1997 TOYOTA TACOMA instrument panel

88To check the indicator bulb, turn the igni-
tion key to the ONº position, but do not
start the engine.
Do not keep driving with the
differential lock switch on.
CAUTION
!
When parking, firmly apply the park-
ing brake to avoid inadvertent creep- ing.
To set: Pull out on the lever. For better
holding power, first depress the brake
pedal and hold it while setting the parking brake.
To release: Press the lock release button,
turn the lever, and push it in.
To remind you that the parking brake is
set,
the parking brake reminder light in the
instrument panel remains on until you re-lease the parking brake.
Before driving, be sure the parking
brake is fully released and the
parking brake reminder light is off. CAUTION
!
Parking brake

103
Fan speed selector
Move the lever to adjust the fan speedÐto the right to increase, to the left to de-crease.
Temperature selector
Move the lever to adjust the temperature Ðto the right to warm, to the left to cool.
Air flow selector
Move the l
ever to select the vents used for
air flow.
1. PanelÐ Air flows mainly from the in-
strument panel vents.
2. Bi-levelÐ Air flows from both the floor
vents and the instrument panel vents.
3. FloorÐ Air flows mainly from the floor
vents.
4. Floor/WindshieldÐ Air flows mainly
from the floor vents and windshield vents.
5. WindshieldÐ Air flows mainly from
the windshield vents. For details about air flow selector settings, see the illustration after A/Cº button.
Vehicles with A/Cº button indicatorÐ
Moving the airflow selector lever to wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
A/Cº button indicator comes on regard- less of whether or not the A/Cº button is pressed in. This is to clear up the front
view more quickly. When the A/Cº button is not pressed in, moving the air flow control lever to anoth-
er position turns off the air conditioning.

Part 1Clock
109
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-8 Other equipment
Clock
Cigarette lighter and ashtray
Glovebox
Cup holder
Floor mat
The digital clock indicates the time.
The key must be in the ``ACCº or ``ON'' position.
To reset the hour: Push the Hº button.
To reset the minutes: Push the Mº button.
If quick adjustment to a full hour is de- sired, push the :00º button. When the instrument panel lights are turned
on, the brightness of the time indi-
cation will be reduced.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00. Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (oneo'clock). When the instrument panel lights turned
on, the brightness of the time indication
will be reduced.

11 0
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automati-
cally pops out ready for use.
If the engine is not running, the key must be in the ACCº position.
Do not hold the cigarette lighter pressed in.
Use a Toyota genuine cigarette lighter or equivalent for replacement.ASHTRAY
To use the ashtray, pull it out. When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the
ashtray, close the ash-
tray cover completely.
To remove the ashtray, press down on the lock spring plate and pull out.To reduce the chance of injury in
case of an accident or sudden stop
while driving, always close the ash-
tray cover completely after use. CAUTION
!
To open the glovebox door, pull the le- ver
.
On some models, the glovebox light will come on when the glovebox is open withthe instrument panel lights on.
To reduce the chance of injury in
case of an accident or sudden stop,
always keep the glovebox door
closed while driving. CAUTION
!
Cigarette lighter and ashtray
Glovebox

122When stowing luggage or cargo in the ve-
hicle, observe the following:
Put luggage or cargo in the trunk when
at all possible. Be sure all items are se- cured in place.
Be careful to keep the vehicle bal-
anced. Locating the weight as far for-
ward as possible helps maintain bal- ance.
For better fuel economy, do not carryunneeded weight.
CAUTION!
To prevent luggage or packages
from sliding forward during brak-
ing, do not stack anything behind
the front seats higher than the
seatbacks (Xtra-cab models).Keep luggage or packages low, as
close to the floor as possible.
Never allow anyone to ride in the
rear deck. It is not designed for
passengers. They should ride in
their seats with their seat belts
properly fastened. Otherwise,
they are much more likely suffer
serious bodily injury, in the event
of sudden braking or a collision.
Do not drive with objects left on
top of the instrument panel. They
may interfere with the driver's
field of view. Or they may move
during sharp vehicle acceleration
or turning, and impair the driver's
control of the vehicle. In an acci-
dent they may injure the vehicle occupants.
Do not load the vehicle beyond the
vehicle capacity weight specified in
Part 8.
NOTICE
The rear step bumper is for rear end
protection and easier step-up load- ing.
CAUTION!
Do not allow more than one per-
son to get on the rear step bumper at a time. It is designed for only
one person.
Never drive the vehicle with any-
one on the rear step bumper.
Luggage stowage precautions
Rear step bumper

