1998 SSANGYONG MUSSO engine

1B1-56 M162 ENGINE MECHANICAL
Removal & Installation Procedure
1. Turn the crankshaft to the direction of engine rotation and
position the no.1 cylinder piston at TDC which the camshaft
is positioned at OT.
2. Remove the cylinder head front cover.
3. Paint the alignment marks (arrows) on the intake and
exhaust camshaft sprocket and the timing chain.
4. Unscrew the bolt (3) from the armature (4) and remove the
armature.
Installation Notice
3 Bolt
4 Amarture
6 Nut (M20 x 1.5)
11 Seal Cover
5. Unscrew the nut (6) and remove the ring and seal cover
(11).
Installation Notice
Tightening Torque 35 Nm
Tightening Torque 60 - 70 Nm
12 Camshaft Sprocket
17 Control Piston
21 Intake Camshaft
6. Unscrew the sprocket bolt from the exhaust camshaft and
remove the sprocket.
Installation Notice
The sprocket bolt is designed to be used only once, so
always replace with new one.Tightening Torque1st step 18 - 22 Nm
2nd step 90° ± 5°

M162 ENGINE MECHANICAL 1B1-57
7. Remove the camshaft sprocket (13) and adjust piston (14),
and remove the flange shaft (16) from the intake camshaft
(22) after removing the bolt (15).
Installation Notice
The sprocket bolt is designed to be used only once, so
always replace with new one.
8. Installation should follow the removal procedure in the
reverse order.
9. Adjust the camshaft timing.
Tightening Torque1st step 18 - 22 Nm
2nd step 90° ± 5°

1B1-58 M162 ENGINE MECHANICAL
CAMSHAFT SPROCKET BOLT
Intake Flange Shaft Bolt
Notice
The sprocket bolts are designed to be used only once, so
always replace with new one.
Exhaust Camshaft Sprocket Bolt
Notice
The sprocket bolts are designed to be used only once, so
always replace with new one.
C. M7 x 13 Collar Bolt Torx-T30
e. 6.8 mm
16. Flange Shaft
18. Control Piston
22. Intake Camshaft
E. M7 x 13 Collar Bolt Torx-T30
e. 6.8 mm
13a. Camshaft Sprocket
22a. Exhaust Camshaft
Tightening Torque1st step 18 - 22 Nm
2nd step 90° ± 5°
Tightening Torque1st step 18 - 22 Nm
2nd step 90° ± 5°

M162 ENGINE MECHANICAL 1B1-59
CAMSHAFT
Preceding Work : Removal of cylinder head cover, removal of coolant connection fitting
1 Chain Tensioner Assembly..................72-88 Nm
2 Exhaust Camshaft Sprocket
3 Upper Guide Rail
4 Cylinder Head Front Cover5 Intake Camshaft Sprocket
6 Chain
7 Wrench (Special Tool)

1B1-60 M162 ENGINE MECHANICAL
Tools Required
000 589 01 10 00 Box Wrench Insert
104 589 01 01 00Spanner
Removal Procedure
1. Turn the crankshaft and position the No. 1 cylinder piston
at BTDC 30°.
2. Remove the alternator.
3. Remove the chain tensioner.
4. Remove the cylinder head front cover and the upper guide
rail.
6. Unscrew the exhaust camshaft sprocket bolt and remove
the sprocket.
7. Separate the chain from the intake camshaft sprocket and
put the chain not to be dropped into timing case. 5. Put the alignment marks (arrows) on the camshaft sprocket
(2, 5) and the timing chain (6).

M162 ENGINE MECHANICAL 1B1-61
8 . Unscrew the intake side bolts (8, 11, 13, 14) and the exhaust
side bolts (1, 4, 6, 7).
9. Loosen the remaining bolts and unscrew the intake and
exhaust side camshaft bearing cap bolts.
Notice
Number the camshaft bearing cap bolts when removing
them, so that they don’t get mixed up.
10. Remove the intake and exhaust camshafts.
Installation Procedure
1. Turn the crankshaft and position the No. 1 cylinder piston
at BTDC 30°.
Notice
Turn the crankshaft in the direction of engine rotation.
3. Turn the camshaft using the wrench (special tool) so that
the intake camshaft adjustment hole lines up with the cylinder
head upper side (3 o’clock direction at the intake, 9 o’clock
direction at the exhaust).
Notice
Turn the crankshaft and adjust it to OT so that No. 1 cylinder’s
piston would be at TDC. Install the bearing caps according to the numbers on the
bearing caps.
Tightening Torque 22.5 - 27.5 Nm 2. Install the exhaust camshaft bearing caps (2, 3, 5) and the
intake camshaft bearing caps (9, 10, 12). Tighten the bolts
with specified torque and install the remaining bearing caps.
Notice

1B1-62 M162 ENGINE MECHANICAL
4. Turn the intake camshaft adjuster to the direction of camshaft
rotation by hard until it stops and then install the chain.
Notice
lMake sure that the camshaft sprocket and timing chain
are aligned with marks.
lIntake camshaft adjuster should be in retarded position.
5. Install the chain on the exhaust sprocket and tighten the
sprocket bolts.
Notice
7. Rotate the crankshaft 2 revolutions and check followings:
- TDC of no. 1 cylinder : OT
- Alignment between camshaft adjustment hole and
cylinder head surface.
- Alignments between timing chain and sprocket marks.
Notice
lTurn the crankshaft in the direction of engine rotation.
lRead just if not aligned. 6. Install the chain tensioner and tighten it as specified.
Notice lMake sure that the camshaft sprocket and timing chain
are aligned with marks.
lReplace the sprocket bolt with new one.
Tightening Torque1st step 18 - 22 Nm
2nd step 90° ± 5°
Tightening Torque( 1 ) 40 Nm
(2) 72 - 88 Nm

M162 ENGINE MECHANICAL 1B1-63
8. Install the upper guide rail and cylinder head front cover.
9. Install the alternator.
