1997 TOYOTA TACOMA instrument panel

Part 11
OPERATION OF INSTRUMENTSAND CONTROLSÐ
Chapter 1-1 Overview of instruments and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the instrument panel

21. Side vent
2. Instrument cluster
3. Automatic transmisssion selector
lever (column shift)
4. Center vents
5. Personal lights or interior light
6. Glovebox
7. Power door lock switch
8. Power window switches
9. Manual transmission gear shift lever or autmatic transmission selector lever (floor shift)
10. Front drive control lever 11. Tilt steering lock release lever
12. Power rear view mirror control switch
Instrument panel overview

3
1. Headlight and turn signal switch
2. Wiper and washer switches
3. Driving pattern selector button
4. Emergency flasher switch
5. Clock
6. Cup holder
7. Air conditioning controls
8. Car audio
9. Ashtray
10. Cigarette lighter 11. Parking brake lever
12. Ignition switch
13. Cruise control switch
14. Hook lock release lever
15. Rear differential lock button
16. Instrument panel light control knob
17. Clutch start cancel switch

6
Anti-lock brake system warning light * 1
Brake system warning light * 1
Seat belt reminder light* 1
Discharge warning light* 1
Low oil pressure warning light* 1
Malfunction indicator light* 1
Low fuel level warning light * 1
SRS airbag warning light* 1 Automatic transmission fluid
temperature warning light*
1
Turn signal indicator lights
Headlight high beam indicator light
Over-drive indicator light
Unengaged Parkºwarning light * 1
Low windshield washer fluid level light*1
Driving pattern (POWERº
model) indicator light
Four-wheel drive indicator light
Automatic transmission indicator lights
Indicator symbols on the instrument panel

Part 1Seats Front seatsÐ
ÐSeat adjustment precautions
19
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-3 Seats, Seat belts, Steering wheel and Mirrors
Seats
Front seats
Rear seats
Head restraints
Armrest
Seat belts
SRS airbags
Child restraint
Tilt steering wheel
Outside rear view mirrors
Anti-glare inside rear view mirror
While the vehicle is being driven, all ve-
hicle
occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belt provided.
CAUTION
Do not drive unless the occupants
are properly seated. Do not allow
sitting on top of a folded-down
seatback, or in the luggage
compartment. Per sons not proper-
ly seated and not properly re-
strained by seatbelts can be se-
verely injured in the event of emer-
gency braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Severe in-
juries can occur in the event of emergency braking or a collision.! Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel
controls are within easy reach of the
driver.CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be careful not to hit the seat against a passen- ger or luggage.
After adjusting the seat position,
try sliding it forward and backward
to make sure it is locked in position.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats
as they may interfere with the seat-
lock mechanism or unexpectedly
push up the seat position adjusting lever; the seat may suddenly move,
causing the driver to lose control of
the vehicle.!

Part 1Headlights and turn signals
51
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-4
Lights and Wipers
Headlights and turn signals
Emergency flashers
Instrument panel light control
Interior light
Personal light
Ignition switch light
Windshield wipers and washer
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob. Position 1ÐParking, tail, license plate,
side marker and instrument panel lights Position 2ÐHeadlights and all of the above If you turn the ignition switch to the
LOCKº position with the headlights lefton, a a buzzer reminds you to turn the
lights off
when you open the driver's door.
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when theengine is not running.
Daytime running light system (Canada only)
The headlights turn on when the parking brake is released with the engine started,
even with the light switch in the OFFº position. They will not go off until the igni-
tion switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the position 2 to turn
to full intensity for driving at night.

52
High-Low beamsÐFor high beams,
turn the headlights on and push the lever away from you (position 1). Pull the lever
toward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will tell
you that the high beams are on.
Flashing the high beam headlights
(position 3) ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights with knob turned to OFFº.TURN SIGNAL
To signal a turn, push the headlight/
turn signal lever up or down to posi-
tion 1. The key must be in the ONº position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position 2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal bulbis burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn other drivers if your vehicle must be
stopped where it might be a traf fic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat- ing. Emergency flashers

53
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when the engine is not running.
To adjust the brightness of the instru-
ment panel lights, turn the knob.Front light
Rear light (Xtra-cab models)
Instrument panel light control Interior light
