1998 DODGE RAM 1500 Power Window circuit

Component Page
Fuel Pump Module.................. 8W-80-66
Fuel Pump Motor (Diesel)............ 8W-80-66
Generator......................... 8W-80-67
Glove Box Lamp And Switch.......... 8W-80-67
Hands Free Module (Telematics)....... 8W-80-67
Headlamp Switch................... 8W-80-68
Headlamp-Left..................... 8W-80-68
Headlamp-Right.................... 8W-80-68
Heated Seat Cushion-Driver........... 8W-80-68
Heated Seat Cushion-Passenger........ 8W-80-69
Heated Seat Switch-Driver............ 8W-80-69
Heated Seat Switch-Passenger......... 8W-80-69
Horn Switch....................... 8W-80-69
Horn-High Note.................... 8W-80-70
Horn-Low Note..................... 8W-80-70
Idle Air Control Motor (3.7L/4.7L)...... 8W-80-70
Ignition Switch..................... 8W-80-70
Inlet Air Temperature Sensor.......... 8W-80-71
Input Speed Sensor (45RFE).......... 8W-80-71
Instrument Cluster C1............... 8W-80-71
Instrument Cluster C2............... 8W-80-72
Instrument Cluster C3............... 8W-80-72
Intake Air Temperature Sensor (Gas).... 8W-80-73
Intake Air Temperature/Manifold Absolute
Pressure Sensor (Diesel)............ 8W-80-73
Integrated Power Module C1.......... 8W-80-73
Integrated Power Module C2.......... 8W-80-74
Integrated Power Module C3.......... 8W-80-74
Integrated Power Module C4.......... 8W-80-75
Integrated Power Module C5.......... 8W-80-75
Integrated Power Module C6.......... 8W-80-76
Integrated Power Module C7.......... 8W-80-76
Knock Sensor (3.7L)................. 8W-80-77
Knock Sensor-Left (5.7L)............. 8W-80-77
Knock Sensor-Right (5.7L)............ 8W-80-77
License Lamp-Left.................. 8W-80-77
License Lamp-Right................. 8W-80-77
Lift Pump Motor (Diesel)............. 8W-80-78
Line Pressure Sensor (NGC)........... 8W-80-78
Lumbar Motor-Driver................ 8W-80-78
Lumbar Motor-Passenger............. 8W-80-78
Manifold Absolute Pressure Sensor
(NGC).......................... 8W-80-79
Mode Door Actuator 1 (Panel To Floor) . . . 8W-80-79
Mode Door Actuator 2 (Defrost To Floor) . 8W-80-79
Multi-Function Switch............... 8W-80-79
Natural Vacuum Leak Detection Assembly
(NGC).......................... 8W-80-80
Output Speed Sensor (45RFE)......... 8W-80-80
Output Speed Sensor (47RE).......... 8W-80-80
Overhead Map/reading Lamp (Except
Base).......................... 8W-80-80
Oxygen Sensor 1/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 1/2 Downstream (NGC) . . 8W-80-81Component Page
Oxygen Sensor 2/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 2/2 Downstream (NGC) . . 8W-80-81
Park/Turn Signal Lamp-Left Front...... 8W-80-82
Park/Turn Signal Lamp-Right Front.... 8W-80-82
Passenger Blend Door Actuator (Dual-
Zone).......................... 8W-80-82
Passenger Lumbar Switch............ 8W-80-82
Power Mirror-Left................... 8W-80-82
Power Mirror-Right................. 8W-80-83
Power Outlet...................... 8W-80-83
Power Outlet-Console (Except Base)..... 8W-80-83
Power Seat Motor-Driver Front Vertical . . 8W-80-83
Power Seat Motor-Driver Horizontal.... 8W-80-84
Power Seat Motor-Driver Rear Vertical . . 8W-80-84
Power Seat Motor-Passenger Front
Vertical......................... 8W-80-84
Power Seat Motor-Passenger Horizontal . 8W-80-84
Power Seat Motor-Passenger Rear
Vertical......................... 8W-80-84
Power Seat Switch-Driver............ 8W-80-85
Power Seat Switch-Passenger.......... 8W-80-85
Power Steering Pressure Switch (NGC) . . 8W-80-85
Power Window Circuit Breaker........ 8W-80-86
Power Window Motor-Driver.......... 8W-80-86
Power Window Motor-Left Rear........ 8W-80-86
Power Window Motor-Passenger........ 8W-80-86
Power Window Motor-Right Rear....... 8W-80-87
Power Window Switch-Left Rear....... 8W-80-87
Power Window Switch-Passenger....... 8W-80-87
Power Window Switch-Right Rear...... 8W-80-87
Powertrain Control Module C1 (NGC) . . . 8W-80-88
Powertrain Control Module C2 (NGC) . . . 8W-80-89
Powertrain Control Module C3 (NGC) . . . 8W-80-90
Powertrain Control Module C4 (NGC) . . . 8W-80-91
Radio C1 (Except Infinity)............ 8W-80-92
Radio C1 (Infinity).................. 8W-80-92
Radio C2.......................... 8W-80-93
Recirculation Door Actuator........... 8W-80-93
Remote Radio Switch-Left............ 8W-80-93
Remote Radio Switch-Right........... 8W-80-93
Seat Belt Switch-Driver.............. 8W-80-94
Seat Belt Tensioner Reducer (Standard
Cab)........................... 8W-80-94
Seat Belt Tensioner-Driver............ 8W-80-94
Seat Belt Tensioner-Passenger......... 8W-80-94
Seat Heater Interface Module.......... 8W-80-94
Sentry Key Immobilizer Module (SKIM) . . 8W-80-95
Side Impact Sensor-Left.............. 8W-80-95
Side Impact Sensor-Right............. 8W-80-95
Speaker-Center Instrument Panel...... 8W-80-95
Speaker-Left Front Door.............. 8W-80-95
Speaker-Left Instrument Panel........ 8W-80-96
Speaker-Left Rear.................. 8W-80-96
Speaker-Right Front Door............ 8W-80-96
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

