1998 MITSUBISHI MONTERO run flat

PINION ROTATING TORQUE SPECIFICATIONS table.
PINION ROTATING TORQUE SPECIFICATIONS









\









\









\









\









\









\









\







Application INCH Lbs. (N.m)\
Oil Seal Not Installed
With Lubrication ................................. 3.5-4.3 (.4-.5)\
Without Lubrication .............................. 5.2-7.8 (.6-.9)\
Oil Seal Installed
With Lubrication ............................... 5.6-6.5 (.65-.75)\
Without Lubrication .......................... 7.4-10.0 (.85-1.15)\









\









\









\









\









\









\









\







3) Install cylinder gauge in side bearing seats. Ensure flat
areas align, and gauge contacts side bearing seat firmly. Select
adjusting shim with same thickness as gap between cylinder gauge and
pinion height gauge.
4) Use minimum amount of adjusting shims. Install selected
adjusting shims between drive pinion gear and rear pinion bearing.
Using bearing installer and press, install rear pinion bearing.
5) Install drive pinion in differential housing. Install
spacer, pinion front shim(s) and front pinion bearing. DO NOT install
oil seal. Install pinion companion flange, washer and retaining nut.
Tighten nut to specification. See TORQUE SPECIFICATIONS.
6) Check pinion rotating torque. See
PINION ROTATING TORQUE SPECIFICATIONS table. Adjust rotating torque by
replacing drive pinion front shims or spacer. Once correct rotating
torque is obtained, install oil seal. Coat seal lip with grease.
Install pinion companion flange so alignment marks are correct. Apply
light coat of grease to contact area of pinion flange washer.
7) Install NEW retaining nut. Recheck pinion rotating torque.
Ensure rotating torque is within specification. Press side bearings
onto differential case. Install outer races. Install differential
carrier into differential housing. Align bearing cap index marks, and
snug carrier cap bolts. Ensure outer races and bearing caps are
installed in original location.
8) Install side bearing nuts. Tighten bearing cap bolts to
specification. See TORQUE SPECIFICATIONS . Tighten bearing nuts until
bearing outer races are seated against bearings. Adjust ring gear
backlash.
Ring Gear Backlash
1) Secure drive pinion in place. Using dial indicator, check
ring gear backlash at heel of ring gear tooth. See Fig. 6. Measure at
4 locations of ring gear. Gear backlash must be within specification.
Backlash should be .005-.007" (.13-.18 mm).
2) If backlash is less than specification, loosen side
bearing nut at back of ring gear, and tighten side bearing nut on
tooth side of ring gear by same amount. If backlash exceeds
specification, loosen side bearing nut at tooth side of ring gear, and
tighten side bearing nut at back of ring gear by same amount.
3) After adjusting backlash, tighten both side bearing nuts
half the distance between 2 adjacent holes on side bearing nut.
Recheck backlash. Ensure bearing cap bolts are tightened to
specification. See TORQUE SPECIFICATIONS .
4) Lock plates are of 2 designs for hole location of side
bearing nuts. Install proper type lock plate. Tighten lock plate bolt
to specification. See TORQUE SPECIFICATIONS. Check gear tooth contact
pattern. See GEAR TOOTH CONTACT PATTERNS article in GENERAL
INFORMATION.
Ring Gear Runout

with tip resting on the main bearing journal area. See Fig. 21.
Rotate crankshaft and note reading. Journal runout must not exceed
specification. Repeat procedure on all main bearing journals.
Crankshaft must be replaced if runout exceeds specification.
Fig. 21: Measuring Crankshaft Main Bearing Journal Runout - Typical
This Graphic For General Information Only
INSTALLATION
Install upper main bearing in cylinder block. Ensure lock
tab is properly located in cylinder block. Install bearings in main
bearing caps. Ensure all oil passages are aligned. Install rear seal
(if removed).
Ensure crankshaft journals are clean. Lubricate upper main
bearings with clean engine oil. Carefully install crankshaft. Check
each main bearing clearance using Plastigage method. See
MAIN & CONNECTING ROD BEARING CLEARANCE in this article.
Once clearance is checked, lubricate lower main bearing and
journals. Install main bearing caps in original location. Install rear
seal in rear main bearing cap (if removed). Some rear main bearing
caps require sealant to be applied in corners to prevent oil leakage.
Install and tighten all bolts except thrust bearing cap to
specification. Tighten thrust bearing cap bolts finger tight only.
Thrust bearing must be aligned. On most applications, crankshaft
must be moved rearward then forward. Procedure may vary with
manufacturer. Thrust bearing cap is then tighten to specification.
Ensure crankshaft rotates freely. Crankshaft end play should be
checked. See CRANKSHAFT END PLAY in this article.
CRANKSHAFT END PLAY
Dial Indicator Method
Crankshaft end play can be checked using dial indicator.
Mount dial indicator on rear of cylinder block. Position dial
indicator tip against rear of crankshaft. Ensure tip is resting
against flat surface.
Pry crankshaft rearward. Adjust dial indicator to zero.

