1998 TOYOTA CELICA Owners Manual

CELICA U
49
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Canada
are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra-
tion.
If your child restraint system does not
provide any of the necessary parts, ask
your Toyota dealer. (See ”—Child restraint
system”.)Bolt
Anchor bracket
Spacer
20 mm
(0.8
in.)
210 mm
(8.3 in.)
Liftback (right seat)— On the luggage
compartment floor
a. Using the illustration as a guide, uncov-
er the anchor by rolling back the carpet
on the luggage compartment floor. The
anchor hole is sealed.
b. Remove the seal of the anchor.
c. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5—24.7 N·m (1.68—2.52
kgf·m, 12.2—18.2 ft·lbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Canada
are provided with a bracket set in the
glovebox. If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt.
ProCarManuals.com

CELICA U
50
Spacer
Bolt
240 mm
(9.4 in.)
Anchor bracket
11 4 m m
(4.5 in.)
Liftback (left seat)— On the luggage
compartment wall
a. Using the illustration as a guide, re-
move the cap of the anchor.
b. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5—24.7 N·m (1.68—2.52
kgf·m, 12.2—18.2 ft·lbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Canada
are provided with a bracket set in the
glovebox.
Tilt steering wheel
To change the steering wheel angle,
hold the steering wheel, pull up the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION
Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
ProCarManuals.com

CELICA U
51
Outside rear view mirrors—
Adjust the mirror so that you can see
the side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger ’s side.
It is a convex mirror with a curved sur-
face. Any object seen in a convex mirror
will look smaller and farther away than
when seen in a flat mirror.
—Power rear view mirror control
With power windows
Without power windows
To adjust a mirror, use the switches.1. Master switch—To select the mirror to be adjusted
Place the switch at ”L” (left) or ”R”
(right).
2. Control switch—To move the mirror Push the switch in the desired direc-
tion.
If the engine is not running, the key must
be in the ”ACC” position.
NOTICE
If ice should jam the mirror, do not
operate the control or scrape the mir-
ror face. Use a spray de −icer to free
the mirror.
ProCarManuals.com

CELICA U
52
—Folding rear view mirrors
The rear view mirrors can be folded
backward for parking in restricted
areas.
To fold the rear view mirror, push back-
ward.
CAUTION
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
Adjust the mirror so that you can just
see the rear of your vehicle in the mir-
ror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight driving—Lever at position 1
The reflection in the mirror has greater
clarity at this position.
Night driving—Lever at position 2
Remember that by reducing glare you also
lose some rear view clarity.
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal injuries.
Anti−glare inside rear view
mirror
ProCarManuals.com

CELICA U
53
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1−4
Lights, Wipers and
Defogger
 Headlights and turn signals
 Emergency flashers
 Instrument panel light control
 Front fog lights
 Interior lights
 Personal lights
 Ignition switch light
 Luggage compartment light
 Windshield wipers and washer
 Rear window wiper and washer
 Rear window defogger
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
The lights automatically turn off when the
driver ’s door is opened with the ignition
key turned off. To turn them on again, turn
the key to the ”ON” position or actuate
the headlight switch. If you are going to
park for over one week, make sure the
headlight switch is off.
NOTICE
To prevent the battery being dis-
charged, do not leave the lights on
for a long period when engine is not
running.
Daytime running light system (Canada
only)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ”OFF” position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
to full intensity for driving at night.
ProCarManuals.com

CELICA U
54
High−low beams— For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to ”OFF”.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the ”ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.
Emergency flashers
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
ProCarManuals.com

CELICA U
55
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob.
Front fog lights
To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
when the tail lights are turned on.
ProCarManuals.com

CELICA U
56
Interior light (with moon roof)
To turn on the interior light, push the
switch. To turn the light off, slightly
push the switch on the opposite side.
The interior light switch has the following
positions:
”ON”—Turns the light all the time.
”DOOR”—Turns the light on when either
side door or the back door is opened. The
light goes off when both side doors and
the back door are closed.The interior lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
The center switch has the following posi-
tions:
”DOOR”—Turn both lights on when either
side door or the back door is opened. The
lights remain on for some time after both
side doors and the back door are closed.
”OFF”—The lights are off unless you oper-
ate either outside switch.
Personal lights
To operate the personal light, move the
knob.
To turn on: Push the knob forward.
To turn off: Pull the knob backward.
The light comes on when either side door
is opened.
Interior lights (without moon
roof)
