79
On vehicles with automatic transmission,
even if you turn off the overdrive switch with
the cruise control on, engine braking
will not be applied because the cruise
control is not cancelled. To decrease the
vehhicle speed, reset to a slower speed
with the cruise control lever or depress
the brake pedal. If you use the brake ped- al, cruise control is cancelled. RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal or clutch pedal, pushing the
lever up in the RES/ACCº direction will
restore the speed set prior to cancellation.
However, once the vehicle speed falls
below about 40 km/h (25 mph), the preset
speed will not be resumed.
CRUISE CONTROL FAILURE WARN- ING
If the CRUISEº indicator light in the instu-
ment cluster flashes when using the cruise control, there is some trouble in the
cruise control system, Contact your Toyo-
ta dealer and have your vehicle inspected.

80

Part 1Car audio systemÐ ÐReference ÐUsing your audio system:
some basics
81
OPERATION OF INSTRUMENTS AND CONTROLSÐ
Chapter 1-7 Car audio systemand Air conditioning system
Car audio system
Reference
Using your audio system: some basics
Using your audio system: controls and features
Car audio system operating hints
Air conditioning system
Controls
Air flow selector settings
Operating tips
Side vents
Type 1-1: AM´FM ETR radio
Type 2: AM´FM ETR radio/cassette player
This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-tem.
Your audio system works when the igni- tion key is in the ACCº or ONº position. TURNING THE SYSTEM ON AND OFF
Push PWR
V VOLº or PWR/VOLº to turn
the audio system on and off. Push AM V FMº or TAPEº to turn on that
function without pushing PWR VVOLº or
PWR/VOLº.
You can turn on the cassette player by in- serting a cassette tape.
You can turn off the cassette player by
ejecting the cassette tape. If the audio
system was previously off, then the entire
audio system will be turned off when you eject the cassette tape. If the radio was
previously on, it will come on again. SWITCHING BETWEEN FUNCTIONS Push AM V FMº or TAPEº if the system is
already on but you want to switch from
one function to the other.

82
TONE AND BALANCE
For details about your system's tone and
balance controls, see the description ofyour own system.
Tone
How good an audio program sounds to
you is largely determined by the mix of the
treble and bass levels. In fact, different
kinds of m
usic and vocal programs usual-
ly sound better with different mixes of treble and bass. Balance
A good balance of the left and right stereo
channels and of the front and rear sound levels is also important. Keep in mind that if you are listening to a
stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another. YOUR RADIO ANTENNA
For coupe models-To
lower a manual an-
tenna, carefully push it down.
To prevent damage to the antenna,
make sure it is retracted before driv-
ing your Toyota through an auto-matic car wash.
NOTICE
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed tape should be to the right.
Do not oil any part of the player anddo not insert anything other than
cassette tapes into the slot, or thetape player may be damaged.
NOTICE

83
Details of specific buttons, controls, and
features are described in
the alphabetical
listing that follows.
ÐUsing your audio system:
controls and features
Type 1

84
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and tune in radio stations.
To preset a station to a button: Tune in the
desired station (see TUNEº). Push and
hold down
the button until you hear a beep
-this will set the station to the button. The
button number will appear on the display.
To tune in to a preset station: Push the
button for the station you want. The button
number and station frequency will appear
on the display.
These systems can store one AM and one
FM station for each button. The preset
station memory will be canceled out if the
power source is interrupted (battery dis-
connected or fuse blown). AM V FM
Push AM V FMº to switch between the AM
and FM brands. AMº or FMº will appear
on the display.
If the audio system is off, you can turn on the radio by pushing AM V FMº. BAL (Balance)
This knob lets you adjust the balance be- tween the right and left speakers.
PushBAL/FADEº so
that it pops out of its
retracted position. Turn the knob to adjust
the balance. Push the knob back into its
retracted position. BASS This knob lets you adjust the bass level. Push BASS/TREBº so that it pops out of
its retracted position. Turn the knob to ad-
just the bass. Push the knob back into its
retracted position.
FADE
This knob lets you adjust the balance be- tween the front and rear speakers. Push BAL/F ADEº so that it pops out of its
retracted position. Pull out the knob. Turn
the knob to adjust the front/rear balance.Push the knob back into its retracted posi-
tion. PWR
V VOL (Power V Volume)
Push PWR V VOLº to turn the audio sys-
tem on and off. Turn the PWR V VOLº
knob to adjust the volume. SCAN When you push SCANº, the radio finds
the next station up the station band, plays
it for 5 seconds, and then scans again. To select a station, push SCANº a second time.
ST (Stereo reception) display
Your radio automatically changes to ste-
reo reception when a stereo broadcast is
received. STº appears on the display. If the signal becomes weak, the radio re-
duces the amount of channel separationto prevent the weak signal from creating
noise. If the signal becomes extremely weak, the radio switches from stereo tomono reception.

85
TREB (Treble)
This knob lets you adjust treble level. Push BASS/TREBº so that it pops out of
its retracted position. Pull out the knob.
Turn the knob to adjust the treble. Push the knob back into its retracted position. TUNE
Tuning
Your Toyota has an electronic tuning radio (ETR). Push and release the
~º (up) or  !º
(down) side of TUNEº to step up or down
the station band. If you hear a beep, you
held the button too long and the radio will
go into the seek mode. Seeking
In the seek mode, the radio finds and plays the next station up or down the sta- tion band.
To seek a station, push and hold the  ~º or
 ! º side of TUNEº until you hear a beep.
Do this again to find another station.

86Details of specific buttons, controls and
features are described in
the alphabetical
listing that follows.

Type 2