(1) - Require replacement of units where dents restrict shock
or strut piston rod movement. If dents don't restrict
movement, no service is suggested or required. Especially
critical on mono-tube shocks.
( 2) - This condition can lead to damage of the piston rod,
which, in turn, causes premature piston rod seal wear.
( 3) - Only required if replacing cartridge.
( 4) - CAUTION: If the strut cartridge has been replaced previously,
the oil on the strut housing may be filler oil. The
technician must identify the source of the oil.
( 5) - If noise is isolated to shock or strut, suggest
replacement.
( 6) - Although shocks or struts may have contributed to tire
cupping, an inspection is needed of the entire suspension
system. If the shock or strut is found to be contributing
to the tire cupping, require replacement.









\









\









\









\









\









\









\


SPINDLES
SPINDLE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Bent .................... B ............ Require replacement.
Broken .................. A ............ Require replacement.
Race seat area
undersized ............. B ............ Require replacement.
Scored .................. A .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.









\









\









\









\









\









\









\


SPRINGS - COIL, LEAF AND TORSION BAR
When springs are replaced, it is suggested, but not required,
that both springs on an axle be replaced to maintain equal height from
side to side and to provide a balanced ride and proper handling.
When variable rate springs are installed in place of
conventional coil springs, they must be installed in axle sets to
ensure proper handling, uniform ride, and proper chassis height.
Erroneous height measurements may result from: improper tire
inflation, non-standard tire or wheel size, and heavy load in vehicle
or trunk.
SPRING (COIL, LEAF AND TORSION BAR) INSPECTION

Condition Code Procedure
Air pressure incorrect .. B .................. Require repair
Bead broken ............. A ............ Require replacement.
Bead leaking, caused
by tire ................ A .. Require repair or replacement.
Bead wire/cord exposed .. A ............ Require replacement.
Cord or belt material
exposed ................ A ............ Require replacement.
Cord ply separations .... A ............ Require replacement.
Directional/asymmetrical
tires mounted
incorrectly ............ B ....... Require remounting and/or
repositioning.
Irregular tread wear,
affecting performance .. 2 ........ (1) Suggest replacement.
Load ratings less
than OEM
specifications ......... B ............ Require replacement.
Mixed tread types (all
season, performance, mud
and snow) on same axle . A ............ Require replacement.
Number of punctures
exceeds manufacturer's
limit .................. B ............ Require replacement.
Out of balance .......... B . Require rebalance of tire/wheel
assembly.
Ply separation .......... A ............ Require replacement.
Pull or lead, caused
by tire ................ A .. Require repair or replacement.
Radial and bias or
bias-belted ply tires
on same axle ........... B .. Require repair or replacement.
Radials are on the front
and not on the rear .... B ........... ( 2) Require repair or
replacement.
Run flat damage ......... A ............ Require replacement.
Shoulder cut ............ A ............ Require replacement.
Shoulder puncture ....... A ............ Require replacement.
Shoulder with plug ...... A ............ Require replacement.
Sidewall bulge .......... A ............ Require replacement.
Sidewall cut ............ A ............ Require replacement.
Sidewall indentation .... .. ......... No service required or
suggested.
Sidewall puncture ....... A ............ Require replacement.
Sidewall with plug ...... A ............ Require replacement.
Speed rating
designations
different
on same axle ........... 2 .. Suggest repair or replacement.
Tire and wheel assembly
has excessive run-out .. B ........... ( 3) Require repair or
replacement of appropriate
part.
Tires with more than
1/4" diameter difference
on a four-wheel drive
vehicle ................ B ............ Require replacement.
Tread area puncture larger
in diameter than
manufacturer's
specifications ......... B ............ Require replacement.
Tread missing pieces

(1) - Require replacement of units where dents restrict shock
or strut piston rod movement. If dents don't restrict
movement, no service is suggested or required. Especially
critical on mono-tube shocks.
( 2) - This condition can lead to damage of the piston rod,
which, in turn, causes premature piston rod seal wear.
( 3) - Only required if replacing cartridge.
( 4) - CAUTION: If the strut cartridge has been replaced previously,
the oil on the strut housing may be filler oil. The
technician must identify the source of the oil.
( 5) - If noise is isolated to shock or strut, suggest
replacement.
( 6) - Although shocks or struts may have contributed to tire
cupping, an inspection is needed of the entire suspension
system. If the shock or strut is found to be contributing
to the tire cupping, require replacement.









\









\









\









\









\









\









\


SPINDLES
SPINDLE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Bent .................... B ............ Require replacement.
Broken .................. A ............ Require replacement.
Race seat area
undersized ............. B ............ Require replacement.
Scored .................. A .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.









