1997 HONDA ODYSSEY mirror

Instruments and Controls

This section gives information about the controls and displays thatcontribute to the daily operation of
your Honda. All the essential controls are within easy reach.
Control Locations............................ 32
Indicator Lights................................ 33 Gauges.............................................. 37
Speedometer................................ 37
Trip Meter.................................... 37
Odometer...................................... 37

Temperature Gauge.................... 38 Fuel Gauge................................... 38
Maintenance Required Indicator.................................... 38
Controls Near the Steering
Wheel........................................ 39

Headlights.................................... 40
Daytime Running Lights............. 40
Instrument Panel Brightness..... 41
Turn Signals................................. 41
Windshield Wipers...................... 42
Windshield Washers................... 43 Rear Window Wiper and Washer......................................
43

Hazard Warning...........................
43

Rear Window Defogger.............. 44
Steering Wheel Adjustment....... 44
Steering Wheel Controls ................ 46 Cruise Control.............................. 46
Keys and Locks................................ 49
Keys...............................................49

Ignition Switch............................. 49
Power Door Locks....................... 50
Remote Transmitter....................

51

Childproof Door
Locks............... 52
Tailgate......................................... 52 Glove Box..................................... 53

Seats.................................................. 54
Passenger Seating....................... 54

Seat Adjustments......................... 54

Driver's Seat Power Height Adjustment............................... 55
Head Restraints........................... 56
Third Seat Access........................ 56

Removing the Second Seats
in the Six-Passenger Model.... 57
Folding the Second Seats in the Seven-PassengerModel.................................... 58
Reclining the Second Seat.......... 59
Folding the Third Seat in All Models............................ 60

Power Windows............................... 62

Sunroof.............................................. 63
Mirrors.............................................. 64
Adjusting the Power Mirrors..... 64

Parking Brake.................................. 65

Digital Clock..................................... 66
Beverage Holder.............................. 66

Dashboard Compartment............... 68
Center Pocket.................................. 68

Vanity Mirror................................... 68
Cigarette Lighter............................. 69

Ashtrays............................................ 69
Interior Lights.................................. 70
Ceiling Lights............................... 70
Spotlights...................................... 70

Tailgate Light............................... 71
Courtesy Lights........................... 71

Instruments and ControlsProCarManuals.comMain Menu s t

Control Locations

Instruments and Controls
MIRROR
CONTROLS

(P.64)
DIGITAL CLOCK
(P.66)
HEATING/COOLING

CONTROLS

(P.74)

AUDIO SYSTEM

(P.83)
DOOR LOCK
SWITCH (P.50)
POWER WINDOW
SWITCH
(P.62)

FUEL FILL DOOR RELEASE(P.110)
HOOD RELEASE
HANDLE(P.111)ProCarManuals.comMain Menu Table of Contents s t

Mirrors

TAB
Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving.
The inside mirror has day and night positions. The night position reduces
glare from headlights behind you. Flip the tab on the bottom edge of
the mirror to select the day or night

position.
Adjusting the Power Mirrors
Adjust the outside mirrors with the
adjustment switch on the driver'sdoor armrest:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).
3. Push the appropriate edge of the

adjustment switch to move the

mirror right, left, up or down.
4. When you finish, move the
selector switch to the center (off)

position. This turns off the
adjustment switch so you can't

move a mirror out of position by

accidentally bumping the switch.
Instruments and Controls SELECTOR SWITCH
ADJUSTMENT SWITCHProCarManuals.comMain Menu Table of Contents s t

Dashboard Compartment, Center Pocket, Vanity Mirror

Dashboard Compartment
Open the dashboard compartment
by squeezing the handle. Close it
with a firm push. Center Pocket
Open the center pocket by pulling
the handle. Close it with a firm push.
The light in the pocket comes on when the instrument panel lights are
on.
Vanity Mirror
To use the vanity mirror, pull down
either sun visor and swing down the

cover.

The passenger's vanity mirror is lighted. The light beside the mirror
comes on only when the light switch
is turned on.
On U.S. models
The driver's vanity mirror is also lighted.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Preparing to Drive

You should do the following checks and adjustments every day before
you drive your car.
1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,or ice.
2. Check that the hood and tailgate are fully closed.
3. Visually check the tires. If a tire looks low, use a gauge to check its
pressure.
4. Check that any items you may be carrying with you inside are stored
properly or fastened down securely. 5. Check the adjustment of the seat
(see page 54).
6. Check the adjustment of the inside and outside mirrors (see
page 64).
7. Check the adjustment of the steering wheel (see page 44).
8. Make sure the doors are securely
closed and locked.

9. Fasten your seat belt. Check that your passengers have fastenedtheir seat belts (see page 7). 10.Turn the ignition ON (II). Check
the indicator lights in the instru-
ment panel.
11. Start the engine (see page 119).
12. Check the gauges and indicator lights in the instrument panel (seepage 33).

