1999 CADILLAC ESCALADE Owners Manual

yellowblue
2-9
3. Turn the ignition from OFF to RUN three times
quickly (within five seconds). The vehicle will
respond by locking the doors, unlocking the driver's
doors and releasing the tailgate or panel doors. Your
transmitter is now ready to match the vehicle.
4. Press and hold the LOCK and UNLOCK buttons on
the first transmitter for 15 seconds. The vehicle will
respond as in Step 3.
5. Repeat Step 4 for the remaining transmitters.
6. When you have finished matching all of your
transmitters, replace the RADIO fuse (Fuse 17).
7. Check that all transmitters work by pressing
their buttons.
If the transmitters don't work, or if you'd rather not
match the transmitters yourself, see your dealer.Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to touch
any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.
Use one three volt, type CR2032, or equivalent battery.

yellowblue
2-10
To replace the battery:
1. Insert a small coin, or flathead screwdriver, to
separate the bottom of the transmitter from the top.
2. Remove the battery and replace it with a new one,
making sure the positive (+) side of the battery is
facing down.
3. Snap the top and bottom together.
4. Test the operation of the transmitter with your
vehicle. If the transmitter does not work, try
synchronizing the transmitter with the receiver.
Resynchronization
Resynchronization may be necessary due to the security
method used by this system. The transmitter does not
send the same signal twice to the receiver. The receiver
will not respond to a signal it has been sent previously.
This prevents anyone from recording and playing back
the signal from the transmitter.
To resynchronize your transmitter, stand close to your
vehicle and simultaneously press and hold the LOCK
and UNLOCK buttons on the transmitter for at least
eight seconds. The door locks should cycle and the
parking lamps and headlamps should flash to confirm
synchronization. If this does not happen, you may need
to replace the battery in your transmitter or match the
transmitter to your vehicle. If the locks still do not cycle,
see your dealer for service.

yellowblue
2-11
Rear Doors
CAUTION:
It can be dangerous to drive with the tailgate
glass, tailgate or rear doors open because carbon
monoxide (CO) gas can come into your vehicle.
You can't see or smell CO. It can cause
unconsciousness and even death.
If you must drive with the tailgate glass, tailgate
or rear doors open or if electrical wiring or other
cable connections must pass through the seal
between the body and the tailgate glass, tailgate
or rear doors:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on VENT. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Tailgate Glass and Tailgate (If Equipped)
If your vehicle has a tailgate, you must raise the rear
glass before lowering the tailgate.
Use your key to open the glass from the outside. Then
lift the glass up.
To release the glass from the inside, use the electric
tailgate glass release switch on the instrument panel.
For more information, see ªTailgate, Glass Releaseº
in the Index.
To open the tailgate, lift up on the handle while pulling
the tailgate toward you.
Close the tailgate before closing the rear glass. After
closing the tailgate, make sure the tailgate is securely
latched by pulling it toward you. After closing the rear
glass, pull up on its handle to make sure it is locked.
Panel Doors (If Equipped)
To open the rear panel doors, you must open the
passenger's side panel door first. If the door is locked,
use your key to unlock it.
To open the passenger's side panel door, pull up on the
handle and pull the door open.

yellowblue
2-12
To open the driver's side door, first open the passenger's
side panel door. Then, pull the handle on the left door
edge outward and pull the door open.
The rear doors have a check assembly to keep them
from fully opening during normal use.
To fully open either rear door, you must release the
check strap. Use the following steps to release the
check strap:
1. Open the door part way until the white mark on the
check strap is fully outside the door edge. If the end
of the strap catches the pin on the door, the door is
open too far.
2. Then, hold the strap at
the white mark, pull the
strap toward you and
open the door all
the way.
To r e
-engage the door check strap, just close the door
and the strap will catch the pin.To close the doors, close the driver's side door first.
After securely closing the door, close the passenger's
side door. Make sure both doors are latched securely.
To lock the rear doors from outside the vehicle, put your
key in the lock and turn it clockwise. If you have power
door locks, you can lock the side doors as well as the
rear doors from inside the vehicle. For more
information, see ªPower Door Locksº in this section.
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make it
impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transmission. Also remember to lock
the doors.

yellowblue
2-13 Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key? What if
you have to leave something valuable in your vehicle?

Put your valuables in a storage area, like your
glove box.

Valuables can also be locked in the center floor
console. Make sure that you take the console key
with you.

Take the remote keyless entry system transmitter
with you.

