Instruments and Controls

This section gives information about
the controls and displays thatcontribute to the daily operation of

your Honda. All the essential
controls are within easy reach.

Control Locations............................ 50

Indicator Lights................................ 51

Gauges.............................................. 54
Tachometer.................................. 54

Trip Meter.................................... 54
Speedometer................................ 55

Odometer...................................... 55

Temperature Gauge.................... 55
Fuel Gauge................................... 55

Maintenance Required
Indicator.................................... 56

Controls Near the Steering

Wheel........................................ 57

Headlights.................................... 58
Daytime Running Lights............. 58
Instrument Panel Brightness..... 59
Turn Signals................................. 59

Windshield Wipers...................... 60

Windshield Washers................... 61

Rear Window Wiper and
Washer...................................... 61

Hazard Warning........................... 61

Rear Window Defogger.............. 62

Steering Wheel Adjustment....... 62

Steering Wheel Controls ................ 64
Cruise Control.............................. 64

Keys and Locks................................ 67
Keys............................................... 67

Immobilizer System..................... 68

Ignition Switch............................. 69

Power Door Locks....................... 70
Remote Transmitter.................... 71

Childproof Door Locks............... 72

Tailgate......................................... 72

Glove Box..................................... 73

Seats.................................................. 74
Passenger Seating....................... 74

Seat Adjustments......................... 74

Driver's Seat Power Height
Adjustment............................... 75

Armrests....................................... 76
Head Restraints........................... 76
Third Seat Access........................ 77

Removing the Second Seats
in the Six-Passenger Model.... 78

Folding the Second Seats
in the Seven-Passenger

Model.................................... 78

Reclining the Second Seat.......... 79
Folding the Third Seat
in All Models............................ 80

Power Windows............................... 82

Sunroof.............................................. 83

Mirrors.............................................. 84
Adjusting the Power Mirrors..... 84

Parking Brake.................................. 85

Digital Clock..................................... 86 Beverage Holder.............................. 86
Dashboard Compartment............... 88
Center Pocket.................................. 88
Vanity Mirror................................... 88
Cigarette Lighter............................. 89
Ashtrays............................................ 89 Interior Lights.................................. 90
Ceiling Lights............................... 90

Spotlights...................................... 90

Tailgate Light............................... 91 Courtesy Lights........................... 91

Instruments and ControlsProCarManuals.comMain Menu s t

Controls Near the Steering Wheel

The two levers on the steering column contain controls for driving
features you use most often. The left lever controls the turn signals,
headlights, and high beams. The right lever controls the windshield
washers and wipers.
The rear window defogger switch and hazard warning switch are on
the dashboard
under the center air

vent.

The controls near the left air vent are for the sunroof, cruise control
and instrument panel brightness.
The tilt adjustment lever on the underside of the steering column
allows you to tilt the steering wheel. HAZARD WARNING LIGHT

WINDSHIELD

WIPERS/WASHERS

SUNROOF
SWITCH
SHIFT LEVER

REAR WINDOW

DEFOGGER

CRUISE
CONTROL
INSTRUMENT
BRIGHTNESS
HEADLIGHTS/

TURN SIGNALS
TILT

ADJUSTMENT

HORN

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Windshield Wipers

The right lever controls the wind- shield wipers and washers. The
rotary switch at the end of the lever
has three positions: INT: intermittent : low speed
: high speed
In intermittent, the wipers operate
every few seconds. In low speed and
high speed, the wipers run continu-
ously.
On U.S. models

In intermittent, you can vary how

often the wipers sweep the
windshield by turning the INT TIME
ring. To operate the wipers in mist mode,

push the control lever down. The

wipers run at high speed until you
release the lever. This gives you a
quick way to clear the windshield.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Windshield Washers
To clean the windshield, pull back on the wiper control lever. The washersspray until you release the lever. The
wipers run at low speed while you're pulling the lever, then complete one
more sweep of the windshield after
you release it. Rear Window Wiper and Washer
The rear window wiper switch is located next to the windshield wiper
switch.

To activate the rear windshield wiper, turn the switch "ON". If you wish touse the wiper and washer, turn and
hold the switch one position up from "ON". To use the washer only, turn
and hold the switch one position
down from "OFF". Hazard Warning
Push the red button to the left of the
clock to turn on the hazard warning
lights (four-way flashers). This causes all four outside turn signals
and both indicators in the instrument
panel to flash. Use the hazard
warning lights if you need to park in a dangerous area near heavy traffic,
or if your vehicle is disabled.
Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Driving in Bad Weather

Visibility — Being able to see clearly in all directions and being
visible to other drivers are important in all weather conditions. This is
more difficult in bad weather. To beseen more clearly during daylight
hours, turn on your headlights.
Inspect your windshield wipers and
washers frequently. Keep the wind- shield washer reservoir full of the
proper fluid. Have the windshield
wiper blades replaced if they start to streak the windshield or leave parts
unwiped. Use the defrosters and air
conditioning to keep the windows
from fogging up on the inside (see

page 99).
Traction — Check your tires
frequently for wear and proper
pressure. Both are important in
preventing "hydroplaning" (loss of
traction on a wet surface). In the
winter, mount snow tires on all four
wheels for the best handling.
Watch road conditions carefully, they can change from moment to
moment. Wet leaves can be as slip-
pery as ice. "Clear" roads can have
patches of ice. Driving conditionscan be very hazardous when the
outside temperature is near freezing.
The road surface can become covered with areas of water puddles
mixed with areas of ice, so your
traction can change without warning.
Be careful when downshifting. If
traction is low, you can lock up the drive wheels for a moment and cause
a skid. Be very cautious when passing, or
being passed by other vehicles. The spray from large vehicles reduces
your visibility, and the wind buffeting can cause you to lose control.
DrivingProCarManuals.comMain Menu Table of Contents s t

Index

Warning Beepers Key in Ignition.............................. 70

Seat Belts...................................... 52

WARNING, Explanation of.............. ii

Warning Labels, Location of.......... 48

Warranty Coverages*................... 263
Washer, Windshield Checking the Fluid Level......... 181
Operation...................................... 60
Washing.......................................... 214
Waxing and Polishing................... 215

Wheels
Adjusting the Steering................ 62
Alignment and Balance............. 198Compact Spare........................... 222
Wrench....................................... 225
Windows Cleaning...................................... 217Operating the Power................... 82
Rear, Defogger............................ 62
Windshield Cleaning........................................ 60
Defroster...................................... 99 Wipers, Windshield
Changing Blades........................ 191
Operation...................................... 60
Rear Windshield Wiper and Washer...................................... 61
Worn Tires..................................... 198
Wrecker, Emergency Towing...... 244
* : U.S. and Canada onlyProCarManuals.comMain Menu s t
