1998 NISSAN QUEST Owners Manual

FIVE PASSENGER SEATING FIVE PASSENGER SEATING WITH CARGO ROOM
The step mat is not used in this seating configuration.
APD0849APD0850
1-66Seats, restraints and supplemental air bag systems
ZX

THREE-PASSENGER BENCH
SEAT IN FULLY
FORWARD POSITION
The step mat is not used in this seating
configuration.
APD00851
Seats, restraints and supplemental air bag systems1-67
ZX

FLOOR MAT POSITIONING AID
Positioning pins are attached to three of the
floor mats. The cargo mat and front mats do
not have pins. However, the front floor mats
each have a grommet which is placed overthe floor mat positioning brackets located at
the base of the front seats.
Push the positioning pins into the seat
tracks to ensure correct installation, then
straighten the mats as necessary.
The step mat has holes in addition to pins.
When the mats are arranged properly, the
positioning pins of the two mats on either
side of the step mat should fit through the
holes in the step mat and into the seat track.
WARNING
cNo occupant should ride in a vehicle
seat unless it is in a normal riding
arrangement and the seat belts are
properly used.
cIt is extremely dangerous to ride in a
cargo area inside of a vehicle. In a
collision, people riding in these ar-
eas are more likely to be seriously
injured or killed.
cProperly secure all cargo to help
prevent it from sliding or shifting. Do
not place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.cDo not allow people to ride in any
area of the vehicle that is not
equipped with seats and seat belts.
cBe sure everyone in your vehicle is
in a seat and is using a seat belt
properly.
cFailure to follow proper seating in-
structions in this section could re-
sult in serious personal injury in an
accident or during a sudden stop.
APD0083
1-68Seats, restraints and supplemental air bag systems
ZX

WITH SECOND ROW BENCH
SEAT
The most common seating arrangement for
seven passengers is with the three-
passenger bench seat in seating position
#1. This provides more leg room for the
passengers sitting in the third row.When more cargo area room is necessary,
the three-passenger sliding bench seat can
be moved to seating position #2. This seat-
ing arrangement provides less leg room for
third row passengers, but more cargo area
room.The fold-down tabletop seats in the second
and third rows provide a surface for eating
or playing games on long trips.
APD0096APD0097APD0042
SEAT POSITIONS
Seats, restraints and supplemental air bag systems1-69
ZX

If a considerable amount of cargo area
room is needed, the seat cushion of the
three-passenger sliding bench seat can be
flipped up and the seat can be moved up to
storage position #2, just behind the second
row seat.When maximum cargo area is needed and
there are no rear seat passengers, the
second row seat can be removed and the
three-passenger sliding bench seat can be
moved up to storage position #1, just behind
the front seats.The second row bench seat can be folded
down to serve as a tabletop for passengers
sitting in the three-passenger bench seat.
APD0043APD0049APD0044
1-70Seats, restraints and supplemental air bag systems
ZX

The second and third row bench seats can
be folded down to tabletops.To increase cargo area space, the second
row bench seat can be removed and the
three-passenger sliding seat can be moved
up to the second row position.The third seat can be folded down into a
tabletop.
APD0045APD0046APD0047
Seats, restraints and supplemental air bag systems1-71
ZX

With the third seat folded down and the
second seat removed, cargo can be placed
in between the front seats and the third row
seat.People should not be allowed to
ride in areas meant for cargo. Passen-
gers should always be properly re-
strained in seat belts.The second row seat can be folded down
and the third row seat can be moved just
behind it in a storage position.WITH SECOND ROW BUCKET
SEATS
The normal seating arrangement for seven
passengers is with the three-passenger
bench seat in seating position #1. This
provides more leg room for the passengers
sitting in the third row.
APD0048APD0050APD0128
1-72Seats, restraints and supplemental air bag systems
ZX

When one passenger in the three-
passenger bench seat would like more leg
room, one of the second row bucket seats
can be removed.When more cargo area room is necessary,
the three-passenger sliding bench seat can
be moved to seating position #2. This seat-
ing arrangement provides less leg room for
third row passengers, but more cargo area
room.If passengers in the three-passenger bench
seat would like more leg room, both second
row bucket seats can be removed.The
floor area should never be used by pas-
sengers. Passengers should always be
properly restrained by seat belts.
APD0127APD0052APD0053
Seats, restraints and supplemental air bag systems1-73
ZX
