1999 CHEVROLET METRO air conditioning

yellowblue
3-2
Comfort Controls
With this system, you can control the heating and
ventilation in your vehicle. If you have the air
conditioning option, you can also control cooling.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System
Airflow Lever
VENT: This position directs the airflow through
the instrument panel vents.
BI-LEVEL: This position directs air through the
instrument panel vents and toward the floor.
FLOOR: This position directs air toward the floor.
DEFOG: This position directs air toward the
floor, the windshield and side windows.
DEFROST: This position directs air to the
windshield and side windows.
Fan Control Lever
Slide the lever away from OFF to turn the system on.
Move the lever toward the fan symbol to increase the
fan's speed.
Temperature Control Lever
Slide the lever to change the temperature of the air
flowing from the system. Move it to the right for
warmer air and to the left for cooler air. Without
optional air conditioning, the air temperature can't be
less than the outside air temperature.
Air Intake Lever
CIRCULATE: Choose this position to circulate
outside air through the comfort control system.
RECIRCULATE: Choose this position to
recirculate the inside air through the comfort
control system.

yellowblue
3-3 Air Conditioner Controls (If Equipped)
The air conditioning system
uses the same controls as
described previously. The
function of each lever is
explained under ªClimate
Control Systemº in this
part. The incoming air is
cooled and dehumidified
instead of being heated.
Push the A/C button to change your comfort control
system from heating to air conditioning. A light will
come on when the air conditioning is on. The A/C
button can also control the humidity in your vehicle.
The air conditioner works best if you keep your
windows closed. On very hot days, open the windows
just long enough for the hot air to escape.For normal cooling, push the A/C button and move the
air intake lever to CIRCULATE. For faster cooling,
move the lever to RECIRCULATE. Then move the
airflow lever to VENT, the temperature control lever
toward the left and the fan control lever toward the
fan symbol.
On days when it is raining or the humidity is high,
follow these dehumidifying steps to help clean windows
that are cloudy with moisture. Push the A/C button.
Move the air intake lever to CIRCULATE. Move the
airflow lever to DEFROST and the fan control lever
toward the fan symbol. Adjust the temperature control
lever to a comfortable setting.
Heating
For the quickest results, move the air intake lever to
RECIRCULATE. Move the airflow lever to FLOOR, the
temperature control lever toward the right for warmer
air and the fan control lever toward the fan symbol. You
should switch to CIRCULATE once in a while to avoid
stale air and cloudy windows.

6-
yellowblue
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-5 Filling Your Tank
6
-8 Filling a Portable Fuel Container
6
-8 Checking Things Under the Hood
6
-13 Engine Oil
6
-17 Engine Air Cleaner/Filter
6
-20 Automatic Transaxle Fluid
6
-23 Manual Transaxle Fluid
6
-24 Clutch Adjustment
6
-24 Radiator Pressure Cap
6
-25 Thermostat
6
-25 Engine Coolant
6
-27 Power Steering Fluid
6
-28 Windshield Washer Fluid6
-29 Brakes
6
-33 Low Maintenance Battery
6
-34 Bulb Replacement
6
-35 Headlamp Aiming
6
-40 Tires
6
-48 Appearance Care
6
-48 Cleaning the Inside of Your Vehicle
6
-50 Care of the Safety Belts
6
-52 Cleaning the Outside of Your Vehicle
6
-54 Underbody Maintenance
6
-56 Vehicle Identification Number (VIN)
6
-57 Electrical System
6
-60 Replacement Bulbs
6
-60 Capacities and Specifications
6
-61 Air Conditioning Refrigerants
6
-61 Normal Maintenance Replacement Parts

yellowblue
6-58
Fuse Useage
1 Left Headlamp,
High
-Beam Indicator
2 Right Headlamp
3 Parking Lamps, Sidemarker
Lamps, License Plate Lamps,
Instrument Cluster LightsFuse Useage
4 Door Lock System (If Equipped)
5 Hazard Lamps, Horn
6 Ignition System, Gages, Warning
and Indicator Lights, Automatic
Transaxle Speed Sensor
7 Heater, Air Conditioning
(If Equipped)
8 Stoplamps
9 Lighter, Radio
10 Back
-Up Lamps,
Turn Signal Lamps
11 Rear Defogger (If Equipped)
12 Front and Rear Wiper/Washer

yellowblue
6-60
Replacement Bulbs
Lamps Bulb Number. . . . . . . . . . . . . . . . . . . . . . . . .
Back
-Up 921. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Part No. 96059983 or equivalent
Center High
-Mounted Stoplamp 921. . . . . . . . . . . . .
GM Part No. 96059983 or equivalent
Dome GM Part No. 94153335. . . . . . . . . . . . . . . . . . .
Front Parking and Sidemarker 168. . . . . . . . . . . . . . .
GM Part No. 96053293 or equivalent
Headlamp (Halogen) GM Part No. 9441731 . . . . . . .
or GM Part No. 91171148 or equivalent
License Plate 168. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Stop/Tail 1157. . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Hazard (Front and Rear) 1156. . . . .
Capacities and Specifications
The following approximate capacities are given in U.S.
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Automatic Transaxle
Drain and Refill 1.6 quarts (1.5 L)**. . . . . . . . . . . . .
Manual Transaxle2.5 quarts (2.4 L)** . . . . . . . . . .
Cooling System
Automatic Transaxle
VIN Engine Code 2 5.0 quarts (4.7 L). . . . . . . . . . . .
Manual Transaxle
VIN Engine Code 6 4.1 quarts (3.9 L). . . . . . . . . . . .
VIN Engine Code 2 4.9 quarts (4.6 L). . . . . . . . . . . .
Crankcase
(With Filter Change)3.5 quarts (3.3 L)* . . . . . . .
Fuel Tank10.6 gallons (40.0 L) . . . . . . . . . . . . . . . . .
Wheel Nut Torque45 lb
-ft (60 N´m) . . . . . . . . . . . .
Air Conditioning

