1997 TOYOTA PASEO Owners Manual

95
Heating
For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone)
Air intake -FRESH (outside air)
Air flow -FLOOR
Air Conditioning -OFF
For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh afterthe vehicle interior has been warmed.
Press the A/Cº button on for dehumid-
ified heating.
Choose floor/windshield air flow toheat the vehicle interior while defrost-ing or defogging the windshield. Air conditioning For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards COLD
(blue zone)
Air intake -FRESH (outside air)
Air flow -PANEL
Air Conditioning -ON For quick cooling, move the air intake
selector to recirculate for a few min-utes.
Ventilation
For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards COLD
(blue zone)
Air intake -FRESH (outside air)
Air flow -PANEL
Air Conditioning -OFF
Defogging The inside of the windshield For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone) to heat; COLD (blue zone) to
cool
Air intake -FRESH (outside air)
Air flow -WINDSHIELD
Air Conditioning -ON
On humid days, do not blow cold air on
the windshieldÐthe difference be- tween the outside and inside tempera-
tures could make the fogging worse.
Defrosting The outside of the windshield For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone)
Air intake -FRESH (outside air)
Air flow -WINDSHIELD
Air conditioning-OFF
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.

96
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.
ÐSide vents

Part 1Clock Cigarette lighter and ashtray
97
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-8 Other equipment
Clock
Cigarette lighter and ashtray
Glovebox
Cup holder
Floor mat
The digital clock indicates the time.
The key must be in the ACCº or ONº position.
To reset the hour: Push the Hº button.
To reset the minutes: Push the Mº button.
Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one o'clock). When the instrument panel lights are turned on, the brightness of the time indi- cation will be reduced.CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automati-
cally pops out ready for use.
If the engine is not running, the key must be in the ACCº position.
Do not hold the cigarette lighter pressed in.
Use a Toyota genuine cigarette lighter or equivalent for replacement.

98
ASHTRAY
To use the ashtray, pull it out. When finished wiith your cigarette, thor- oughly extingish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the lock spring plate and pull out.
To reduce the chance of injury in
case of an accident or sudden stop while driving, always push the ash-tray back in completely after using.
CAUTION
!
Coupe
Convertible To use the glovebox, do this. CoupeÐ
To open the glovebox door, compress the lock release buttons. ConvertibleÐ
To open: Compress the lock release but- tons.
To lock: Insert the master key and turn it clockwise.
To reduce the chance of injury in
case of an accident or sudden stop,
always keep the glovebox door
closed while driving.
CAUTION
!
Glovebox

99
The cup holder is designed for holding
cups or drink-cans fits snugly in its holes.
To use the cup holder, pull it out.
Do not place anything else on the
cup holder, as such item may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or
an accident.
Keep the cup holder shut when not
in use. CAUTION
!
Use a floor mat of the correct size.
If the floor mat has a hole, then it is de-
signed for use with a locking clip. Fix thefloor mat and locking clip into the hole in the floor carpet.
Make sure the floor mat is properly
placed on the floor carpet. If the
floor mat slips and interferes with
the movement of the pedals duringdriving, it may cause an accident.
CAUTION
!
Floor mat
Cup holder

100

Part 2Break-in periodFuel
101
INFORMATION
BEFORE DRIVING
YOUR TOYOTA
Break-in period
Fuel
Operation in foreign countries
Three-way catalytic converter
Engine exhaust cautions
Facts about engine oil consumption
Twin ground electrode spark plugs
Brake system
Brake pad wear limit indicators
Luggage stowage precautions
Your Toyota's idenitification
Theft prevention labels
Suspension and chassis
Types of tires
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break-in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of your vehicle:
Do not drive over 88 km/h (55 mph).
Run the engine at moderate speed be- tween 2000 and 4000 rpm.
Avoid full-throttle starts.
Try to avoid hard stops during the first
300 km (200 miles).
Do not drive slowly with the manual
transmission in a high gear.
Do not drive for a long time at any
single speed, either fast or slow. FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mixups, your
Toyota has a new smaller fuel tank open- ing.
The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
Do not use leaded gasoline. Use of
leaded gasoline will cause the
three-way catalytic converter tolose its effectiveness and the emis- sion control system to function im-properly. Also, this can increase maintenance costs.
NOTICE
OCTANE NUMBER
Select Research Octane Number 91
(Octane Rating 87) or higher.
Use of unleaded fuel with an octane num- ber rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage.

102If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady sp
eed on level roads, consult your
Toyota dealer.
However, now and then, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is no cause
for concern.
GASOLINES CONTAINING DETER-
GENT ADDITIVES
Toyota recommends use of gasolines
that contain detergent additives to
avoid build-up of engine deposits.
For further details, ask your Toyota dealer
or a local gasoline retailer.
GASOLINES CONTAINING MTBE
Gasolines that contain MTBE (Methyl
Tertiary-Butyl Ether) are available in
the market. If you use a gasoline mixed
with MTBE, make certain that it does
not contain more than 15% of MTBE.
If the use of gasolines containing MTBE causes poor driveability and/or poor fuel
economy, you should discontinue the use
of fuels containing MTBE. If you use gasohol in your Toyota, be sure that it is unleaded, has an octane
rating no lower than 87 and does not
contain more than 10% ethanol.
Gasohol is a
mixture of gasoline and etha-
nol.
Toyota does not recommend the use of
gasolines containing methanol. If you use
gasoline containing methanol, use only
gasoline meeting the requirements above
and also containing less than 5% metha-
nol with cosolvents and corrosion inhibi-
tors for methanol.

Do not use gasohol other thanstated above. It will cause fuel
system damage or vehicle perfor-
mance problems.
If driveability problems are en-countered (poor hot starting, va-porizing, engine knock, etc), dis-continue the use.
Take care not to spill gasohol dur-
ing refueling. Gasohol may causepaint damage.
NOTICE
45 L (11.9 gal., 9.9 Imp. gal.)
GASOLINES CONTAINING ALCOHOL
If your engine knocks... FUEL TANK CAPACITY
