Self-levelling suspension
warning lamp K134
The warning lamp É
... is constantly illuminated in the case of
corresponding system errors or when the
system is switched off.
... ...ßashes in the case of extremely low or
high levels. <Ð55 mm/>+30 mm.
... ... ßashes during Þnal control diagnosis.
... ßashes when the control system is
switched off (only possible with diagnostic
tester).
After switching off the ignition, K134
illuminates for a function check and
extinguishes after the control system has
performed internal control unit test sequence
(unless an error is present).
Warning lamp K134
242_050
The vehicle should not be driven as
long as the warning lamp is ßashing, as
low vehicle parts may be damaged due
to inadequate ground clearance.
If the warning lamp remains on
continuously to indicate a system error,
the system is switched off.
The driver is requested to contact the
nearest Audi service centre.

59
Sleep mode
To minimise electricity consumption the
control system switches to Òsystem idleÓ
(sleep mode) after 15 minutes.
There is no level adjustment in sleep mode.
ÒWake-upÓ is primarily triggered by the door
switch signal.
If the door switch signal fails, the system is
activated when the ignition is switched ÒONÓ
or by the driving speed signal.
The system can switch between sleep mode
and run-up mode, triggered by the door
switch signal, a maximum of 5 times. After
this, the system can only be activated via
terminal 15 and/or the driving speed signal. Run-on mode/run-up mode
After ÒIgnition OFFÓ, the control system is in
the so-called run-on/run-up mode. The
control unit remains active for a maximum of
15 minutes (via terminal 30) until it goes into
sleep mode.
The run-on/run-up mode is used to adjust
level deviations after parking the vehicle or
prior to starting on a journey.
The limit value in the rebound direction is
increased by 25 mm in the run-on/run-up
mode so that when the driver and/or the
passenger re-enters the vehicle, it does not
sink lower than the reference level or in order
to minimise any necessary vehicle raising
period.
The same response times apply as those
indicated for the stationary mode.

61
Overheating protection
In order to protect the compressor from
overheating, it switches off at excess
temperatures.
A temperature module is integrated into the
control unit. This monitors the temperature
and is used to calculate the compressor
temperature.
The calculations are based on the running
and cooling times of the compressor.
The max. running time is limited to 120 sec.
(an fault entry is made in the control unit
whenever the maximum running time is
exceeded).
15 seconds running time are allowed
following every 6 minutes of cooling time.
After 48 minutes of cooling time the
maximum running time of 120 seconds is
available.
242_011
Battery protection
In order to protect the battery, the maximum
running time of the compressor is limited to
60 seconds after the ignition has been
switched ÒOFFÓ. The system switches off and
only reactivates after the ignition has been
switched ÒONÓ again.
Switching self-levelling on/off.
The system can be switched off using the
diagnostic tester, e.g. during repair work.
When the ignition is switched ÒONÓ, the
systemÕs off status is indicated by a ßashing
warning lamp (T34).
At a driving speed of >20 km/h the system is
activated automatically.
