1999 CHEVROLET METRO steering

yellowblue
6-27
Adding Coolant
If you need more coolant, add the proper coolant
mixture at the coolant recovery tank, but be careful not
to spill it.
CAUTION:
Turning the radiator pressure cap when the engine
and radiator are hot can allow steam and scalding
liquids to blow out and burn you badly. With the
coolant recovery tank, you will almost never have
to add coolant at the radiator. Never turn the
radiator pressure cap
-- even a little -- when the
engine and radiator are hot.
CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol,
and it will burn if the engine parts are hot
enough. Don't spill coolant on a hot engine.
Power Steering Fluid
When to Check Power Steering Fluid
It is not necessary to regularly check power steering
fluid unless you suspect there is a leak in the system or
you hear an unusual noise. A fluid loss in this system
could indicate a problem. Have the system inspected
and repaired.

yellowblue
6-28 How To Check Power Steering Fluid
You can check your fluid without taking the cap off. Just
look at the reservoir.

When the engine compartment is hot, the level
should be between the HOT marks.

When the engine compartment is cool, the level
should be between the COLD marks.
What to Use
To determine what kind of fluid to use, see
ªRecommended Fluids and Lubricantsº in the Index.
NOTICE:
When adding power steering fluid or making a
complete fluid change, always use the proper
fluid. Failure to use the proper fluid can cause
leaks and damage hoses and seals.
Windshield Washer Fluid
What to Use
When you need windshield washer fluid, be sure to read
the manufacturer's instructions before use. If you will be
operating your vehicle in an area where the temperature
may fall below freezing, use a fluid that has sufficient
protection against freezing.
Adding Washer Fluid

yellowblue
7-42
Part C: Periodic Maintenance
Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's
service department or other qualified service center do
these jobs. Make sure any necessary repairs are
completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and
Front-Wheel-Drive Axle Boot and
Seal Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts, signs of
wear, or lack of lubrication. Inspect power steering lines
and hoses for proper hook
-up, binding, leaks, cracks,
chafing, etc. Check for seal leakage. Clean and then
inspect the drive axle boot seals for damage, tears or
leakage. Replace seals if necessary. Check final drive
axle output shaft seals for leakage.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body
near the exhaust system. Look for broken, damaged,
missing or out
-of-position parts as well as open seams,
holes, loose connections or other conditions which could
cause a heat build
-up in the floor pan or could let
exhaust fumes into the vehicle. See ªEngine Exhaustº in
the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.
Throttle System Inspection
Inspect the throttle system for interference or binding,
and for damaged or missing parts. Replace parts as
needed. Replace any components that have high effort
or excessive wear. Do not lubricate accelerator and
cruise control cables.

yellowblue
7-44
Part D: Recommended Fluids
and Lubricants
NOTE: Fluids and lubricants identified below by name,
part number or specification may be obtained from
your dealer.
USAGE
FLUID/LUBRICANT
Engine OilEngine Oil with the American
Petroleum Institute Certified For
Gasoline Engines ªStarburstº
symbol of the proper viscosity. To
determine the preferred viscosity
for your vehicle's engine, see
ªEngine Oilº in the Index.
Engine Coolant50/50 mixture of clean, drinkable
water and good quality Ethylene
Glycol Base Coolant (GM Part
No. 1052753 or equivalent)
conforming to GM Specification
1825M or approved recycled
coolant conforming to GM
Specification 1825M. See ªEngine
Coolantº in the Index.
USAGEFLUID/LUBRICANT
Hydraulic Brake
SystemDelco Supreme 11
Brake Fluid
(GM Part No. 12377967 or
equivalent DOT
-3 Brake Fluid).
Windshield
Washer SolventGM Optikleen
Washer Solvent
(GM Part No. 1051515)
or equivalent.
Parking Brake
Cable GuidesChassis Lubricant (GM Part
No. 12377985 or equivalent) or
lubricant meeting requirements of
NLGI # 2, Category LB
or GC
-LB.
Power Steering
SystemDEXRON
-III Automatic
Transmission Fluid.
Manual
TransaxleGM Goodwrench Synthetic
Manual Transmission Fluid (GM
Part No. 12346190
- 1 quart) or
equivalent SAE 75W
-85 GL-4
Gear Oil.
Automatic
TransaxleDEXRON
-III Automatic
Transmission Fluid.

