1999 CHEVROLET LUMINA Owners Manual

yellowblue
6-61
Fuse Description
F/INJN Fuel Injectors
PCM IGN Mass Air Flow (MAF) Sensor
Heated Oxygen Sensor #1 and #2
Evaporative Emissions (EVAP)
Canister Purge Solenoid Valve
ELEK IGN Electronic Ignition (EI)
Control Module
10 I/P Fuse Block
12 Passenger's Side Underhood
Electrical Center, IGN SYST Relay,
R/CMPT REL fuse, PCM BAT fuse
13 FAN CONT #1 Relay
Relay Description
14 FUEL PUMP
15 A/C CMPR
16 FAN CONT #2
-- Secondary
Cooling Fan (Passenger's Side)
17 FAN CONT #1
-- Primary Cooling
Fan (Driver's Side)
18 IGN SYSTUnderhood Electrical Center
-- Driver's Side

yellowblue
6-62
Fuse Description
FAN #3 FAN #3 Relay
PARK LPS Headlamp Switch
HORN Horn Relay
ABS Anti
-Lock Brake System
11 Circuit Breaker C, Starter Relay,
STR WHL Control # 2,
Power Accessory #2, and
Theft
-Deterrent RelayFuse Description
12 HD LPS
-- Circuit Breaker to
Headlamp Switch
13 ABS
-- ABS Relay
Relay Description
14 ABS
-- Anti-Lock Brake System
15 FAN #3
-- Secondary Cooling Fan
(Passenger's Side)
16 HORN
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-Up 3156 or 3057. . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp 891T2. . . . . . . . . . .
Front Parking/Turn Signal 3357NA. . . . . . . . . . . . . . .
Headlamp, High
-Beam 9005. . . . . . . . . . . . . . . . . . .
Headlamp, Low
-Beam 9006. . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb Number
Dome 10230955. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
Chevrolet dealer service department.

yellowblue
6-63
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
4T60E:
Automatic Transaxle
Pan Removal and Replacement 7.0 quarts (6.7 L). . .
After Complete Overhaul 9.6 quarts (9.2 L). . . . . . . .
4T65E:
Automatic Transaxle
Pan Removal and Replacement 7.4 quarts (7.0 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
When draining/replacing converter, more fluid will
be needed.
Cooling System Including Reservoir
3100 (Code M) V6 11.6 quarts (10.9 L). . . . . . . . . . . .
3800 (Code K) V6 11.7 quarts (11.0 L). . . . . . . . . . . . Refrigerant (R
-134a),
Air Conditioning*1.88 lbs. (0.85 kg) . . . . . . . . . . . .
Engine Crankcase
- Oil and
Filter Change
3100 (Code M) V6 4.5 quarts (4.3 L). . . . . . . . . . . . .
3800 (Code K) V6 4.5 quarts (4.3 L). . . . . . . . . . . . .
Fuel Tank
3100 (Code M) V6 16.6 gallons (62.8 L). . . . . . . . . . .
3800 (Code K) V6 16.6 gallons (62.8 L). . . . . . . . . . .
*See ªAir Conditioning Refrigerantsº later in
this section.
Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.

yellowblue
6-64 Engine Specifications
3100 (Code M) V6 3800 (Code K) V6. . . . . . . . . . . . . . . . . . . . . .
Type V6 V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID 231 CID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compression Ratio 9.6:1 9.25:1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-61-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) 195
F (91
C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 160 @ 5200 200 @ 5200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
6-65
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
All Engines A1208C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery
3100 (Code M) V6 600 CCA. . . . . . . . . . . . . . . . . .
3800 (Code K) V6 690 CCA. . . . . . . . . . . . . . . . . . .
Engine Oil Filter
3100 (Code M) V6 PF47. . . . . . . . . . . . . . . . . . . . .
3800 (Code K) V6 PF47. . . . . . . . . . . . . . . . . . . . . .
PCV Valve
3100 (Code M) V6 CV892C. . . . . . . . . . . . . . . . . . . . Radiator Cap
All Engines RC27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plugs
3100 (Code M) V6 AC Type 41
-940 . . . . . . . . . . . . . .
Gap: 0.060 inches (.152 cm)
3800 (Code K) V6 AC Type 41
-921 . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
Windshield Wiper
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Type hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 107.5 inches (273.0 cm). . . . . . . . . . . . . .
Tread Width (Front) 59.5 inches (151.2 cm). . . . . . . .
Tread Width (Rear) 59.1 inches (150.0 cm). . . . . . . .
Length 200.9 inches (510.4 cm). . . . . . . . . . . . . . . . .
Width 72.5 inches (184.1 cm). . . . . . . . . . . . . . . . . . .
Height 54.8 inches (139.2 cm). . . . . . . . . . . . . . . . . . .

yellowblue
6-66
-NOTES

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance
7
-13 Part B: Owner Checks and Services7
-17 Part C: Periodic Maintenance Inspections
7
-19 Part D: Recommended Fluids and Lubricants
7
-20 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
