NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual CEL759
HARNESS LAYOUT
Engine Room Harness/LHD Models (Contd)
EL-289

Page 294 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual Engine Room Harness/RHD Models
CEL826
HARNESS LAYOUT
EL-290

Page 295 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual CEL827
HARNESS LAYOUT
Engine Room Harness/RHD Models (Contd)
EL-291

Page 296 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual PASSENGER COMPARTMENT
CEL828
HARNESS LAYOUT
Engine Room Harness/RHD Models (Contd)
EL-292

Page 297 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual CEL829
HARNESS LAYOUT
Engine Room Harness/RHD Models (Contd)
EL-293

Page 298 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual Engine Harness
CEL830
HARNESS LAYOUT
EL-294

Page 299 of 326

NISSAN PATROL 1998 Y61 / 5.G Electrical System Workshop Manual Engine Control Harness and Alternator
Harness
CEL832
HARNESS LAYOUT
EL-295
