Changing a Flat Tire
WHEEL NUTS
9. Loosen the five wheel nuts 1/2 turn with the wheel wrench.
U.S. LX and all Canadian models:
Do not attempt to forcibly pry the
wheel cover off with a screwdriver or other tool. The wheel cover
cannot be removed without first
removing the wheel nuts. 10.Find the jacking point nearest the
wheel you are removing. Place the
jack under the jacking point. Turn the end bracket clockwise until
the top of the jack contacts the
jacking point. Make sure the
jacking point tab is resting in the
jack notch. EXTENSION
WHEEL WRENCH
11. Use the extension and wheel
wrench as shown to raise the
vehicle until the flat tire is off the
ground.
CONTINUED
Taking Care of the Unexpected
JACKING POINTProCarManuals.comMain Menu Table of Contents s t
Index
Ignition
Keys............................................... 67
Switch............................................ 69
Timing Control System............. 256
Important Safety Precautions .......... 4
Indicator Lights, Instrument Panel.............................................. 51
Infant Restraint................................ 27
Inflation, Proper Tire .................... 196
Inside Mirror.................................... 84
Inspection, Tire.............................. 198
Instrument Panel............................. 51
Instrument Panel Brightness......... 59
Interior Cleaning............................ 216
Interior Lights.................................. 90 Introduction......................................... i
Jacking up the Car......................... 225
Jack, Tire........................................ 223
Jump Starting................................. 230
Keys................................................... 67
Label, Certification........................ 246
Lane Change, Signaling.................. 59
Lap Belt............................................. 42
Lap/Shoulder Belts......................... 41
Leaking of Exhaust into Car.......... 47
Lighter, Cigarette............................ 89
Lights
Headlight Aiming...................... 204
Bulb Replacement..................... 206
Indicator........................................ 51
Parking.......................................... 58
Turn Signal................................... 59
LOCK (Ignition Key Position)....... 70
Locks
Anti-theft Steering Column........ 50Fuel Fill Door............................. 129
Glove Box..................................... 73
Power Door................................... 70
Tailgate ...................................... 72
Low Coolant Level......................... 177
Lo
w Oil
Pressure Indicator.... 50, 234
Lubricant Specifications Chart.... 248
Luggage.......................................... 137
Maintenance..................................
. 159
Owner Maintenance Checks.... 171
Record.................................. 169- 170
Required Indicator......................
. 56
Safety........................................... 160
Schedule.............................. 164- 168
Malfunction Indicato
r Lamp.. 52, 236
Maximum Allowable Speeds........ 145
Meters, Gauges................................ 55
Methanol in Gasoline.................... 253
Mirrors, Adjusting........................... 84
Neutral Gear Position.................... 144
New Vehicle Break-in ................... 128
NOTICE, Explanation of................... ii
Numbers, Identification................ 246
CONTINUED
