1999 CADILLAC CATERA clock

yellowblue
6-6
CAUTION:
Gasoline vapor is highly flammable. It burns
violently, and that can cause very bad injuries.
Don't smoke if you're near gasoline or refueling
your vehicle. Keep sparks, flames and smoking
materials away from gasoline.
To open your fuel door,
your vehicle must be in
PARK (P). Press the FUEL
DOOR unlock button
located on the instrument
panel center console to
unlock and open the
fuel door.
You can also press the fuel button on the remote keyless
entry transmitter to access the fuel cap.
Your vehicle has a tethered fuel cap.
To remove the cap, turn it slowly to the left
(counterclockwise). The cap has a spring in it; if you let
go of the cap too soon, it will spring back to the right.

yellowblue
6-7
CAUTION:
If you get gasoline on yourself and then
something ignites it, you could be badly burned.
Gasoline can spray out on you if you open the
fuel filler cap too quickly. This spray can happen
if your tank is nearly full, and is more likely in
hot weather. Open the fuel filler cap slowly and
wait for any ªhissº noise to stop. Then unscrew
the cap all the way.
Be careful not to spill gasoline. Clean gasoline from
painted surfaces as soon as possible. See ªCleaning the
Outside of Your Vehicleº in the Index.
When you put the cap back on, turn it to the right
(clockwise) until you hear a clicking sound. Make sure
you fully install the cap. The diagnostic system can
determine if the fuel cap has been left off or improperly
installed. This would allow fuel to evaporate into the
atmosphere. See ªMalfunction Indicator Lampº in
the Index.The FUEL CAP light will come on if the fuel cap is not
properly reinstalled.
NOTICE:
If you need a new cap, be sure to get the right
type. Your dealer can get one for you. If you get
the wrong type, it may not fit properly. This may
cause your malfunction indicator lamp to light
and your fuel tank and emissions system may be
damaged. See ªMalfunction Indicator Lampº in
the Index.

yellowblue
6-12 When to Add Engine Oil
If the oil is at or below the MIN mark, then you'll need
to add at least one quart of oil. But you must use the
right kind. This part explains what kind of oil to use. For
crankcase capacity, see ªCapacities and Specificationsº
in the Index.
NOTICE:
Don't add too much oil. If your engine has so
much oil that the oil level gets above the upper
mark that shows the proper operating range,
your engine could be damaged.
The oil fill cap is located
behind the engine oil dipstick
and next to the engine block
on the driver's side of the
engine. Turn the yellow cap
counterclockwise to
remove it.Be sure to fill it enough to put the level somewhere in
the proper operating range. Push the dipstick all the way
back in when you're through.
What Kind of Engine Oil to Use
Oils recommended for your vehicle can be identified by
looking for the ªStarburstº symbol. This symbol
indicates that the oil has been certified by the American
Petroleum Institute (API). Do not use any oil which
does not carry this Starburst symbol.
If you change your own oil,
be sure you use oil that has
the Starburst symbol on the
front of the oil container. If
you have your oil changed
for you, be sure the oil put
into your engine is
American Petroleum
Institute certified for
gasoline engines.
You should also use the proper viscosity oil for your
vehicle, as shown in the following chart:

yellowblue
6-34
2. On the outboard side of each low-beam headlamp,
you will find the turn signal bulbs. Turn the lamp
assembly counterclockwise to remove.3. Pull the bulb out to replace and then reassemble.
Center High-Mounted Stoplamp (CHMSL)
The CHMSL is equipped with high-durability
illumination. If a bulb problem does occur, see your
dealer for assistance.

yellowblue
6-35 Taillamp and Rear Turn Signal Lamp
1. Open the trunk to access the lamp housing.
2. Depending on which outer bulb needs replacing,
open either the spare tire cover on the driver's side or
the storage compartment on the passenger's side to
access the bulbs.
3. Press the gray tab on the lamp housing up as you pull
the black tab on the lamp housing away from the
vehicle. Continue to pull the lamp housing straight
out to access the bulbs.4. To remove the bulb, turn it counterclockwise. When
you replace the bulb, you need to push it in and twist
it clockwise into place.
5. Replace the lamp housing by snapping it back
into place.
Note: The taillamp assembly running across the rear
deck lid is equipped with high
-durability illumination.
If a bulb problem does occur, see your dealer
for assistance.

yellowblue
8-3
Leather 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of the Windshield and Wiper Blades 6-48 . . . . . . .
Outside of Your Vehicle 6-49 . . . . . . . . . . . . . . . . . . . . . . . .
Speaker Covers 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Top of the Instrument Panel 6-47 . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster, Instrument Panel 2-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls and Audio Systems 3-1 . . . . . . . . . . . . . . . .
Compact Disc Changer Errors 3-26 . . . . . . . . . . . . . . . . . . . . .
Compartments, Storage 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . .
Console Shift Lever 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Console Storage 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience Net 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Add to the Coolant Surge Tank 5-13 . . . . . . . . . . . .
Surge Tank 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cornering Lamps 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 7-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control Light 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . Customer Assistance
Information 7
-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Offices 7-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Text Telephone (TTY) Users 7-3 . . . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 7-2 . . . . . . . . . . . . . . . . . . . .
Damage, Finish 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage, Sheet Metal 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps (DRL) 2-42 . . . . . . . . . . . . . . . . . . .
Dead Battery 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defects, Reporting Safety 7-10, 7-11 . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogger, Rear Window 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . .
Defrosting 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions, Vehicle 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dolby Noise Reduction 3-13, 3-20 . . . . . . . . . . . . . . . . . . . . .
Door
Central Unlocking System 2
-4 . . . . . . . . . . . . . . . . . . . . . . .
Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRIVE (D), Automatic Transmission 2-23 . . . . . . . . . . . . . . .
Driver Position 1-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver's Side Instrument Panel Fuse Block 6-57 . . . . . . . . . . .
Driver's Side Temperature Knob 3-2 . . . . . . . . . . . . . . . . . . . .
Driving
City 4
-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defensive 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway 4-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In a Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Rain and on Wet Roads 4-17 . . . . . . . . . . . . . . . . . . . . . .