123
The vehicle identification number
(VIN) is the legal identifier for your ve- hicle. This number is on the left top of
the instrument panel, and can be seen
through the windshield from outside.
This is the primary identification number
for your Toyota. It is used in registering the
ownership of your vehicle.The vehicle identification number (VIN) is
also on the Certification Label.2RZ-FE and 3RZ-FE engines
5VZ-FE engine
-Engine number
Your Toyota's identification-
-V ehicle identification number

164
Do not use dye or bleach on thebeltsÐit may weaken them.
NOTICE
Windows
The windows may be cleaned with any
household window cleaner.
When cleaning the inside of the
windows, be careful not to scratch
or damage the heater wires on therear window.
NOTICE
Air conditioning control panel, car au-
dio, instrument panel, console panel,
and switches Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off any dirt.

Do not use organic substances(solvents, kerosene, alcohol, gas-
oline, etc.) or alkaline or acidicsolutions. These chemicals cancause discoloring, staining or
peeling of the surface.
NOTICE
If you use cleaners or polishingagents, make sure their ingredi-
ents do not include the sub-
stances mentioned above.
If you use a liquid car freshener,do not spill the liquid onto the ve-
hicle's interior surfaces. It maycontain the ingredients men-
tioned above. Immediately clean
any spill using the method men-tioned above.
Leather Interior
The leather upholstery may be cleaned
with neutral detergent for wool. Remove dirt using a soft cloth dampened
with 5 % Solution of neutral detergent for
wool. Then thoroughly wipe off all traces
of detergent with a clean damp cloth.
After cleaning or whenever any part of the
leather gets wet, dry with a soft clean
cloth. Allow the leather to dry in a venti-
lated shaded area.

If a stain should fail to come outwith a neutral detergent, apply a
cleaner that does not contain anorganic solvent.
NOTICE
Never use organic substancessuch as benzine, alcohol or gaso-
line, or alkaline or acid solutionsfor cleaning the leather as thesecould cause discoloring.
Use of a nylon brush or synthetic
fiber cloth, etc. may scratch thefine grained surface of the leather.
Mildew may develop on soiled
leather upholstery. Be especiallycareful to avoid oil spots. Try to
keep your upholstery alwaysclean.
Long exposure to direct sunlightmay cause the leather surface to harden and shrink. Keep your ve-hicle in a shaded area, especially
in the summer.
The interior of your vehicle is aptto heat up on hot summer days, so
avoid placing on the upholsteryitems made of vinyl or plastic orcontaining wax as these tend to
stick to leather when warm.
Improper cleaning of the leatherupholstery could result in discol-
oration or staining.

212
Engine compartment (Canada)
6. HORN 15 A: Emergency flashers,
horns
7. DOME 15 A: Car audio system, power
antenna, interior light, clock, ignition
switch light, personal ligths, door cour-
tesy lights
8. TAIL 10 A: Tail lights, license plate
lights
9. PANEL 10 A: Emergency flashers,
heater cotnrol system, air conditioning
cooling system, gauges and meters,
clock, car audio system overdrive indi-
cator light, glovebox light, cigarette
lighter, instrument panel lightsInstrument panel
10. A/C 10 A: Air conditionin cooling sys-
tem
11. HEAD (RH) 10 A: Right-hand head-
light
12. HEAD (LH) 10 A: Left-hand headlight
13. HEAD (HI RH) 10 A: Right-hand
headlight (high beam), hi-beam indi-
cator light
14. HEAD (HI LH) 10 A: Left-hand head-
light (high beam)
15. HEAD (LO RH) 10 A: Right-hand
headlight (low beam)
16. HEAD (LO LH) 10 A: Left-hand head-
light (low beam) 17. DRL 7.5 A:
Daytime running light sys-
tem
18. 4WD 15 A: A.D.D. control system,
four-wheel drive control system, rear
differential lock system
19. GAUGE 10 A: Gauges and meters,
back-up lights, cruise control system,
power antenna, power door lock con- trol system, electronically controlled
automatic transmission system, start-
ing system, charging system, heater control system
20. TURN 10 A: Turn signal lights
21. ECU-IG 15 A: Cruise control system,
anti-lock brake system, shift lock sys-tem
22. WIPER 20 A: Windshield wipers and
washer
23. IGN 7.5 A: Discharge warning light,
SRS airbag system
24. RADIO 7.5 A: Car audio system, pow-
er antenna
25. CIG 15 A: Cigarette lighter, clock,
power rear view mirrors, back-up lights, shift lock system
26. ECU-B 15 A: SRS airbag warning
light, daytime running light system, cruise control syste, anti-lock brake system
