SELF DIAGNOSIS TEST
1. Turn the ignition switch to “OFF” position.
2. Connect the scanner harness connector to the engine
compartment diagnosis socket.
3. Turn the ignition switch to “ON” position.
4. Select “Electronics control vehicle diagnosis” from the
function selection display and press “Enter”.
5. Select “Musso(98 face lift)” from the vehicle model selection
model selection display and press “Enter”.
6. Select “Transmission control unit(TCU)” from the control
system selection and press “Enter”.
7. Select “Self-diagnosis” from diagnosis items.
Notice
Check sensor output value displays if necessary.
8. Determine the fault code and check the detective Items.
Notice
Refer to sefadf3fnosfs list.
Page 1053 of 1463

5A-76 AUTOMATIC TRANSMISSION
Action
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck voltage between terminal 27 and 29 of TCU,
- Standard value : 0.2 - 4.7V
lCheck TPS.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck engine speed sensor.
lCheck resistance between terminal 8 and 24 of TCU (when the
connector is disconnected).
- Standard value : 1 .9 - 0.2 k
W
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck vehicle speed sensor.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck engine speed sensor.
lCheck inhibitor switch resistance between terminal 34 and 37 of
TCU(when the connector is disconnected).
- Standard value : 1st gear - 4 - 4.4 k
W
2nd gear - 4,8 - 2.2 kW
3rd gear - 3 - 3.4 kW
D gear - 4.5 - 4.g kW
N gear - 6.8 - 7.2 kW
R gear - 10.8 -11.2 kW
P gear - 18.6 - 19 kW
lCheck voltage between terminal 31 and 37 of TCU.
- Standard value : 0-5V(P,R,N,D,L)
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck mode switch.
lCheck condition between terminal 1 and 13 of TCU.
Winter mode :12V, Normal mode : Open status, Power mode : 0V
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck voltage between terminal 32 and 38 of TCU.
- Standard value : 0-5V
lCheck oil temperature sensor.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck battery condition.
lCheck alternator. Possible Cause
Throttle position sensor
Engine RPM
Vehicle speed
Shift lever
W, E, P mode switch
T/M oil temperature
Battery voltage Symptom
P1702
P1703
P1704
P4705
P1706
P1707
P1708
Self-diagnosis List
Page 1054 of 1463

AUTOMATIC TRANSMISSION 5A-77
Action
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck voltage between terminal 4 and 11 of TCU.
- Standard value : when the A/C compressor is ON : 12V
when the A/C compressor is OFF : 0V
lCheck cable for open / short,
lCheck connection of other connectors.
lCheck voltage between terminal 1 and 12 of TCU.
- Standard value : when the kick down switch is ON : 12V
when the kick down switch is OFF : 0V
lFully depress accelerator pedal for 5 seconds(ignition key is ON).
lRelease accelerator pedal.
lDepress brake pedal and start the engine in ‘P’ position.
lDepress brake pedal and idle the engine for 5 seconds in ‘D’
position.
lShift into ‘D’ position and determine fault code for throttle initial-
ization.
lComplete the initialization.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck resistance between terminal 1 and 34 of TCU(when the
connector is disconnected).
- Standard value : 26 - 30
W
lCheck solenoid.
lCheck cable for open / short.
lCheck connection of other connectors,
lCheck resistance between terminal 1 and 40 of TCU (when the
connector is disconnected).
- Standard value : 26 - 30
W
lCheck solenoid.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck resistance between terminal 1 and 41 of TCU (when the
connector is disconnected).
- Standard value : 26 - 30
W
lCheck solenoid.
lCheck cable for open / short.
lCheck connection of other connectors.
lCheck resistance between terminal 1 and 33 of TCU (when the
connector is disconnected),
- Standard value : 26 - 30
W
Possible Cause
Air conditioner switch
Kick down switch
Pedal
Vehicle ID
VPS offset
Throttle position sensor
initialization
Solenoid 1
Solenoid 2
Solenoid 3
Solenoid 4 Symptom
P1710
P1712
P1713
P1714
P1715
P1716
P1733
P1734
P1735
P1736
Page 1059 of 1463
5A-82 AUTOMATIC TRANSMISSION
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
Tightening Torque 70 - 80 Nm
5. Remove the rear propeller shaft .
Installation Notice
REMOVAL & INSTALLATION OF
TRANSMISSION
1. Disconnect the negative battery cable.
2. Disconnect the connectors from transfer case.
3. Disconnect the speedometer connector from transfer
case.
4. Disconnect the inhibitor and Sear position sensor
connector.
6. Unscrew the eight bolts and two nuts, and remove the
cross member.
Page 1173 of 1463