DrivingProCarManuals.comMain Menu Table of Contents s t

Towing a Trailer

Mirrors
Many states and provinces have laws
requiring special outside mirrors
when you are towing a trailer. Check the laws in your area. You may want
to install mirrors, even if they are not
required. Hook up the trailer and see
how much it obscures your ability to see behind you with the standard
mirrors. If you cannot see directly
behind you, or have a large blind spot next to the trailer or the car,
you should install mirrors intended for towing. Connecting the Trailer
Most trailers that have a gross
weight of 1,000 Ibs (450 kg) do not
have their own braking system. If
you are thinking of getting a trailer that does have brakes, make sure
they are electrically-operated. Thereare no provisions in your car to tap
into its hydraulic braking system.
Any attempt to attach the trailer's brakes to your car's hydraulicsystem, no matter how successful it
may seem, will lower braking effectiveness and create a potential

hazard.
Always use a safety chain when
towing a trailer. Connect the safetychain securely at both ends. Make
sure the chain crosses under the
tongue so it will catch the trailer if it becomes unhitched. Leave enoughslack in the chain so it can't bind in a
sharp turn. Do not let it drag on the

ground.

DrivingProCarManuals.comMain Menu Table of Contents s t

Index

Accessories
Installation.................................. 115
ACCESSORY (Ignition Key Position)........................................ 50
Adding Automatic Transmission
Fluid........................................ 152
Brake Fluid................................. 158
Engine Coolant........................... 152
Engine Oil................................... 148 Power Steering Fluid................. 159
Windshield Washer Fluid......... 156
Additional Safety Information........ 18 Door Locks................................... 19
Driving with Pets......................... 19
Head Restraint Position.............. 18
Seat-back Position........................ 18
Storing Cargo Safely................... 19
Additives, Engine Oil..................... 150
Adjustments
Mirrors.......................................... 64

Head Restraints........................... 56

Seats.............................................. 54

Steering Wheel............................ 44
Airbag (SRS).................................... 12
Air Cleaner Element...................... 160
Air Conditioning............................... 74
Maintenance............................... 169
Usage............................................. 74
Air Outlets (Vents).......................... 76
Air Pressure, Tires........................ 171
Alcohol and Drugs........................... 28
Alcohol in Gasoline........................ 108
Antifreeze....................................... 152 Anti-lock Brakes (ABS) Indicator Light..................... 35, 127
Operation.................................... 126
Anti-theft Steering Column Lock .. 50
Appearance Care........................... 185

Ashtray.............................................. 69

Audio System................................... 83
Automatic Speed Control................ 46
Automatic Transmission............... 120 Capacity, Fluid........................... 218
Checking Fluid Level................ 157
Shifting........................................ 120

Shift Lever Positions................. 120

Shift Position Indicator............. 120

Shift Lock Release..................... 123
Battery
Charging SystemIndicator............................ 34, 207
Jump Starting............................. 202
Maintenance............................... 164
Specifications............................. 221
Before Driving............................... 107
Belts, Seat........................................... 5
Beverage Holder.............................. 66 Body Repair.................................... 191

Brakes
Anti-lock System (ABS)............ 126
Break-in, New Linings .............. 108

Fluid............................................ 158
Light, Burned-out...................... 181
Parking.......................................... 65
System Indicator.......................... 34
Wear Indicators......................... 125
Brakes, ABS Operation.................................... 126
System Indicator.................. 35, 127
Braking System.............................. 125
CONTINUEDProCarManuals.comMain Menu s t

Index

Fluids Automatic Transmission........... 157

Brake........................................... 158

Power Steering........................... 159
Windshield Washer................... 156
FM Stereo Radio
Reception...................................... 97

Folding the Second Seats ............... 58
Folding the Third Seats.................. 60
Foreign Countries, Driving in...... 109

Four-way Flashers........................... 43

Front End, Towing by Emergency Wrecker...................................... 215

Fuel.................................................. 108
Fill Door and Cap....................... 110

Gauge............................................ 38

Octane Requirement................. 108

Oxygenated................................ 108

Tank, Filling the......................... 110

Fuses, Checking the...................... 211

Gas Mileage, Improving................ 114

Gasohol........................................... 108
Gasoline.......................................... 108

Gauge............................................ 38

Octane Requirement................. 108
Tank, Filling the......................... 110
Gas Station Procedures................. 110
Gauges Engine Coolant Temperature .... 38

Fuel................................................ 38

Gearshift Lever Positions............. 120

Glass Cleaning............................... 189

Glove Box......................................... 53
Halogen Headlight Bulbs.............. 179 Hazard Warning Flashers............... 43
Headlights......................................... 40 Aiming......................................... 177
Daytime Running Lights............. 40
High Beam Indicator................... 36
High Beams, Turning on............ 40Low Beams, Turning on............. 40
Reminder Chime.......................... 40
Replacing Halogen Bulbs ......... 179

Turning on....................................
40

Head Restraints...............................
56Heating and Cooling........................ 74
High Altitude, Starting at.............. 119
High-Low Beam Switch .................. 40
Hood, Opening the ........................ 111
Horn................................................... 39
Hot Coolant, Warning about........ 152
Hydroplaning.................................. 129

Identification Number, Vehicle.... 218

If Your Car Has to be Towed....... 215

Ignition
Keys............................................... 49
Switch............................................ 49
Timing Control System............. 226
Indicator Lights, Instrument
Panel..............................................33

Infant Restraint................................ 22

Inflation, Proper Tire .................... 171

Inside Mirror.................................... 64

Inspection, Tire.............................. 173
Instrument Panel............................. 33

Instrument Panel Brightness......... 41

Interior Cleaning............................ 188
Interior Lights.................................. 70ProCarManuals.comMain Menu s t
