Page 321 of 352
yellowblue
6-61
Name Circuits Protected
GLOW
PLUGNot Used
HORN Horn, Underhood Lamp
AUX FAN Auxiliary Fan
ECM
-1 Injectors, PCM/VCM
HTD ST
-FR Heated Front Seats
A/C Air Conditioning
HTD MIR Heated Outside Mirrors
ENG
-1 Ignition Switch, EGR,
Canister Purge, EVRV Idle Coast
Solenoid, Heated O
2
HTD ST-RR Heated Rear Seats
AUX B Trailer WiringName Circuits Protected
AUX A SEO Wiring
LIGHTING Headlamp and Panel Dimmer
Switch, Fog and Courtesy Fuses
BATT Battery, Fuse Block Busbar
IGN A Ignition Switch
IGN B Ignition Switch
ABS Anti
-Lock Brake Module
BLOWER Hi Blower and Rear Blower Relays
STOP/HAZ Stoplamps
HEATED
SEATSHeated Seats
Page 322 of 352
yellowblue
6-62
Replacement Bulbs
LAMP OR BULB TRADE NO. POWER RATING AT 12.8V, WATTS QTY
HEADLAMPS
Low Beam 9006 HB4 55 2
High Beam 9005 HB3 65 2
LAMP OR BULB TRADE NO. QTY
EXTERIOR
Front Marker Lamp 194 2
Front Parking and Turn Lamp 2357NA 4
Rear Parking Lamp 3057 2
Rear Stop and Turn Lamp 3057 2
Back
-up Lamp3156 2
License Plate Lamp 194 2
Underhood Lamp 93 1
Fog Lamp 894 2
Page 323 of 352
yellowblue
6-63
LAMP OR BULB TRADE NO. QTY
INTERIOR
Dome Lamps 211
-22
Reading Lamps 211
-24
Roof Console Lamps* 168 2
Door Courtesy Lamp 194 2
Instrument Panel Compartment Lamp 194 1
Ashtray Lamp 194 1
Sunshade Vanity Mirror 74 4
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Maintenance Schedule booklet for
more information.
Engine Identification
EngineªVORTECº 5700
Type V8
RPO Code L31
VIN Code R
Fuel System SFI*
*Sequential Fuel Injection
Page 324 of 352
yellowblue
6-64 Wheels and Tires
MODEL DESCRIPTION TORQUE
K 1500 6 bolts (14 mm) 140 lb
-ft (190 N´m)
Tire Pressure See the Certification/Tire label on
the rear edge of the driver's door.
Cooling System Capacity (Approximate)
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
ENGINE VIN QTY
ªVORTECº 5700 V8 R 17.5 Quarts (16.5 L)
Crankcase Capacity (Approximate)
After refill, the level must be rechecked. See ªEngine Oilº in the Index.
ENGINE VIN QUANTITY WITH FILTER
ªVORTECº 5700 V8 R 5.0 Quarts (4.8 L)
Oil filter should be changed at every oil change.
Page 325 of 352

yellowblue
6-65 Fuel Tank Capacity (Approximate)
Quantity 30.0 Gallons (113.0 L)
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
See refrigerant charge label under the hood for charge
capacity information and requirements.
Normal Maintenance
Replacement Parts
Replacement part numbers listed in this section are
based on the latest information available at the time of
printing, and are subject to change. If a part listed in this
manual is not the same as the part used in your vehicle
when it was built, or if you have any questions, please
contact your Cadillac dealer.
Oil Filter AC Type PF52
Engine Air
Cleaner/FilterAC Type A1300C
Spark Plugs AC Type 41
-932Spark Plug Gap 0.060 in. (1.52 mm)
Fuel Filter AC Type GF626
Wiper Blades
(Front)GM Part No. 22154886
Wiper Blade
Type (Front)Trico
Wiper Blade
Length (Front)18.0 inches (45.0 cm)
Wiper Blade
(Rear)GM Part No. 22154396
Wiper Blade
Type (Rear)Trico
Wiper Blade
Length (Rear)14.0 inches (35.5 cm)
A1301C high
-capacity air cleaner filter.
Page 326 of 352
Page 327 of 352
7-
yellowblue
7-1
Section 7 Customer Assistance Information
Here you will find out how to contact Cadillac if you need assistance. This section also tells you how to obtain service
publications and how to report any safety defects.
7
-2 Customer Satisfaction Procedure
7
-3 Customer Assistance for Text Telephone
(TTY) Users
7
-4 Customer Assistance Offices
7
-5 GM Mobility Program for Persons
with Disabilities
7
-5 Roadside Service
7
-7 Roadside Service for the Hearing or
Speech Impaired
7
-8 Courtesy Transportation
7
-8 Transportation Options7
-10 Warranty Information
7
-10 Reporting Safety Defects to the United
States Government
7
-11 Reporting Safety Defects to the
Canadian Government
7
-11 Reporting Safety Defects to
General Motors
7
-11 Ordering Service and Owner Publications
in Canada
Page 328 of 352

yellowblue
7-2
Customer Satisfaction Procedure
Your satisfaction and goodwill are important to your
dealer and to Cadillac. Normally, any concerns with the
sales transaction or the operation of your vehicle will be
resolved by your dealer's sales or service departments.
Sometimes, however, despite the best intentions of all
concerned, misunderstandings can occur. If your
concern has not been resolved to your satisfaction, the
following steps should be taken:STEP ONE -- Discuss your concern with a member of
dealership management. Normally, concerns can be
quickly resolved at that level. If the matter has already
been reviewed with the sales, service or parts manager,
contact the owner of the dealership or the general manager.
STEP TWO -- If after contacting a member of
dealership management, it appears your concern cannot be
resolved by the dealership without further help, contact
the Cadillac Customer Assistance Center, 24 hours a day, by
calling 1-800-458-8006. In Canada, contact GM of Canada
Customer Communication Centre in Oshawa by calling
1-800-263-3777 (English) or 1-800-263-7854 (French).
We encourage you to call the toll-free number in order
to give your inquiry prompt attention. Please have the
following information available to give the Customer
Assistance Representative:
Vehicle Identification Number (This is available
from the vehicle registration or title, or the plate
at the top left of the instrument panel and visible
through the windshield.)
Dealership name and location
Vehicle delivery date and present mileage