\









\









\









\









\









\









\


SPRINGS - COIL, LEAF AND TORSION BAR
When springs are replaced, it is suggested, but not required,
that both springs on an axle be replaced to maintain equal height from
side to side and to provide a balanced ride and proper handling.
When variable rate springs are installed in place of
conventional coil springs, they must be installed in axle sets to
ensure proper handling, uniform ride, and proper chassis height.
Erroneous height measurements may result from: improper tire
inflation, non-standard tire or wheel size, and heavy load in vehicle
or trunk.
SPRING (COIL, LEAF AND TORSION BAR) INSPECTION

Condition Code Procedure
Air pressure incorrect .. B .................. Require repair
Bead broken ............. A ............ Require replacement.
Bead leaking, caused
by tire ................ A .. Require repair or replacement.
Bead wire/cord exposed .. A ............ Require replacement.
Cord or belt material
exposed ................ A ............ Require replacement.
Cord ply separations .... A ............ Require replacement.
Directional/asymmetrical
tires mounted
incorrectly ............ B ....... Require remounting and/or
repositioning.
Irregular tread wear,
affecting performance .. 2 ........ (1) Suggest replacement.
Load ratings less
than OEM
specifications ......... B ............ Require replacement.
Mixed tread types (all
season, performance, mud
and snow) on same axle . A ............ Require replacement.
Number of punctures
exceeds manufacturer's
limit .................. B ............ Require replacement.
Out of balance .......... B . Require rebalance of tire/wheel
assembly.
Ply separation .......... A ............ Require replacement.
Pull or lead, caused
by tire ................ A .. Require repair or replacement.
Radial and bias or
bias-belted ply tires
on same axle ........... B .. Require repair or replacement.
Radials are on the front
and not on the rear .... B ........... ( 2) Require repair or
replacement.
Run flat damage ......... A ............ Require replacement.
Shoulder cut ............ A ............ Require replacement.
Shoulder puncture ....... A ............ Require replacement.
Shoulder with plug ...... A ............ Require replacement.
Sidewall bulge .......... A ............ Require replacement.
Sidewall cut ............ A ............ Require replacement.
Sidewall indentation .... .. ......... No service required or
suggested.
Sidewall puncture ....... A ............ Require replacement.
Sidewall with plug ...... A ............ Require replacement.
Speed rating
designations
different
on same axle ........... 2 .. Suggest repair or replacement.
Tire and wheel assembly
has excessive run-out .. B ........... ( 3) Require repair or
replacement of appropriate
part.
Tires with more than
1/4" diameter difference
on a four-wheel drive
vehicle ................ B ............ Require replacement.
Tread area puncture larger
in diameter than
manufacturer's
specifications ......... B ............ Require replacement.
Tread missing pieces

BRAKE SYSTEM TROUBLE SHOOTING CHART








\









\









\









\









\









\









\







CONDITION POSSIBLE CAUSE CORRECTION








\









\









\









\









\









\









\







Brakes Pull Left
or Right Incorrect tire pressure Inflate tires to proper
pressure
Front end out of alignment See WHEEL ALIGNMENT
Mismatched tires Check tires sizes
Restricted brake lines
or hoses Check hose routing
Loose or malfunctioning
caliper See DISC BRAKES or
BRAKE SYSTEM
Bent shoe or oily linings See DRUM BRAKES or
BRAKE SYSTEM
Malfunctioning rear brakes See DRUM, DISC BRAKES
or BRAKE SYSTEM
Loose suspension parts See SUSPENSION









\









\









\









\









\









\









\







Noises Without
Brakes Applied Front linings worn out Replace linings
Dust or oil on drums See DRUM, DISC BRAKES
or rotors or BRAKE SYSTEM









\









\









\









\









\









\









\







Noises With
Brakes Applied Insulator on outboard See DISC BRAKES or
shoe damaged BRAKE SYSTEM
Incorrect pads or linings Replace pads or linings









\









\









\









\









\









\









\







Brake Rough, Chatters
or Pulsates Excessive lateral runout Check rotor runout
Parallelism not to
specifications Reface or replace rotor
Wheel bearings not adjusted See SUSPENSION
Rear drums out-of-round Reface or replace drums
Disc pad reversed, steel
against rotor Remove and reinstall
pad









\









\









\









\









\









\









\







Excessive Pedal
Effort Malfunctioning power unit See POWER BRAKES or
BRAKE SYSTEM
Partial system failure Check fluid and pipes
Worn disc pad or lining Replace pad or lining
Caliper piston stuck or

WHEEL ALIGNMENT THEORY/OPERATION
1998 Mitsubishi Montero
GENERAL INFORMATION
Wheel Alignment Theory & Operation
ALL MODELS
* PLEASE READ THIS FIRST *
NOTE: This article is intended for general information purposes
only. This information may not apply to all makes and models.
PRE-ALIGNMENT INSTRUCTIONS
GENERAL ALIGNMENT CHECKS
Before adjusting wheel alignment, check the following:
* Each axle uses tires of same construction and tread style,
equal in tread wear and overall diameter. Verify that radial
and axial runout is not excessive. Inflation should be at
manufacturer's specifications.
* Steering linkage and suspension must not have excessive play.
Check for wear in tie rod ends and ball joints. Springs must
not be sagging. Control arm and strut rod bushings must not
have excessive play. See Fig. 1.
Fig. 1: Checking Steering Linkage
* Vehicle must be on level floor with full fuel tank, no
passenger load, spare tire in place and no load in trunk.
Bounce front and rear end of vehicle several times. Confirm