See the refrigerant information label under the hood.

See ªAir Conditioning Refrigerantsº later in
this section.

yellowblue
6-61
*When changing the oil filter, additional oil may be
needed. Recheck the oil level after filling. See ªEngine
Oilº in the Index.
**Recheck the fluid level after filling. See ªAutomatic
Transaxle Fluidº or ªManual Transaxle Fluidº in
the Index.
Engine Specifications
Type
VIN Engine Code 6 L3. . . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code 2 L4. . . . . . . . . . . . . . . . . . . . . . .
Firing Order
VIN Engine Code 6 1
-3-2 . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code 2 1
-3-4-2 . . . . . . . . . . . . . . . . . . .
Horsepower
VIN Engine Code 6 55 hp @ 5700 rpm. . . . . . . . . .
VIN Engine Code 2 79 hp @ 6000 rpm. . . . . . . . . .
Fuel DeliveryFuel Injection . . . . . . . . . . . . . . . . . . .
Piston Displacement
VIN Engine Code 6 61 CID (1.0L). . . . . . . . . . . . . .
VIN Engine Code 2 79 CID (1.3L). . . . . . . . . . . . . .
Valve ArrangementIn
-Head . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
See the refrigerant charge label under the hood for
information regarding refrigerant capacity.
Normal Maintenance
Replacement Parts
Air Cleaner Filter AC Type A1203C. . . . . . . . . . . . . .
Battery 26R
-50S . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF53. . . . . . . . . . . . . . . .
Fuel Filter GM Part No. 96068664 or equivalent. . . . .
PCV Valve GM Part No. 96051849. . . . . . . . . . . . . . .
Radiator Pressure Cap 13 psi (90 kPa). . . . . . . . . . . .
Spark Plugs
1.0L L3 Engine AC Type R42XLS. . . . . . . . . . . . . . .
0.039 to 0.045 inch gap (1.0 to 1.1 mm)
1.3L L4 Engine NGK Type BKR6E11. . . . . . . . . . . .
0.039 to 0.045 inch gap (1.0 to 1.1 mm)
1.3L L4 Engine Denso Type K20PR
-U11 . . . . . . . . .
0.039 to 0.045 inch gap (1.0 to 1.1 mm)

yellowblue
7-42
Part C: Periodic Maintenance
Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's
service department or other qualified service center do
these jobs. Make sure any necessary repairs are
completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and
Front-Wheel-Drive Axle Boot and
Seal Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts, signs of
wear, or lack of lubrication. Inspect power steering lines
and hoses for proper hook
-up, binding, leaks, cracks,
chafing, etc. Check for seal leakage. Clean and then
inspect the drive axle boot seals for damage, tears or
leakage. Replace seals if necessary. Check final drive
axle output shaft seals for leakage.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body
near the exhaust system. Look for broken, damaged,
missing or out
-of-position parts as well as open seams,
holes, loose connections or other conditions which could
cause a heat build
-up in the floor pan or could let
exhaust fumes into the vehicle. See ªEngine Exhaustº in
the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.
Throttle System Inspection
Inspect the throttle system for interference or binding,
and for damaged or missing parts. Replace parts as
needed. Replace any components that have high effort
or excessive wear. Do not lubricate accelerator and
cruise control cables.

9-
yellowblue
9-1
Section 9 Index
A
dding Equipment to the Outside of Your Vehicle 6-3 . . . . .
Air Bag 1-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-25 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-22, 2-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-25 . . . . . . . . . . . . . . .
When Should it Inflate 1-24 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioner Controls 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-60, 6-61 . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-46 . . . . . . . . . . . . . . . . . . . . . .
Antenna 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock
Brake System Active Light 2-41, 4-9 . . . . . . . . . . . . . . . . .
Brake System Warning Light 2-40, 4-7 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care Materials 6-55 . . . . . . . . . . . . . . . . . . . . . . .
Arbitration Program 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Automatic
Starting Your Engine 2
-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle 2-11, 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Check 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Fluid 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Operation 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Park Mechanism Check 7-41 . . . . . . . . . . . . . . . .
Battery 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Leaving on a Long Trip 4-22 . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 8-4 . . . . . . . . . . . . . . . . . . .
Blizzard 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-33 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-39 . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock 2-21 . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 7-40 . . . . . . . . . . . . . . . . . .
Wear 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
