1998 TOYOTA CELICA Owners Manual

CELICA U
1
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1−1
Overview of instruments
and controls
 Instrument panel overview
 Instrument cluster overview
 Indicator symbols on the
instrument panel
ProCarManuals.com

CELICA U
2
Instrument panel overview
1. Side vents
2. Side defroster outlets
3. Instrument cluster
4. Personal lights
5. Electric moon roof switches and interiorlights
6. Glovebox
7. Power door lock switches
8. Power window switches
9. Ashtray
10. Cup holder 11. Parking brake lever
12. Manual transmission gear shift lever or automatic transmission selector lever
13. Lower vent
14. Hood lock release lever
15. Power rear view mirror control switch (with power windows)
ProCarManuals.com

CELICA U
3
1. Headlight and turn signal switch
2. Wiper and washer switches
3. Emergency flasher switch
4. Clock
5. Center vents
6. Car audio
7. Auxiliary box
8. Air conditioning controls
9. Rear window defogger switch
10. Coupe and liftback— Power rear view mirror control switch
(without power windows)
Convertible—
Convertible top control switch and
quarter window control switches
11. Cigarette lighter
12. Ignition switch
13. Cruise control switch
14. Tilt steering lock release lever
15. Instrument panel light control knob
ProCarManuals.com

CELICA U
4
Instrument cluster overview
1. Service reminder indicators and indica-tor lights
2. Tachometer
3. Odometer 4. Engine coolant temperature gauge
5. Fuel gauge
6. Trip meter
7. Trip meter reset knob
8. Speedometer
ProCarManuals.com

CELICA U
5
Indicator symbols on the instrument panel
(type A)
(type A)
Brake system warning light∗
1
Discharge warning light∗1
Low oil pressure warning light∗1
Malfunction indicator lamp∗1
Headlight high beam indicator light
Overdrive −off indicator light
SRS airbag warning light∗
1
Turn signal indicator lights
Anti-lock brake system warning light∗1
Seat belt reminder light∗1
Open door warning light∗1
∗ 1
: For details, see ”Service reminder indicators and warning
buzzers” in Chapter 1 −5.
∗
2: If this light flashes, see ”Cruise control” in Chapter 1 −6.
Cruise control indicator light∗
2
Low fuel level warning light∗1
(type B)
(type B)
ProCarManuals.com

CELICA U
6
ProCarManuals.com

CELICA U
7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1−2
Keys and Doors
 Keys
 Side doors
 Power windows
 Trunk lid/Back door
 Hood
 Fuel tank cap
 Electric moon roof
 Convertible top
Keys
Your vehicle is supplied with two kinds
of key.
1. Master key—This key works in every lock.
2. Subkey—This key is for side doors.
To protect things locked in the glovebox,
trunk or luggage compartment when you
have your vehicle parked, leave the sub-
key with the attendant.
Since the side doors, trunk lid and back
door can be locked without a key, you
should always carry a spare master key
in case you accidentally lock your keys
inside the vehicle.KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com

CELICA U
8
Side doors
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Both side doors lock and unlock simulta-
neously with either side door. In the driv-
er’s door lock, turning the key once will
unlock the driver’s door and twice in suc-
cession will unlock both side doors simul-
taneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the side door with the lock knob
in the lock position will also lock the side
door. Be careful not to lock your keys in
the vehicle.
Vehicles with a power door lock sys-
tem—The side door cannot be locked if
you leave the key in the ignition switch.Driver’s side
Passenger’s side
