AUTOMATIC TRANSMISSION (AW30-40LE) 7A–157
248RY00057
248RY00058
248RY00051
5. Thrust washer (plastic)
Install thrust washer.
NOTE:
Make sure that the lugs fit into the holes on the sun gear
input drum.
6. One–way clutch and second brake hub
Install assembled No.1 one–way clutch and second brake
hub onto planetary sun gear as shown.
Check operation of No.1 one–way clutch
Hold the planetary sun gear and turn the second brake
hub. The second brake hub should turn freely clockwise
and should lock counterclockwise.
(1) : Free
(2) : Lock

7A–164 AUTOMATIC TRANSMISSION (AW30-40LE)
247RY00028
247RY00029
247RY00030
247RY00031
Important operations
3. Oil seal ring
Remove oil seal ring from output shaft.
5. Rear planetary gear assembly
Remove rear planetary gear from rear planetary ring gear.
Check operation of No.2 one–way clutch
Hold the planetary gear and turn the one–way clutch inner
race. The one–way clutch inner race should turn freely
counterclockwise and should lock clockwise.
(1) : Lock
(2) : Free
6. One–way clutch inner race
Remove the one–way clutch inner race from the rear
planetary gear.

7A–168 AUTOMATIC TRANSMISSION (AW30-40LE)
247RY00039
247RY00040
247RY00041
247RY00029
7. Snap ring
Install snap ring.
8. One–way clutch inner race
While turning counterclockwise, install one–way clutch
inner race to rear planetary gear.
Check operation of one–way clutch
Hold the planetary gear and turn the one–way clutch inner
race. The one–way clutch inner race should turn freely
counterclockwise and should lock clockwise.
(1) : Lock
(2) : Free
9. Rear planetary gear assembly
Install rear planetary gear onto rear planetary ring gear.

AUTOMATIC TRANSMISSION (AW30-40LE) 7A–181
241RY00018
TORQUE CONVERTER
INSPECTION AND REPAIR
Insert special tool in end of torque converter
Insert a turning tool into the inner race of the one–way
clutch.
One–way clutch testing tool : 5–8840–2168–0 (J–35467)
Insert the stopper so that it fits in the notch of the converter
hub and outer race of the one–way clutch.
Test one–way clutch
The clutch should lock when turned counterclockwise, and
rotate freely and smoothly clockwise. Less than 25kgꞏcm
(22 Ibꞏin) of torque should be required to rotate the clutch
clockwise. If necessary, clean the conver ter and retest the
clutch. Replace the converter if the clutch still fails the test.

7A–188 AUTOMATIC TRANSMISSION (AW30-40LE)
248RY00014
248RY00019
248RY00020
247RY00012
7. Snap ring
Install the snap ring.
Check pack clearance of second brake
Using a thickness gauge, measure the clearance between
the snap ring and flange as shown in the figure.
If the values are nonstandard, check for an improper
installation.
8. Drum
While turning the sun gear input drum clockwise, install it
into the one-way clutch.
NOTE:
Confirm the thrust washers are installed correctly.
9. Front planetary gear and bearing
Install the front planetary gear to the sun gear.
NOTE:
Confirm the bearing and race is installed correctly.mm (in.)
Clearance0.62–1.98
(0.0244–0.0780)