C301 - (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 P195 18LG/YL (POWER WINDOWS/
LOCKS)
3 P72 18TN/GY (POWER WINDOWS/
LOCKS)
4 X154 18GY/YL
5 X156 18GY/LB
6 P74 18TN/OR (POWER WINDOWS/
LOCKS)
7 Q15 14OR/LB (POWER WINDOWS/
LOCKS)
8-
9-
10 Z74 20BK/WT (EXCEPT POWER WIN-
DOWS/LOCKS)
10 Z461 20BK/DG (POWER WINDOWS/
LOCKS)
C302 (SLT) - (BODY SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9 G162 20VT/LB
10 P392 18LG/DB
11 Z216 18BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 33

C302 - BLACK (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9-
10 P392 18LG/DB
11 Z216 20BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
C304 - (BODY SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (SLT)
3 P72 18TN/GY (SLT)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (SLT)
7 F30 12PK/YL (SLT)
8 Q15 12OR/LB (SLT)
9 A930 18RD (SLT)
10 Z75 20BK/VT
C304 - (DRIVER DOOR SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (POWER WINDOW/
LOCKS)
3 P72 20TN/GY (POWER WINDOW/
LOCKS EXCEPT SECURITY)
3 P72 18 TN/GY (SECURITY)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (POWER WINDOW/
LOCKS)
7 F30 14PK/YL (POWER WINDOW/
LOCKS)
8 Q15 14OR/LB (POWER WINDOW/
LOCKS)
9 A930 18RD (POWER WINDOW/LOCKS)
10 Z75 20BK/VT (EXCEPT SECURITY)
10 Z463 20BK/LB (SECURITY)
8W - 80 - 34 8W-80 CONNECTOR PIN-OUTSDR

C306 - (REAR DOOR SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/GY
3 P393 18LG (POWER WINDOW/LOCKS)
4 P5 18TN/OR (POWER WINDOW/LOCKS)
5 Q15 14OR/LB (POWER WINDOW/
LOCKS)
6 Q411 14OR/WT (POWER WINDOW/
LOCKS)
7 Q611 14OR/GY (POWER WINDOW/
LOCKS)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C306 - NATURAL (BODY SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/OR
3 P393 18LG (SLT)
4 P5 18TN/OR (SLT)
5 Q15 14OR/LB (SLT)
6 Q411 14OR/WT (SLT)
7 Q611 14OR/GY (SLT)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C308 - (BODY SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 G162 20VT/LB (SLT)
3 D25 20WT/VT
4 X154 18GY/YL
5 G160 20VT/LG (SLT)
6 G76 20TN/YL
7 F201 18PK/OR
8 P392 18LG/DB (SLT)
9 G778 18VT/LB (SLT)
10 F21 20PK/DG (SLT)
11 -
12 -
13 -
14 X206 18DG/LG
15 X296 18DG/GY
16 -
17 -
18 Z105 18BK
19 X156 18GY/LB
8W - 80 - 36 8W-80 CONNECTOR PIN-OUTSDR

