
odometer, then it must be. But if it can't, then it's set to
zero and a label must be put on the driver's door to show
the old mileage reading when the new odometer
was installed.
Trip Odometer (If Equipped)
Your vehicle may be equipped with a trip odometer. The
trip odometer can tell you how far your vehicle has been
driven since you last set the trip odometer to zero.
To reset the trip odometer to zero, press the knob located
to the right of the speedometer.
Tachometer (If Equipped)
The tachometer displays the
engine speed in revolutions
per minute (rpm).
NOTICE:
Do not operate the engine with the tachometer in
the red area, or engine damage may occur.

yellowblue
3-6
Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
Press and hold RECALL (TIME SET) to set the correct
hour. At the same time, press and hold the TUNE left
arrow (H) until the correct hour appears.
Press and hold RECALL (TIME SET) to set the correct
minute. At the same time, press and hold the TUNE
right arrow (M) until the correct minute appears.
AM-FM Stereo (If Equipped)
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.

yellowblue
3-7
Finding a Station
AM´FM: Press this button to switch between AM and
FM. The display shows your selection.
TUNE: Press the right or left arrows to go to a higher or
lower station. Press and hold to continue tuning and
release when you find your station. The display will
show the frequency of each station tuned.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your previously played stations. You can
set up to 12 stations (six AM and six FM). Just:
1. Turn the radio on.
2. Press AM´FM to select the band.
3. Tune in the desired station.
4. Press one of the six pushbuttons for at least two
seconds. The sound will mute and then return when
the station is stored. Whenever you press that
numbered button, the station you set will return.
5. Repeat the steps for each pushbutton.Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Then pull the
knob all the way out. Turn the knob clockwise for the
right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise to
adjust the sound to the rear speakers and
counterclockwise for the front speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
3-8 AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control (If Equipped)
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.Finding a Station
AM´FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Press the right or left arrows to go to a higher or
lower station. Press and hold to continue tuning and
release when you find your station. The display will
show the frequency of each station tuned.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there.
PUSHBUTTONS: The six numbered pushbuttons
let you return to your previously played stations. You
can set up to 18 stations (six AM, six FM1 and six
FM2). Just:
1. Turn the radio on.
2. Press AM´FM to select the band.
3. Tune in the desired station.
4. Press one of the six pushbuttons for at least two
seconds. The sound will mute and then return when
the station is stored. Whenever you press that
numbered button, the station you set will return.
5. Repeat the steps for each pushbutton.

yellowblue
3-9
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: Press this button to choose preset bass and
treble equalization settings designed for ROCK, NEWS,
POP, JAZZ and CLASSIC. ROCK will appear when
you first press TONE. Each time you press it, another
setting will appear on the display. If you press it one
more time, after CLASSIC appears on the display, tone
control will be back to the BASS and TREB knobs.Adjusting the Speakers
BAL: Press this knob lightly so it extends. Then pull the
knob all the way out. Turn the knob clockwise for the
right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise to
adjust the sound to the rear speakers and
counterclockwise for the front speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
3-10
Playing a Cassette Tape
With the ignition and radio on, insert a cassette tape.
The tape will begin playing as soon as it is inserted.
Press EJECT or RECALL to load a tape with the
ignition off. Then insert the cassette tape. A tape symbol
is shown in the center of the graphic display whenever a
tape is inserted. When a tape is active, the tape symbol
will be accompanied by a direction arrow.
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this player.
The longer side with the tape visible should face to the
right. If you hear nothing or hear just a garbled sound, it
may not be in squarely. Press EJECT to remove the tape
and start over.
While the tape is playing, use the VOLUME, FADE,
BAL, TREB, BASS and TONE controls just as you do for
the radio. The display will show an arrow to show which
side of the tape is playing. When the down indicator arrow
is lit, selections listed on the bottom side of the cassette are
playing. When the up arrow is lit, selections listed on the
top side of the cassette are playing.
REV (TUNE): Press the left arrows to reverse the tape
rapidly. Press REV (TUNE) or TAPE to return to
playing speed.FWD (TUNE): Press the right arrows to advance
rapidly to another part of the tape. Press FWD (TUNE)
or TAPE to return to playing speed.
PREV (SEEK): Press the left arrow to go to the start of
the current selection if more than eight seconds have
played. If you hold the button or press it more than once,
the player will continue moving back through the tape.
Press the left arrow or TAPE to return to playing speed.
NEXT (SEEK): Press the right arrow to go to the start
of the next selection if more than eight seconds have
played. If you hold the button or press it more than once,
the player will continue moving forward through the
tape. Press the right arrow or TAPE to return to
playing speed.

(2): Press this button to reduce background noise
from tapes encoded with Dolby NR.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
MTL: Your bias is set automatically. MTL will appear
on your display when a metal or chrome tape is inserted.
AM´FM: Press this button to play the radio when a tape
is playing.

yellowblue
3-11
TAPE: With a tape loaded in the player and the radio
playing, press this button once to play the tape. To
switch from the tape to the radio when the tape is
playing, press the AM´FM button. Press this button to
switch from one side of the tape to the other. Your
cassette tape player can play continuously because the
player has an auto
-reverse feature.
EJECT: Press this button to remove the tape. The radio
will play.
CLEAN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold EJECT for five seconds to
reset the CLEAN indicator. The radio will display
--- to
show the indicator was reset.
AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.