Lock all the doors except the driver's.
Theft-Deterrent System
Your vehicle has a theft-deterrent alarm system. Once
armed, the system will sound the horn and flash the
parking lamps if the vehicle is tampered with.
Opening the doors may activate the alarm. See
ªDisarming the Systemº later in this section for further
information on turning the system off.
Shock Sensor
A shock sensor triggers the alarm when it detects a blow
to your vehicle. It is located in the center floor console.
There are two levels of alarms via the shock sensor: two
horn blasts and the headlamp/parking lamps flash for
non
-threatening blows to the vehicle or a full
two
-minute alarm for harder blows to the vehicle. The
sensitivity can be adjusted if more or less is desired. If
sensitivity is increased too much, it may give false
alarms caused by gusts of wind or other natural events
that may shake the vehicle.

yellowblue
2-14
The adjustment for the
shock sensor sensitivity can
be accessed through a hole
in the forward wall of the
main bin of the center
floor console.
Using a small flat
-tipped screwdriver, turn the adjuster
clockwise to increase sensitivity and turn
counterclockwise to decrease sensitivity. The shock
sensor is ignored by the alarm system when the ignition
is on, when the tailgate or panel doors are open, when
the alarm is disarmed, when customized to be ignored
and for five seconds after the horn sounds an alarm or
chirp. The shock sensor is ignored after triggering three
full alarms until the system is rearmed.
Arming the System
The alarm system can be armed to detect break-ins by
locking your vehicle using the keyless entry or by
locking the doors with the power door lock switch.
Passive arming is also available if you would like the
system to arm all by itself after the doors have been
closed, the ignition is OFF and the keys have been
removed from the ignition. When the system is armed, a
red light will flash on the center floor console briefly
once every two seconds. If you return to your vehicle
and the red light is flashing two brief flashes every two
seconds, the system is armed and the shock sensor had
triggered a two minute alarm. If the red light is flashing
three times every two seconds, the system is armed and
there was an intrusion that sounded the alarm.
Horn chirps and parking lamp flashes can be set to your
choice. See ªFeature Customizationº in the Index.

yellowblue
2-15
Remote Keyless Entry Transmitter Locking
If all the doors are closed, locking the vehicle with the
transmitter will immediately arm the system. If any door
is open when the transmitter LOCK button is pressed,
the system goes into an armed wait mode, waiting for
the doors to close. Once they are closed, the system will
arm and the headlamps and parking lamps will flash. If
the tailgate or panel doors are open or ajar at the time
the system is arming, the headlamps and parking lamps
flash once.
Power Door Lock Switch Locking
If any door is open when the power door lock switch is
pressed, the system goes into an armed wait mode,
waiting for the doors, tailgate or panel doors to close.
Once they are closed, the system will arm and the
parking lamps will flash. If a door is closed when the
power lock switch is pressed, the system assumes you
are inside the vehicle, so it will not arm. Locking the
doors by using the manual door locks will not arm
the system.Passive Arming
If the ignition was just turned off and a door was
opened, the system will arm six seconds after the doors,
tailgate or panel doors are closed. If a door is opened
without the ignition being turned on, the system will
wait 30 seconds after the doors, tailgate or panel doors
are closed before arming. This provides time to get into
the vehicle and put the key in the ignition. The parking
lamps will flash when the system arms. Passive arming
is not enabled from the factory.
If the LOCK button on the keyless entry transmitter or
the power door lock switch is pressed, the system will
arm immediately.
Disarming the System
There are two ways to disarm the system:
1. Press the UNLOCK button on the keyless entry
transmitter. If the horn chirps two or three times
when you unlock the vehicle, the alarm sounded in
your absence. Two chirps means that the shock
sensor was set off and three chirps means that a door,
tailgate or the panel doors were opened.
2. Turn the ignition to RUN with the proper key.
For more information on customizing the features
mentioned here, see ªFeature Customizationº in the Index.

yellowblue
2-16 Turning Off the Alarm
If you started the alarm by pressing the panic button on
the keyless entry transmitter, you must either push that
button again or turn the ignition to RUN to stop
the alarm.
If the alarm is sounding due to the shock sensor or a
door, tailgate or panel door opening, it can be turned off
by either turning the ignition switch with a proper key
inserted or by pressing any button on the keyless entry
transmitter. If you use your keyless entry transmitter to
silence the alarm, additional things will happen
depending upon which button you press.

Pressing the UNLOCK button will turn the alarm
off, unlock the driver's door and disarm the system.

Pressing the LOCK button will turn the alarm off,
keep the doors locked and keep the system armed.

Pressing the REAR 2X button will turn the alarm off
and disarm the system.

Pressing the panic button will turn the alarm off,
keep the doors locked and keep the system armed.
If the alarm is sounding because an incorrect ignition
key was used, press any button on the keyless entry
transmitter to turn the alarm off.
The alarm will stop by itself after two minutes.
Driver's Door Alarm Delay
The alarm will sound eight seconds after the driver's
door is opened with your key.
Feature Customization
Your vehicle's locks and lighting systems can be
programmed with several different features. The
following list tells you the features that can
be programmed.

Lockout Prevention

Keyless Entry Verification

Theft
-Deterrent Arming Method

Theft
-Deterrent Arming Verification
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. Put your key in the ignition.
2. Turn the ignition to RUN to disarm the
theft
-deterrent system.
3. Turn the ignition to OFF.