C316 - (PASSENGER SEAT SIDE)
CAV CIRCUIT
1 P89 20LG/OR
2 P54 20OR/LG
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT
6-
C319 - (CENTER CONSOLE SIDE)
CAV CIRCUIT
1 Z939 18BK
2 A405 18RD/DB
C319 - (SEAT JUMPER SIDE)
CAV CIRCUIT
1 A405 12RD/DB (EXCEPT HEATED SEAT)
1 Z939 14BK (HEATED SEAT)
2 Z939 14BK (EXCEPT HEATED SEAT)
2 A405 12RD/DB (HEATED SEAT)
C320 - (RIGHT REAR DOOR SIDE)
CAV CIRCUIT
1 Z72 20LG/BK
2 G76 20VT/GY
3 P392 18LG (POWER WINDOW/LOCKS)
4 G778 18TN/OR (POWER WINDOW/
LOCKS)
5 Q15 14TN/LG (POWER WINDOW/
LOCKS)
6 Q412 14OR/WT (POWER WINDOW/
LOCKS)
7 Q612 14OR/GY (POWER WINDOW/
LOCKS)
8 X296 18GY/DG
9 X206 18GY/LG
10 -
8W - 80 - 40 8W-80 CONNECTOR PIN-OUTSDR

DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57

HORN-HIGH NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z299 18BK/OR GROUND
HORN-LOW NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z298 18BK/DB GROUND
IDLE AIR CONTROL MOTOR (3.7L/4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K961 18BR/VT IAC RETURN
2 K61 18VT/GY IAC MOTOR CONTROL
IGNITION SWITCH - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 A970 10RD FUSED B(+)
2 F1 16PK/WT FUSED IGNITION SWITCH OUTPUT (OFF-RUN-START)
3 F951 16PK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
4 A951 16RD FUSED B(+)
5 G15 20VT/TN KEY IN IGNITION SWITCH SENSE
6 Z943 20BK GROUND
7 A921 16RD FUSED B(+)
8 C7 10DB BLOWER MOTOR FEED
9 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 F991 10PK/YL (POWER WINDOWS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 A981 14RD FUSED B(+)
12 A991 10RD (POWER WINDOWS) FUSED B(+)
13 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
14 F922 16PK/YL FUSED IGNITION SWITCH OUTPUT (RUN)
8W - 80 - 70 8W-80 CONNECTOR PIN-OUTSDR

INTEGRATED POWER MODULE C6 - BLACK 15 WAY
CAV CIRCUIT FUNCTION
1- -
2 A400 14TN/RD FUSED B(+)
3- -
4 K342 16BR/WT ASD RELAY OUTPUT
5- -
6- -
7- -
8- -
9- -
10 A961 14RD (DIESEL) FUEL HEATER RELAY OUTPUT
10 C123 16LB/WT (NGC) CONDENSER FAN RELAY OUTPUT
11 A960 14RD (DIESEL) FUSED B(+)
11 A16 16RD/BR (NGC) FUSED B(+)
12 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 - -
14 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
15 - -
INTEGRATED POWER MODULE C7 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 T750 14YL/GY STARTER MOTOR RELAY OUTPUT
2 W3 16BR/WT WIPER RELAY LOW SPEED OUTPUT
3 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 A930 18RD FUSED B(+)
5- -
6 L43 18WT/DB LEFT LOW BEAM OUTPUT
7 L34 18WT/GY RIGHT HIGH BEAM OUTPUT
8- -
9 A109 16OR/RD (GAS) FUEL PUMP RELAY OUTPUT
10 - -
11 K51 20BR/WT (GAS) ASD RELAY CONTROL
13 - -
14 - -
15 L33 18WT/LG LEFT HIGH BEAM OUTPUT
16 - -
16 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT
17 - -
17 C15 16DB/WT REAR WINDOW DEFOGGER RELAY OUTPUT
18 - -
19 K31 20BR FUEL PUMP RELAY CONTROL
20 - -
20 L89 18WT/YL (FOG LAMPS) FOG LAMP RELAY OUTPUT
21 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
22 L44 18WT/TN RIGHT LOW BEAM OUTPUT
23 T41 20YL/DB (EXCEPT NGC) TRS T41 SENSE
23 T752 20DG/OR (NGC) STARTER RELAY CONTROL
24 A944 20RD FUSED B(+)
26 - -
8W - 80 - 76 8W-80 CONNECTOR PIN-OUTSDR