TRANSFER CASE (PART TIME 4408) 5D1-3
Cannot Front Wheel Drive when Shifted 4H,4L
DIAGNOSIS
Electric Shift Problems
Action
Overhaul and check, replace if necessary.
Overhaul and check for wear and damage.
Replace if necessary.
Check sliding parts, replace if necessary. Checks
Faulty or Damaged TCCU, Speed Sensor, Motor, Clutch
or Internal Wirings
Damaged or Worn Shift Cam, Hub, Fork and Rail Shift
Binding Shift Fork, Hub Collar or Gear
Checks
Broken Drive ChainAction
Check sliding parts, replace if necessary.
Noise in 4WD Operation
Checks
Improper or low oil
Loosened bolts or mounted parts
Noisy T/C bearing
Noisy gearsAction
Drain and replace with specified oil.
Retighten as specified.
Disassemble bearings and parts and check for wear or
damage. Replace if necessary.
Check for wear and damage including speedometer
gear, replace if necessary.
Noise in 4H or 4L
Checks
Worn or Damaged Sprockets or Drive Chain
Incorrect Tire PressureAction
Disassemble and check for wear and damage, replace
if necessary.
Adjust tire pressure.
Transfer Case Oil Leakage
Action
Replace the case.
Clean case and parts and check for leakage.
Remove breather hose and clean, replace if necessary.
Use specified oil and adjust oil level.
Retighten
Use specified sealant and retighten.
Replace Checks
Cracked Transfer Case
Leakage from Other Parts
Breather Clogging
Improper or too much Oil
Loosened Sealing Bolts
Improperly Applied Sealant
Worn or Damaged Oil Seal
Page 1174 of 1463

5D1-4 TRANSFER CASE (PART TIME 4408)
SELF-DIAGNOSIS
SYSTEM DESCRIPTION
1. TCCU detects transfer case system malfunctions and
indicates malfunctioning part(s) through flashing 4H,4L
indicator lights.
Using a service connector, connect it to the diagnosis box
in the engine room and read the flashing of the ‘4WD
CHECK’ indicator light.
The flashing indicator light will show you defective code(s).
2. Identify 7 defective codes after reading the flashing indicator
light.
lTCCU
lShift motor
lMagnetic synchronizer clutch
lSpeed sensor
lHub solenoid
lSelector switch
lMotor position sensor
3. Transfer case system is malfunctioning when:
l4H ,4L indicator lights are remain on after 0.6 second
when turning the ignition switch ‘ON’
l4H,4L indicator lights are continuously come on during
driving.
4. If only 1 part is malfunctioning, ‘4WD CHECK’ indicator light
will display defective code 3 times continuously.
5. If more then 2 part is malfunctioning, the first malfunctioning
part will be displayed 3 times and following malfunctioning
parts will be displayed .
6. To read defective code, connect the service connector and
turn the ignition switch 'ON'.
7. After repairing, eliminate the defective code stored in the
TCCU.
Notice
Before replacing the malfunction parts with defective code,
check the wires and connectors for proper condition.
Page 1176 of 1463
5D1-6 TRANSFER CASE (PART TIME 4408)
Diagnostic Table
Connect a service connector. If turn the ignition switch ‘ON’
‘4WD CHECK’ indicator light will come on for 0.6 second and
turn off for 3 seconds and then display a defective code 3
times continuously.
No.Defective Code
Malfunctioning Part
1
2
3
4
5TCCU
Shift Motor
Synchronizer Clutch
Speed Sensor
Hub Solenoid
4WD
CHECK
Light
ON
OFF
Defective Code
4WD
CHECK
Light
ON
OFF
Defective Code
4WD
CHECK
Light
ON
OFF
Defective Code
4WD
CHECK
Light
ON
OFF
Defective Code
4WD
CHECK
Light
ON
OFF
Defective Code
Page 1177 of 1463
TRANSFER CASE (PART TIME 4408) 5D1-7
No.Defective Code
Malfunctioning Part
6
7
Selector Switch
Motor Positon Sensor
4WD
CHECK
Light
ON
OFF
Defective Code
4WD
CHECK
Light
ON
OFF
Defective Code
