1999 CHEVROLET METRO fuse box

yellowblue
2-33
1. Rear Window Wiper Switch (If Equipped)
2. Turn Signal/Multifunction Lever
3. Air Vent
4. Brightness Control
5. Horn
6. Hazard Warning Flasher
7. Instrument Cluster
8. Ignition Switch
9. Windshield Wiper/Washer Lever
10. Coinholder
11. Comfort Controls
12. Side Defroster Vent13. Glove Box
14. Audio System
15. Cigarette Lighter
16. Cupholder
17. Storage Compartment
18. Parking Brake Lever
19. Transaxle Shift Lever
20. Ashtray
21. Fuse Block
22. Hood Release
23. Rear Window Defogger Switch
24. Rear Window Washer Switch (If Equipped)

yellowblue
6-11 1.0L L3 Engine
When you lift the hood, you'll see these items:
A. Hood Prop
B. Engine Oil Dipstick
C. Engine Air Cleaner/Filter
D. Engine Oil Fill CapE. Radiator Pressure Cap
F. Brake Fluid Reservoir
G. Engine Coolant ReservoirH. Battery
I. Main Fuse Box
J. Windshield Washer Reservoir

yellowblue
6-12 1.3L L4 Engine
When you lift the hood, you'll see these items:
A. Hood Prop
B. Power Steering Reservoir
C. Engine Air Cleaner/Filter
D. Engine Oil DipstickE. Engine Oil Fill Cap
F. Electric Engine Cooling Fan
G. Radiator Pressure Cap
H. Brake Fluid ReservoirI. Engine Coolant Reservoir
J. Battery
K. Main Fuse Box
L. Windshield Washer Reservoir

yellowblue
6-57
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment can
keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Windshield Wiper Fuses
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If
the overload is caused by some electrical problem and
not snow, etc., be sure to get it fixed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by fuses, circuit breakers and thermal links
in the wiring itself. This greatly reduces the chance of
fires caused by electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the correct size.
If you ever have a problem on the road and don't have a
spare fuse, you can borrow one. Just pick some feature
of your vehicle that you can get along without
-- like the
radio or cigarette lighter
-- and use its fuse, if it is the
size you need. Replace it as soon as you can. Before
replacing a fuse, turn every vehicle electrical switch off.
There are two fuse blocks in your vehicle: the engine
compartment fuse block and the instrument panel
fuse block.
Instrument Panel Fuse Block
This fuse box is under the left side of the instrument
panel. To open it, squeeze the short sides and pull off the
cover. The fuses here protect each separate circuit
including headlamps. If you have electrical failure,
check here first.

yellowblue
6-59
Engine Compartment Fuse Block
The main fuse box is in your engine compartment on the
driver's side. It protects all electrical loads.
For access to the main fuses, squeeze the tabs on the
sides and pull off the cover.
Fuse Useage
BATT All Electrical Load
ABS ABS System
IG Accessory, Ignition, Windshield
Wipers, Defrost/Defog, Heater,
Back
-Up Lamps
LAMP Taillamps, Stoplamps, Hazard,
Headlamps (right and left)
PTC PTC Heater
FI Fuel Injection
RDTR Radiator Fan Motor
A/C Air Conditioner