yellowblue
8-12
CURRENT PUBLICATIONS FOR 1999 CHEVROLET
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $20.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $15.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 CHEVROLET SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

yellowblue
9-5
Steering 7-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Cluster 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard Cluster 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components, Cleaning 6-50 . . . . . . . . . . . . . .
Jack, Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-39 . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-56 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-33 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-56 . . . . . . . . . . . . . . . . . . .
Lamps 2-27, 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Latches, Seatback 1
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle With the Engine Running 2-20 . . . . . . .
Lid Release, Hatchback 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lid Release, Remote 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighter 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-22, 2-37 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Active 2-41, 4-9 . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-40, 4-7 . . . . . . . . . . . .
Brake System Warning 2-39 . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps Indicator 2-45 . . . . . . . . . . . . . . .
Engine Oil Pressure Light 2-44, 6-13 . . . . . . . . . . . . . . . . .
Interior 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-9, 2-37 . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift 2-17, 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cylinders 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Automatic Transaxle Check 7-41 . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-39 . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Security 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Long Trip, Before Leaving 4-22 . . . . . . . . . . . . . . . . . . . . . . .
Low Gear, Automatic Transaxle 2-15 . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-39 . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-7
Power
Door Locks 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Fluid 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pregnancy, Use of Safety Belts 1-20 . . . . . . . . . . . . . . . . . . . .
Problems on the Road 5-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Publications, Service and Owner 8-11, 8-12 . . . . . . . . . . . . . .
Radiator 5-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Pressure Cap 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio Reception 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radios
AM
-FM Stereo 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
Rain, Driving In 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear
Door Security Locks 2
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Passengers 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Window Defogger 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rearview Mirrors 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Adjust 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Remote Control 2-29 . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front Seatbacks 1-3 . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-44 . . . . . . . . . . . . . . .
Recovery Tank, Coolant 5-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recreational Vehicle Towing 4-29 . . . . . . . . . . . . . . . . . . . . . .
Refrigerants, Air Conditioning 6-60, 6-61 . . . . . . . . . . . . . . .
Remote Lid Release 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Replacement
Bulbs 6
-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Safety Belts 1-49 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reporting Safety Defects 8-10 . . . . . . . . . . . . . . . . . . . . . . . . .
Restraints
Checking 1
-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child 1-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Parts After a Crash 1-49 . . . . . . . . . . . . . . . . . . .
System Check 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reverse
Automatic Transaxle 2
-14 . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Transaxle 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-21 . . . . . . . . . . . . . . . . . . . .
Roadside Assistance 8-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Roadside Assistance, Canadian 8-7 . . . . . . . . . . . . . . . . . . . . .
Rocking Your Vehicle 5-31 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rotation, Tires 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Extender 1-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belts 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adults 1-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Care 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Children 1-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver Position 1-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Extender 1-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Wear Properly 1-14 . . . . . . . . . . . . . . . . . . . . . . . . .
Incorrect Usage 1-16, 1-17, 1-18, 1-19, 1-46, 1-47 . . . . .
Lap-Shoulder 1-14, 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Larger Children 1-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Questions and Answers 1-13 . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-8
Safety Belts (Continued)
Rear Seat Passengers 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reminder Light 1-9, 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing After a Crash 1-49 . . . . . . . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-21 . . . . . . . . . . . . . . . . . .
Smaller Children and Babies 1-32 . . . . . . . . . . . . . . . . . . . .
Use During Pregnancy 1-20 . . . . . . . . . . . . . . . . . . . . . . . . .
Why They Work 1-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Defects, Reporting 8-10 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Warnings and Symbols vi. . . . . . . . . . . . . . . . . . . . . . .
Scheduled Maintenance Services 7
-4 . . . . . . . . . . . . . . . . . . . .
Seatback
Folding Rear 1
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats
Easy Entry 1
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Front 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Restraint Systems 1-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Controls 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing a Child Restraint 1-40, 1-43 . . . . . . . . . . . . . . . . .
Second Gear
Automatic Transaxle 2
-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Transaxle 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 6-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulletins, Ordering 8-11, 8-12 . . . . . . . . . . . . . . . . . . . . . . .
Engine Soon Light 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manuals, Ordering 8-11, 8-12 . . . . . . . . . . . . . . . . . . . . . . .
Parts Identification Label 6-56 . . . . . . . . . . . . . . . . . . . . . . .
Publications, Ordering 8-11, 8-12 . . . . . . . . . . . . . . . . . . . .
Work, Doing Your Own 6-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Appearance Care 6-1 . . . . . . . . . . . . . . . . . . . . . . Service and Owner Publications 8
-11, 8-12 . . . . . . . . . . . . . .
Service Publications 8-11, 8-12 . . . . . . . . . . . . . . . . . . . . . . . .
Servicing Your Air Bag-Equipped Chevrolet 1-27 . . . . . . . . .
Sheet Metal Damage 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lever 2-13, 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Light 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting
Automatic Transaxle 2
-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Into Park (P) 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Transaxle 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of Park 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signaling Turns 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding 3-15 . . . . . . . . . . . . . . . . . . . . . . . .
Spare Tire, Compact 5-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications and Capacities 6-60 . . . . . . . . . . . . . . . . . . . . . .
Specifications, Engine 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . . .
Speedometer 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains, Cleaning 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starter Switch Check 7-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steam 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage, Vehicle 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-31 . . . . . . . . . . . . . . . . . .
Sun Visors 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle viii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
