Page 9 of 344
1-
yellowblue
1-1
Section 1 Seats and Seat Restraints
Here you'll find information about the seats in your vehicle and how to use your safety belts properly. You can also
learn about some things you should not do with air bags and safety belts.
1
-2 Seats and Seat Controls
1
-6 Safety Belts: They're for Everyone
1
-10 Here Are Questions Many People Ask About
Safety Belts
-- and the Answers
1
-11 How to Wear Safety Belts Properly
1
-12 Driver Position
1
-19 Safety Belt Use During Pregnancy
1
-20 Right Front Passenger Position
1
-20 Supplemental Restraint System (SRS)
1
-26 Rear Seat Passengers1
-30 Rear Safety Belt Comfort Guides for
Children and Small Adults
1
-32 Center Passenger Position
1
-34 Children
1
-37 Child Restraints
1
-50 Larger Children
1
-53 Safety Belt Extender
1
-53 Checking Your Restraint Systems
1
-53 Replacing Restraint System Parts
After a Crash
Page 10 of 344
yellowblue
1-2
Seats and Seat Controls
This section tells you about the seats -- how to adjust
them
-- and also about reclining seatbacks and
head restraints.
Manual Seats
CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver's seat while the vehicle is
moving. The sudden movement could startle and
confuse you, or make you push a pedal when you
don't want to. Adjust the driver's seat only when
the vehicle is not moving.
Lift the lever under the front seat to unlock it. Slide the
seat to where you want it. Then release the lever and try
to move the seat with your body, to make sure the seat is
locked into place.
Page 11 of 344
yellowblue
1-3 6-Way Power Seat (If Equipped)
The power seat button is located on the lower left side of
the driver's seat. This button allows you to move the
seat up, down, forward and backward. It will also move
the front of the seat up or down and the rear of the seat
up or down.Move the seat higher by lifting and holding the bottom
of the button. Lower the seat by pushing and holding the
top of the button.
To move the seat forward, push the rear of the button
forward. To move the seat backward, push the front of
the button rearward.
Raise the front of the seat by lifting and holding the
bottom front end of the button. Lower the front of the
seat by pushing and holding the top front of the button.
Raise the rear of the seat by lifting and holding the
bottom rear of the button. Lower the rear of the seat by
pushing and holding the top rear of the button.
Page 12 of 344
yellowblue
1-4 Reclining Front Seatbacks
To adjust the seatback, lift the lever on the outer side of
the seat and move the seatback to where you want it.
Release the lever and ensure the handle returns to the
original position and the seatback is securely locked.
Pull up on the lever and the seat will go to an
upright position.But don't have a seatback reclined if your vehicle
is moving.
Page 13 of 344

yellowblue
1-5
CAUTION:
Sitting in a reclined position when your vehicle is
in motion can be dangerous. Even if you buckle
up, your safety belts can't do their job when
you're reclined like this.
The shoulder belt can't do its job because it
won't be against your body. Instead, it will be in
front of you. In a crash you could go into it,
receiving neck or other injuries.
The lap belt can't do its job either. In a crash the
belt could go up over your abdomen. The belt
forces would be there, not at your pelvic bones.
This could cause serious internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit well
back in the seat and wear your safety belt properly.
Head Restraints
Slide the head restraint up or down so that the top of the
restraint is closest to the top of your ears. This position
reduces the chance of a neck injury in a crash.
Rear Seats
Folding Rear Seat
To open the folding rear seat, open the trunk and pull
one or both of the tethers located on the left side of the
trunk. The left
-hand tether will open the larger side of
the seatback. The right
-hand tether will open the smaller
side of the seatback. Once a tether is pulled, the seatback
can be pushed open through the trunk, or pulled open
from inside the vehicle.
To close the split folding rear seat, push the seatback up
until you hear a click. Then pull on the seatback to make
sure it is secure.
Page 14 of 344

yellowblue
1-6
Safety Belts: They're for Everyone
This part of the manual tells you how to use safety belts
properly. It also tells you some things you should not do
with safety belts.
And it explains the Supplemental Restraint System
(SRS), or air bag system.
CAUTION:
Don't let anyone ride where he or she can't wear
a safety belt properly. If you are in a crash and
you're not wearing a safety belt, your injuries
can be much worse. You can hit things inside the
vehicle or be ejected from it. You can be seriously
injured or killed. In the same crash, you might
not be if you are buckled up. Always fasten your
safety belt, and check that your passengers' belts
are fastened properly too.
CAUTION:
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed. Do not allow people to
ride in any area of your vehicle that is not
equipped with seats and safety belts. Be sure
everyone in your vehicle is in a seat and using a
safety belt properly.
Your vehicle has a light that
comes on as a reminder to
buckle up. (See ªSafety Belt
Reminder Lightº in
the Index.)
Page 15 of 344
yellowblue
1-7
In most states and Canadian provinces, the law says to
wear safety belts. Here's why: They work.
You never know if you'll be in a crash. If you do have a
crash, you don't know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up a person wouldn't survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without belts they could have been badly hurt
or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up does
matter ... a lot!Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it's just a seat
on wheels.
Page 16 of 344
yellowblue
1-8
Put someone on it.Get it up to speed. Then stop the vehicle. The rider
doesn't stop.
